Main Features
Channel Switch Pedal
A/B/Y Jack: 1/4 monaural jack ”
Power Requirements: AC adapter 9V DC (center minus plug), can
work without power (LED doesn’t work). Recommended to use Mooer
Micro Power
Current Draw: 8 mA
Dimensions: 93.5mm (D) 42mm (W) × × 52mm (H)
Weight: 145g
Accessories: Owner’s Manual
* Disclaimer: Any specification’s update won't be amended in this manual.
The comprehensive channel switch pedal, can switch the one way
signal to two different outputs, applicable for the circuit of instrument,
amplifier, speaker (be sure to use speaker cable) and pedalboard
The design of mode-choosing switch, which enables A, B channels
transfer from respectively to simultaneously
In both modes, ABY can be used in both positive and negative directions,
the signal path can flow from A/B to Y, or from Y to A/B
Can work without power supply (LED will not light up)
Full metal shell
Very small and compact design
True byp ass switch
DC 9V adapter power su pply
A/B Mode: Y(instrument) A/B(amplifier A / amplifier B), stepped →
on the foot switch to select the amplifier
A / B Y(A &B)
A:R ED
B:B LUE
Y:PI NK
A(instrume nt A)/B(instrument B) Y(amplifier) Stepped →
on the foot switch to select the instrument
A / B Y(A &B)
A:R ED
B:B LUE
Y:PI NK
A&B Mode: In this mode, can connect any A, B, Y connector according
to personal demand
1. CHANNEL SELECT Footswitch:
Push down the footswitch to toggle
between channel A and channel B
(in A&B mode, footswitch is invalid).
3. LED Light:
4. DC IN Power Jack:
5. A Jack:
1/4” mono audio jack, connect instruments
or speakers and other devices.
In A/B mode, indicates in A channel
or B channel; the red lights mean in
A channel, the blue lights mean in B
channel; In A&B mode, LED lights
turn into pink.
A / B Y(A&B)
A:RED
B:BLUE
Y:PINK
6
52
4
7
3
2. MODE SELECT Switch:
Select A/B mode or A&B mode.
For power supply, use a 9-volt
DC regulated AC adapter (plug
polarity is positive on the barrel
and negative in the center).
6. B Jack:
1/4” mono audio jack, connect instruments
or speakers and other devices.
7. Y Jack: 1/4 mono audio jack, connect instruments or speakers and other ”
devices.
Diagrams
Panel Instruction
Specification
PLEASE READ CAREFULLY BEFORE PROCEEDING
Power Supp ly
Connections
Always turn off th e power of this a nd all other eq uipment before connecting or
disconnecting, this will help prev ent malfunction and / or dama ge to other devices.
Also make sure to disconnect all connection cables and the power cord before
moving thi s unit.
Cleaning
Clean only w ith a soft, dry cloth. If necessary, slightly moi sten the cloth.
Do not use abrasive cleanser, cleaning alcohol, pai nt thinners, wax, solven ts,
cleaning fluids, or chemical-impregnated wiping cloths.
Interfer ence with other electrical devices
Radios and t elevisions placed near by may experience reception interference.
Operate th is unit at a suitable distance from radios and televisi ons.
Location
To avoid deformation, disc oloration, or other serious damage, do n ot expose
this unit to t he following conditions:
Direct sunlight Heat sources
Magnetic fields Extreme temperature o r humidity
Excessiv e dusty or dirty location High humidity or moisture
Strong vibrations or shocks
Please con nect the designated AC adapter to an AC outlet o f the correct voltage.
Please be su re to use only an AC adapter which s upplies 9V (±10%) DC, center
minus. The maxi mum working voltage shall n ot exceed 12V, otherwise may be
dangerou s equipment d amage, fire or o ther problems.
Unplug the AC p ower adapte r when not using or during elec trical storms.
Precautions
FCC certif ication
This devic e complies with Part 15 of the FC C Rules. Operation is subject
to the following two cond itions:
This device may not ca use harmful interferen ce.
This device must accept any interference received, including interference
that may cau se undesired operation.
