Precautions
PLEASE READ CAREFULLY BEFORE PROCEEDING
Interference with other electrical devices and Cleaning
Radios and televisions placed nearby may experience reception interference.
Operate this unit at a suitable distance from radios and televisions.
Clean only with a soft, dry cloth.
Power Supply
Please connect the designated AC adapter to an AC outlet of the correct voltage.
Please be sure to use only an AC adapter which supplies 9V DC, ,center
negative. Unplug the AC power adapter when not in use or during electrical storms.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metal, or other objects into this unit.
Take care not to drop the unit, and do not subject it to shock or excessive pressure.
FCC certification
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
Connections
Always turn off the power and all other equipment before connecting or
disconnecting. This will help prevent malfunction and dama ge to any of the devices.
Make sure to unplug all connection cables and power cords before moving this unit.
To avoid deformation, discoloration, or other serious damage,
do not expose this unit to the following conditions:
Direct sunlight
Magnetic fields
Excessively dusty or dirty location
Strong vibration or shock
Extreme temperature or humidity
High humidity or moisture
Heat sources
Introduction
MODFACTORY MKII is a revamped update of our very popular MOD FACTORY
Micro pedal. Sporting a compilation of 11 brand new modula tion algorithms, taken
directly from the award winning MOD FACTORY PRO and a whole host of exciting
control features and routing options. MOD FACTORY MKII is a highly versatile
micro pedal and is sure to fill all your modulation needs.
MKII
Pedal layout
Features
Digital Multi Modulation pedal with 11 different algorithms
SERIES/PARALLEL routing control
TAP TEMPO control
ACCELERATION feature
9
MK I I
DC I N
SPEED CTR L
DEPTH
RIN G
LOW B IT
SERIES PARALLEL
TAP/ ACCE L
CHO RUS
FLA NGE
TRE M
PHA SE
VIB RA
STU TT
ROTA R Y
AUT O
WAH
LIQ UID
1 3
2
7
85
6
6. FOOTSWITCH
The footswitch has 3 different functions
7. INPUT
Connect to your instrument using a standard ¼” jack cable
8.OUTPUT
Connect to your amplifier using a standard ¼” jack cable
ON/OFF
Press the footswitch to toggle the pedal on/off
ACCEL
When the pedal is on, press and hold the footswitch to engage
the acceleration feature.
The speed will gradually increase. Release the footswitch to revert
back to normal speed
TAP
When the pedal is on, double press the footswitch to enter tap tempo mode.
The LED will change colour to signify tap tempo mode. Tap the footswitch
in your desired tempo to set the speed of the effect .
The pedal will automatically exit tap tempo mode, 5 seconds after your last tap.
1. SPEED
Adjusts the speed of the modulation effect
2. DEPTH
Adjusts the depth of the modulation effect
3. CTRL
Adjusts various different parameters
depending on the modulation type
(See CTRL table)
4. MOD SELECTOR
Selects the type of modulation effect
5. SERIES/PARALLEL
Toggles between serial and parallel
internal signal chain.
SERIES = BLUE
PARALLEL = RED
9.DCIN
Connect to a 9V DC 160mA power source
4
CTRL TABLE
MOD TYPE CTRL
1
2
3
4
5
6
7
8
9
10
11
CH RUSO
FLANGER
TREMOLO
PHASER
VIBRATO
ROT RYA
LIQUID
AUTO WAH
STUTTER
RING
LOW BIT
tone
feedback
tone
tone
tone
tone
tone
tone
tone
tone
Bit Rate
SERIES/PARALLEL
The SERIES/PARALLEL switch toggles between serial and parallel internal
signal chain routing. This effectively provides 2 very different sounds from each
modulation type.
In SERIAL mode the entire guitar signal is routed through the modulation circuit
providing very obvious and strong effects. The LED will show BLUE when the
pedal is in SERIAL mode.
In PARALLEL mode the guitar signal is split at the input, before entering the
modulation circuit. One signal is routed through the modulation circuit and the
other is routed directly to the output of the pedal. This will retain your orig inal dry
signal and provide very different sounds from each of the modulation types.
*Notes Any specification’s update will not be amended in this manual.：
Input:1/4” mono audio jack. Impedance: 470（Ω）
Output:1/4” mono audio jack Impedance: 100 （Ω）
Power requirements: 9V DC
Current Draw:160mA
Dimensions:93.5mm(D) x 42mm(W) x 52mm(H)
Weight：146g
Part N o:203050 1592
Modulation Effects
OutInput
OutInput
