Morphy Richards Supervac Pro734030 Bruksanvisning

Morphy Richards dammsugare Supervac Pro734030

Läs nedan 📖 manual på svenska för Morphy Richards Supervac Pro734030 (12 sidor) i kategorin dammsugare. Denna guide var användbar för 5 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/12
VC734030MUK Rev2
Cordless Vacuum Cleaner
www.morphyrichards.co.uk/blog
For competitions, product hints and tips
and more join us at
Please read and keep these instructions for future use
www.facebook.com/morphyrichardsuk
@loveyourmorphy
CHARGE THE PRODUCT FULLY BEFORE FIRST USE
*Register at www.morphyrichards.co.uk/support
UK and Ireland customers only
VC734030MUK Rev 2.qxp_Instruction Book 08/03/2017 11:10 Page 1
2
Health and Safety
•WARNING: Whenever the cleaner is in use, due to the risk of
entrapment in rotating parts, keep loose clothing, hair, fingers etc.
away from the brush bar, nozzle and any handheld accessories.
•WARNING: Disconnect from the mains supply and remove the
handheld vacuum cleaner (15) before carrying out any routine
maintenance, such as cleaning any blockages, changing any
filters, accessing the motorised floor brush or removing the
battery.
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, if they have been given supervision
or instruction concerning the use of the appliance in a safe way and
understand the hazards involved.
•Only use the mains adaptor supplied with the unit.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be undertaken by children
without supervision.
•If the battery is damaged, do not use or try to charge it. Contact the
helpline on the back page.
•Refer to page 11 for disposal of the product and battery.
Personal safety
• WARNING: Only lift the product by the handles (3 & 6)
and never pick the cleaner up by the motorised floor
brush.
• WARNING: Misuse of the appliance could cause
personal injury.
•To prevent accidental contact with the rotating brush bar,
always remove the motorised floor brush (22) during
maintenance.
•Never use in the presence of explosive liquid or vapours.
•Never pick up inflammable or poisonous liquids such as
petrol, copier toner or other volatile substances. Never
pick up acids, asbestos or asbestos dust.
•Never touch the adaptor, product or cable with wet
hands.
•Unprofessional repairs can be dangerous for users.
•To protect against fire, electric shock and personal injury,
do not immerse cord, mains adaptor or cleaner in water
or other liquid.
•The appliance must never be left running unsupervised.
Location
•Do not use or keep this product outside.
•Do not store the appliance near hot surfaces eg. ovens or
heating appliances.
Product safety
•This appliance is not intended for liquid/wet pick up.
•Never use the appliance without the filter being installed.
•Never use the appliance to vacuum hot ashes, broken
glass, sharp objects or liquids.
•Never modify the cleaner in any way.
•Use only Morphy Richards spare parts and accessories.
Electrical requirements
•Check that the voltage on the rating plate of the mains
adaptor corresponds with your house electricity supply
which must be A.C. (Alternating Current).
•The battery is not a serviceable item. Remove at the end
of the product’s life for recycling.
The use of any electrical appliance requires the following common sense safety rules.
Please read these instructions carefully before using the product.
VC734030MUK Rev 2.qxp_Instruction Book 08/03/2017 11:10 Page 2
3
Features
(1) Backsaver handle button
(2) Upright handle On/Off
button
(3) Upright handle
(4) Backsaver pivot
(5) Handheld charging inlet
(6) Handheld vacuum cleaner
handle
(7) Power level indicator lights
(8) Charge indicator
(9) On/Off button
(10) Dust canister release
button
(11) Main filter
(12) Dust canister
(13) Upright handle connector
hole
(14) Upright handle release
buttons
(15) Handheld vacuum cleaner
(16) Battery
(17) Battery release button
(18) Dust canister swing base
release button
(19)
Handheld vacuum cleaner
attachments release buttons
(20) Handheld vacuum cleaner
suction inlet
(21) Dust canister swing base
(22) Motorised floor brush
(23) Mains adaptor connector
(24) Mains adaptor
(25) Dusting brush
(26) Upholstery nozzle
(27) Crevice tool
(28) Charging cradle electrical
connectors
(29) Charging cradle
(30) Tool storage
(31) Charging cradle base
(32) Charging cradle charging
inlet
(33) Charging cradle base
detach button
(34) Upper cord storage hook
(35) Lower cord storage hook
Product overview
24
3
1
2
5
7
9
10
12
18
22
14
16
19
6
12
11
21
1617
27
29
28
30
31 32 34
33 35
20
15
25 2623
44
3
13
8
VC734030MUK Rev 2.qxp_Instruction Book 08/03/2017 11:10 Page 3
