OPERATING INSTRUCTIONS
AND OWNER’S MANUAL
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
PORTABLE PROPANE HEATER FOR
RECREATIONAL AND COMMERCIAL USE
MH18B
Model #
01/10 78438US Rev. DMR. HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216- 6-300091
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
WARNING:
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appli-
ance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light appliance.•
•
Shut off gas to appliance.•
— Service must be performed by a qualified service agency.
Adequate combustion and ventilation air must be provided. Refer to page 2.
START SERIAL #MHC-748000572690
LANGUAGES
ENGLISH
Pages E1 — E8
SPANISH
Pages S1 — S8
e-2
Mr. Heater | Big Buddy Operating Instructions and Owner’s Manual
warning:
Every time hose or tank is connected to unit, connection
must be checked for leaks in one or more ways: Apply
soapy water to connection, look for bubbles, listen for
hiss of escaping gas, feel for extreme cold, smell for rot-
ten egg odor. Do not use if leaking!
warning:
Any changes to this heater or its controls can be danger-
ous.
warning:
Early signs of carbon monoxide poisoning resemble the
flu, with headache, dizziness and/or nausea. If you have
these signs, heater may not be working properly. Get
fresh air at once! Have heater serviced.
speciFicatiOns
MODEL NO. .....................................................MH18B
GAS TYPE ......................................................PROPANE
INPUT BTU/HR. ......................... 4,000 / 9,000 /18,000
CLEARANCE TO COMBUSTIBLES
TOP ....................................................................... 30”
FRONT ....................................................................24”
SIDES ...................................................................... 6”
REAR ....................................................................... 0”
warning:
If the recreational or commercial enclosure does not
have a window or roof vent, DO NOT USE THIS HEATER
INSIDE.
tHe state OF caliFOrnia reQuires tHe
FOllOwing warning:
warning:
Combustion by-products produced when using this product
contain carbon monoxide, a chemical known to the State
of California to cause cancer and birth defects (or other
reproductive harm).
cOntents
General Safety Instructions ............................................ E-2
General Information ....................................................... E-3
Operating with Disposable Propane Cylinders ................ E-3
Operating With Hose Connected to Remote Cylinder ..... E-4
Maintenance.................................................................. E-5
Troubleshooting ............................................................. E-6
Parts List ........................................................................ E-6
Parts Ordering Information ............................................ E-8
Service Information ........................................................ E-8
• Due to high temperatures, the appliance should be
located out of traffic and away from combustible materi-
als.
• Children and adults should be alerted to the hazard of
high surface temperatures and should stay away to avoid
burns or clothing ignition.
• Young children should be carefully supervised when they
are near the appliance.
• Do not place clothing or other flammable material on or
near the appliance.
• Do not operate heater in any moving vehicle.
• This heater can only be used in a recreational or com-
mercial enclosure with a window or roof vent. It may
also be used outdoors.
• This heater requires a vent area of 18 square inches
(example 4 1
/4” x 4 1
/4” opening) minimum for adequate
ventilation during operation. Do not use other fuel burn-
ing appliances inside.
• GAS PRESSURE AT HEATER IS REGULATED AND FIXED
AT 11” W.C. WHEN USING A REMOTE HOSE CONNEC-
TION TO HEATER REGULATOR(S), DO NOT REGULATE
OR REDUCE PROPANE TANK SUPPLY PRESSURE TO
HEATER.
• warning: ANY HOSE CONNECTION TO A QUICK DIS-
CONNECT FITTING ON HEATER MUST BE REGULATED
TO 11” W.C. PRESSURE
• REGULATOR(S) IN HEATER MUST ALWAYS BE IN PLACE
DURING OPERATION.
• Any safety screen or guard removed for servicing the ap-
pliance must be replaced prior to operating the heater.
general saFetY instructiOns
tHis is a Heating appliance. dO nOt Operate
tHis appliance witHOut tHe FrOnt wire guard
installed
cautiOn: Some carpets or linoleum may discolor if
heater is placed directly on these floor coverings.
Operating Instructions and Owner’s ManualMr. Heater | Big Buddy e-3
general inFOrMatiOn:
• This heater is safe for indoor use in small recreational
enclosures, having means for providing combustion air
and ventilation, such as enclosed porches, cabins, fishing
huts, trailers, tent trailers, tents, truck caps and vans.
It may be used for emergency indoor heating when
connected to a disposable 1-lb. propane cylinder(s) and
for indoor use in commercial enclosures, having means
for providing combustion air and ventilation, such as
construction trailers or temporary work enclosures.
• When the heater is cold or at room temperature, it will
take a few minutes for the burner(s) tile to turn bright
orange. This is normal and the heater is working prop-
erly. If burner(s) tile is visibly aming, turn heater off
and call a qualified service technician.
• When the unit is lit, there should be about a quarter
• The appliance should be inspected before each use. Fre-
quent cleaning may be required. The control compart-
ments, burner(s) and circulating air passageways of the
appliance must be kept clean, see MAINTENANCE.
• DO NOT use this heater if any part has been under
water. Immediately call a qualified service technician to
inspect the heater and to replace any part of the control
system and any gas control, which has been under wa-
ter.
• When used without adequate combustion and ventila-
tion air, this heater may give off excessive CARBON
MONOXIDE, an odorless, poisonous gas.
• Some people - pregnant women, persons with heart
or lung disease, anemia, those under the influence of
alcohol, those at high altitudes - are more affected by
carbon monoxide than others.
• When heater is placed on the ground, make sure the
ground is level and keep any objects at least 24 inches
from the front of the heater. THIS HEATER IS EQUIPPED
WITH A TIP OVER SWITCH THAT WILL SHUT THE HEAT-
ER OFF IF THE HEATER TIPS OVER HOWEVER, DO NOT
LEAVE HEATER UNATTENDED OR WHERE CHILDREN
MAY CAUSE THE HEATER TO TIP OVER. NEVER OPERATE
THE HEATER WHILE SLEEPING!
inch border around the tile that will not turn bright
orange. This is normal.
• When operating the heater at altitudes over 7,000 FT.
above sea level, the unit may not burn as bright as in
lower altitudes. This is normal. At higher altitudes, the
heater may shut-off. If this happens, provide fresh air,
wait 5 minutes and re-light. Due to local atmospheric
conditions heater may not re-light.
• Operating time will vary depending on the heater set-
ting and the supply cylinder size. (One 1 lb. cylinder: 1.5
to 6 hours. Two 1 lb. cylinders: 3 to 12 hours. Two 20
lb. cylinders: 50 to 220 hours.) Heater may be operated
from quick disconnect, one or both regulated inlets.
• When moving heater when lit or bumping heater setting
it down, tip over switch may shut off heater. If this hap-
pens, re-light.
• nOte: tHis Heater MaY Be Operated witH (1) Or (2)
dispOsaBle 1 lB. prOpane cYlinders Or witH a re-
MOte reFillaBle cYlinder(s) MaX. 20 lBs using (1)
Or (2) F273701, F273702 Or F272702 HOse asseMBlies
witH Fuel Filters (F273699) On eacH HOse asseMBlY.
it MaY alsO Be Operated witH (1) F271802 HOse
asseMBlY cOnnected tO a regulated (11” w.c.)
prOpane sOurce Or (1) F271803 HOse asseMBlY witH
11” regulatOr witH acMe nut.
ligHting / Operating instructiOns
FOr use witH dispOsaBle 1 lB.
prOpane cYlinders:
warning: Always inspect propane cylinder and heater propane
connections for damage, dirt, and debris before attaching
propane cylinder. Do not use if head of cylinder is damaged,
punctured or deteriorated.
ALWAYS ATTACH OR DETACH CYLINDER OUTDOORS AWAY
FROM FLAMES, OTHER IGNITION SOURCES, AND ONLY WHEN
HEATER IS COOL TO TOUCH. NEVER SMOKE WHEN ATTACHING
OR REMOVING PROPANE CYLINDER OR MAKING REMOTE
CONNECTIONS!
• Use only LP-gas cylinders marked in accordance with the
U.S. Dept. of Transportation (DOT).
• Use only 16.4 oz. (1 lb.) disposable cylinders that mate
with No. 600 valve connection.
• Heater and attached cylinder(s) must be in an upright
position during operation.
• Make sure ve-position Control Knob is in “OFF” posi-
tion; see Figure 1.
• Screw 1 lb. disposable LP-gas supply cylinder(s) clock-
wise (from bottom) into portable heater until hand-tight.
• Check cylinder(s) connection for leaks with soapy water
at the threaded connection under the domed plastic
cover where the cylinder screws into the regulator. SEE
WARNING! ON PLASTIC COVER DOORS.
• Depress and turn Control Knob counterclockwise to “PI-
LOT” position. Ignitor will spark to light the pilot burner.
(If needed, repeat these steps until pilot lights) and
continue to hold control knob down in “Pilot” position
for 30-60 seconds.
• After lighting pilot, release knob. Knob should return
