MXL Forge Bruksanvisning

MXL mikrofon Forge

Läs nedan 📖 manual på svenska för MXL Forge (2 sidor) i kategorin mikrofon. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/2
Premium
USB Microphone
A Division of Marshall Electronics
310-333-0606
800-800-6608
www.mxlmics.com
sales@mxlmics.com
Warranty
MXL microphones are guaranteed against defects in materials and workmanship
for one year from the date of purchase. If you encounter any problem with this unit,
promptly contact the company from which you purchased it for assistance. The
original dated sales receipt will be necessary for any warranty claim. Do not send
any unit directly to us without prior authorization from our service department.
Warranty coverage is limited to repair or replacement (at our option) of the
microphone, and does not cover incidental damages due to use of this unit, nor
damage caused by accidental misuse of this product.
5Polar Patterns - Selectable with the switch on the back
of the microphone
Cardioid - Microphone picks up audio from the front
side. Best for one person using the mic for streaming
and podcasting.
Omni - Microphone picks up audio from all sides.
Best for use with 2 or more people or if you’re
recording multiple sources at once in a room.
Note: NOT The top of the microphone does pick up audio.
Onboard
headphone and
mic gain controls
Mute Toggle
Cardioid/Omni
Pickup Switch
Controls
Features
• Plug and Play USB connectivity
• Cardioid and Omni pickup patterns
• Zero latency headphone output
• Onboard earphone and mic gain controls
• Removable stand to mount mic with boom armMXL Flex
• Mac and PC compatible
Built to work, the delivers professional quality Forge Plug and Play USB Microphone
and functionability packed into a sleek all-in-one tool. With selectable pickup
patterns, dedicated audio controls, and exible mounting, The Forge empowers you
to optimize your audio for your next stream, recording or remote work meeting.
Every time, in no time.
Premium USB Microphone
QUICKSTART GUIDE
Connect the USB-Cable to the microphone and computer.
Set computer input and
output sound settings to
“MXL Forge”
Control Modes
Press the to toggle modes. control knob
You will see either a blue or green light.
Blue Light - Adjust the level so the
microphone audio is not peaking
(Use the meter in your audio settings
or capture software)
Green Light - Adjust the headphone
audio volume.
Mute button
Mutes the mic audio input
Power Requirements: ................................................5V DC, 0.3A max
Sample Rate: ...........................................................................48kHz, 96kHz
Bit Depth: .......................................................................................................24Bit
Capsules: MXL .................................................. - Dual Electret Design
Polar Patterns: .........................................Cardioid, Omnidirectional
Frequency Response: ........................................................20Hz - 20kHz
Sensitivity: .................................................................-33dBFS (min gain)
Max SPL: .........................................................................................................90dB
Dimensions (with stand): ....................................118 x 118 x 262mm
Weight: ..........................................................................................................1055g
Computer Compatibility: ........................... Windows 10 or above
Mac 10.13 or above
Technical Specications
Continued on following page
1
2
3
4

Produktspecifikationer

Varumärke: MXL
Kategori: mikrofon
Modell: Forge
