Sida 1/4
NEXT
GENERATION
HOT
WATER
EST. 2010 CONTINUOUS FLOW
6 STAR
Energy
Rating
12 YEAR
Warranty*
26 LPM
30 LPM
CONTINUOUS FLOW
GAS HOT WATER.
EFFICIENCY
6 Star Energy Rating.
84% Thermal Efficiency.
CONSERVATION
Solar Hot Water ready.
Install now, add solar later.
FREEZE
PROTECTION
Ignites at low temperature
to prevent freezing.
AESTHETICS
Sleek design.
Optional recess box.
RELIABILITY
12 Year Heat Exchanger Warranty.
3 Years Parts & Labour Warranty.
SAFETY
Adjustable temperature at fixture
using optional controller.
SPECIFICATIONS
& SIZING GUIDE.
SPECIFICATIONS
Model Number NP26 LP26 NP30 LP30
Unit Dimensions | Height x Width x Depth (mm) 571 x 394 x 166 566 x 373 x 240
Package Dimensions | Height x Width x Depth (mm) 697 x 465 x 255 703 x 451 x 345
NET Weight (KG) 19 22
Packaged Weight (KG) 22 25
Preset Temperature Options 50°C | 60°C | 70°C 50°C | 60°C | 70°C
Controller Optional Optional
Temperature range 37°C - 70°C 37°C - 70°C
Gas Type Natural Gas LPG Natural Gas LPG
Nominal Gas Consumption (MJ/h) 205 235
Thermal Efficiency 84% 84%
Hot Water Delivery (25°C Rise) 26LPM 30LPM
Min. Flow Rate (L/Minute) 3 3
Minimum Water Pressure (kPa) 20 20
Maximum Water Pressure (kPa) 1000 1000
Hot, Cold & Gas Connections (mm) 20 20
Voltage 240V 240V
Standby Power Consumption 2w 2w
Energy Rating 6 Star 6 Star
AGA Certified YES YES
Watermark Certified YES YES
SIZING GUIDE
Product Cool Climate Warm Climate
NP26 1-2 Bathrooms 1-3 Bathrooms
NP30 2-3 Bathrooms 2-4 Bathrooms
WARRANTY*
Heat Exchanger 12 Years
Parts & Labour 3 Years
Controller (Optional) 1 Year
*This is a guide only. Site specifics
and flow rates of fixtures will have an
impact on performance.
Please contact a Neopower hot water
expert on to discuss a 1300 062 788
solution to suit your specific needs.
Warranty policy & T&Cs available at
www.neopower.com.au
