LH 64 Mounting manual
Important safety and
mounting instructions
EN
• Read and follow the safety and mounting instructions, keep these
instructions easily accessible and always include them when pas-
sing the LH64 on to third parties.
• Also read and follow the installation instructions contained in the
operating manual of the studio monitor to be mounted.
• -When mounting, follow the local, national and international regu
lations and standards.
Intended use
The LH64 is a holder for fastening KH 80 DSP, KH 120, KH 120 II and
KH 150 studio monitors to a 75×75 VESA mount. The LH64 is only
suitable for the above-mentioned 2-way monitors and must only be
used indoors in dry, clean rooms such as studios.
To properly mount the LH64 together with a studio monitor, you need
additional products from the VESA75×75 range of accessories, as
well as additional fastening elements for mounting on the wall or a
surface.
The LH64 must not be used for other purposes or in other environ-
ments. In case of any damage or any deviation from the safety and
mounting instructions, immediately dismount the studio monitor and
the LH64.
Required qualifications
Only skilled personnel may attach the LH64 to the studio monitor and
mount it on the wall. Due to his/her technical training, know-how and
experience as well as knowledge of relevant provisions, regulations
and standards, the specialist must be able to assess assigned tasks,
recognize potential hazards and ensure appropriate safety measures.
Safety instructions for mounting
• Mount only one LH64 to a studio monitor, as described in these
assembly instructions. Centred suspension is recommended, see
Figure1a. When using the cinch sockets, the side suspension must
be used, see Figure1b.
• Place something soft underneath the studio monitor so that you do
not scratch its surface while performing the work.
• Always use the enclosed original accessories.
• The wall or surface must be able to support the weight of the studio
monitor and all accessories used, such that no parts will fall even
if someone pulls hards on the power or audio cables. When calcu-
lating the weight, also take into account the additional leverage.
• When mounting the LH 64 on the wall or surface, use products
from the range of accessories, as well as fastening VESA75× 75
elements (not included with delivery) that are suciently dimensi-
oned to ensure that the entire weight is held securely.
• Tighten all screws by hand. Once you have finished mounting and
aligning the studio monitor, ensure that all screws are firmly tigh-
tened.
• Do not use the LH64 in environments that are exposed to external
vibrations.
• Every 3 months, check that all screws are properly tightened and
that the LH64, the studio monitor, the mounting accessories and
the wall on which the LH64 is mounted are in the proper condition.
Package contents
A: 1 × adapter plate
B: 2 × Allen screws, M8×12
C: 2 × Allen screws, M6×12
D: 1 × Allen key, 4mm
E: 1 × Allen key, 5mm
Specifications
Weight 0.2kg
Dimensions when assembled 96×98×22,5mm (H × W × D)
Max. load 10kg
Guarantee
For the current terms and conditions of the product guarantee
please visit www.neumann.com.
· . · · / · /
() / - · - · @. · ..
LH 64
Mounting manual
1a
2
1b
B = KH 120
C = KH 80 DSP/
KH 150
B = KH 120
C = KH 80 DSP/
KH 150
C
B/C
D/E
A
B/C
D/E
A
D
B
E
A
