Welcome. Thank you for buying a NOCO Genius

GX Series Smart Charger. Read and understand the

User Guide before operating the charger. For questions

regarding our chargers, view our comprehensive support

information at www.no.co/support. To contact NOCO for

personalized support (not available in all areas), visit

www.no.co/connect.

What’s In The Box.

• GX Series Smart Charger

• AC Cable

• User Guide

• Information Guide and Warranty

User Guide

GXSeries

PRIOR TO USE, READ AND UNDERSTAND

PRODUCT SAFETY INFORMATION.

Failure to follow the instructions may result

in ELECTRICAL SHOCK, EXPLOSION,

or FIRE, which may result in SERIOUS

INJURY, DEATH, DAMAGE TO DEVICE or

PROPERTY. Do not discard this information.

DANGER

Basic Charging ModeContacting NOCO.

About GX Series Chargers. The NOCO Genius

® GX

Series of chargers represents some of the most innovative

and advanced technology on the market, making each

charge simple and easy. The GX is designed for charging all

types of 24V, 36V or 48V lead-acid and lithium-ion battery

systems, including Wet (Flooded), Gel, MF (Maintenance-

Free), CA (Calcium), EFB (Enhanced Flooded Battery), AGM

(Absorption Glass Mat), and LIB (Lithium Ion) batteries. It

is suitable for charging battery capacities from 25 to 500

Amp-Hours and maintaining all battery sizes.

Getting Started. Before using the charger, carefully

read the battery manufacturer’s speciﬁc precautions and

recommended rates of charge for the battery. Make sure

to determine the voltage and chemistry of the battery by

referring to your battery owner’s manual prior to charging.

Mounting. The GX Series Chargers have four (4) external

holes for mounting. Make sure there are no obstructions

behind the mounting surface. It is important to keep in mind

the distance to the battery. Allow for 12-inches (304mm) of

slack in cables between connections.

Charging Modes. The GX Series Chargers have seven

(7) modes: Standby, NORM, COLD/AGM, AGM+, LI-ION,

REPAIR and SUPPLY. Some charge modes must be

pressed and held for three (3) seconds to enter the mode.

These “Press and Hold” modes are advanced charging

modes that require your full attention before selecting. It

is important to understand the differences and purpose

of each charge mode. Do not operate the charger until

you conﬁrm the appropriate charge mode for your battery.

Below is a brief description:

1.800.456.6626

support@no.co

30339 Diamond Parkway, #102

Glenwillow, OH 44139

United States of America

Phone:

Email:

Mailing Address:

Using AGM+. [Press &

Mode Explanation

AGM+

LI-ION

REPAIR

For charging advanced AGM batteries,

which requires a higher than normal

charging voltage. When selected, a

blue LED will illuminate.

For charging lithium-ion batteries,

including lithium iron phosphate. When

selected, a blue LED will illuminate.

An advanced battery recovery mode

for repairing and storing, old, idle,

damaged, stratiﬁed or sulfated

batteries. When selected, a red LED

will illuminate and ﬂash.

SUPPLY Converts to a DC power supply. When

selected, a red LED will illuminate.

Press & Hold

31.2V ± 0.3V | 40A ± 1A

46.8V +/- 0.4V | 26A ± 1A

62.4V +/-0.6V | 20A ± 1A

29.2V ± 0.3V | 40A ± 1A

43.8V +/-0.45V | 26A ± 1A

58.4V +/- 0.6V | 20A ± 1A

32V ± 0.3V | 5A ± 1A

48V +/-0.45V | 5A ± 1A

64V +/-0.6V | 5A ± 1A

GX2440

GX3626

GX4820

GX2440

GX3626

GX4820

GX2440

GX3626

GX4820

27.2V ± 0.3V | 20A ± 1A

40.8V +/-0.45V | 13A ± 1A

54.4V +/-0.6V | 10A ± 1A

GX2440

GX3626

GX4820

Advanced Charging Modes

IMPORTANT: Advanced Charge Modes are modes that

require the users full attention when selecting.
