THE PUMA GRILL

WWW.PRODUCTOSNUKE.COM.AR

General recommendations

OUTDOOR FIRE LINE

At the first start-up of the Grill it will give off paint odor, this is

because the paint cures in use, this event is normal and will not

repeat itself in the following uses.

During the curing process, no surface of the grill should be touched.

So your product is ready to Roast!!!

Do not burn plastics derived from oil.

Do not wet, in contact with moisture it may rust.

Choose a dry place for storage and shelter from

rain and dust.

(fig. 1)

(fig. 2)

CONTROLLING THE FRAME LIFT

Frame Elevation

Lowering the frame

WITH PRIDE, WE THANK YOUR PREFERENCE AND CONFIDENCE

TO ALL OF US WHO MAKE ÑUKE

The Puma grill has a steering wheel lifting mechanism. To operate it, the steering

wheel must be turned in the direction indicated in figure 1, to the desired height. It

includes a locking system that does not need to be operated when the frame is raised.

To lower the frame, the safety catch must be unlocked, holding it up and turning the

steering wheel in the opposite direction to the elevation, as shown in figure 2.

IMPORTANT!!! DO NOT RELEASE THE WHEEL WHILE THE INSURANCE IS RELEASED.

PRECAUTIONS

ASSEMBLING THE BASE

ASSEMBLING THE GRILL

The first step in assembling the

structure is to join and screw the

sides to the base.

If necessary, remove the

bricks, grills and stoker

to lighten the grill.

Don't forget to adjust the cross bars support once the grill

is attached to the base.

If necessary, require the

help of a person to raise

the grill to its base.

The grill is fixed with 4 screws

at the bottom of it.

The second step is to join the sides

by means of the cross bars support.

When screwing, leave them almost

unadjusted, you should adjust

them once the grill is located.

FAILURE TO OBSERVE THE HAZARD NOTICES, WARNINGS AND

PRECAUTIONS CONTAINED IN THIS OWNER'S MANUAL COULD

RESULT IN SERIOUS PERSONAL INJURY OR DEATH, OR IN A FIRE

OR EXPLOSION CAUSING PROPERTY DAMAGE.

SAFETY SYMBOLS ( ) will alert you to important information

Read all the safety information in this Owner's Guide before operating the grill.

Do not use it inside the house! This grill should only be used outdoors. If used indoors, fumes

will build up causing serious bodily injury or death.

If you use lighter fluid, after using it, cap the bottle of lighter and place it at a safe distance

from the grill.

You must be careful when operating your grill. It will be hot while cooking and should never

be left unattended while in use.

Do not remove the ashes until the charcoal has burned completely and is completely

extinguished and the grill is cold.

Keep grill on a level and safe surface at all times, away from combustible materials.

Do not dispose of hot coals where they could be stepped on or pose a fire risk.

Do not dispose of ashes or coals before they are completely extinguished.

Never add lighter fluid or charcoal impregnated with it to charcoal already lit.

Do not leave babies, children, or pets unattended near a hot grill.

Do not try to move the hot grill. Wait for the grill to cool down before moving it.

STEP 1

STEP 3

STEP 2
