Omega OFI604 Bruksanvisning

Omega Diskmaskin OFI604

Läs nedan 📖 manual på svenska för Omega OFI604 (2 sidor) i kategorin Diskmaskin. Denna guide var användbar för 10 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Sida 1/2
NB: Drawings are not to scale - they are to assist only. WARNING: technical specifications and product sizes can be varied by the manufacturer without notice. Cut-outs for appliances should only be by physical product measurements. The above information is indicative only.
Key features Benefits
Omega Dishwashers
Technical details
Installation type: Fully integrated built in
Place settings: 14
Wash programs: Intensive
Heavy
Normal
Glass
60 min
Quick
Water rating: 4.5 stars
Energy rating: 3.5 stars
Wash temperatures (ºC): 4 - 40, 50, 55 and 65
Maximum water
temperature (ºC): 60ºC
Floating plug: Yes
Lockable controls: No
Delayed start: Yes (3, 6 and 9 hours)
DualZone: No
Aquastop safety hose: No
Flexible top basket: Yes
Half load: Yes
Cutlery tray: Yes
Plate sizes allowed: Up to 30cm
Residual heat drying: Yes
Maximum current: 10amps
Connection: 240V, 50Hz
Water connection: Cold water recommended
Length of hose: 2.0m
Water pressure: 40 - 1000kpa
Noise: 49dBA
Warranty: 24 months parts and labour
Aesthetics
Finish: Supplied without a decorative
door
Controls: Electronic controls concealed in
the top of the door.
Dimensions/weight
Overall dimensions (mm): 815h x 598w x 550d
Weight: 43kg
OFI604
Omega 60cm fully integrated dishwasher with 14 place settings, electronic controls and 6 wash programs.
Flexible top basket Click the side levers of your top basket to lower it to accommodate tall glasses, or raise to
the higher position for maximum room in the bottom section.
DECORATIVE DOOR NOT
INCLUDED. DESIGNED TO
ACCOMMODATE YOUR
OWN CABINETRY.
Cutlery tray Positioned above the top basket, this tray eliminates streaks through superior drainage and
leaves more room in the dishwasher for plates, pots and pans.
The half load function will use less water and energy while effectively cleaning your half load.
Half load
Page 10
Updated 18/08/2017
