301 Fulling Mill Road, Suite G
Middletown, PA 17057
Phone (800) 321-2343 / Fax (717) 702-2546
www.onqlegrand.com
Page 1 of 9
INSTRUCTION/INSTALLATION SHEET
lyriQ™ High Performance Keypad
IS-0369 REV. E
©Copyright 2009 by Legrand All Rights Reserved.
1. Introduction
The lyriQ™ High Performance Keypad, P/N AU1000-xx (see Figure 1), is an
integral part of the lyriQ™ Multi-Room Audio System. It is a component which,
when combined with other essential components ( a Source Input Unit,
Distribution Module and Speakers) and your source equipment (receiver, CD
player, etc.), creates a versatile whole-house audio system that will fill your
rooms with high-quality sound for years to come. It uses Category 5 wiring to
distribute audio signals, control information and IR for remote control. The High
Performance Keypad has on-board 20 Watt per channel class D amplifiers to
provide a rich level of clean sound even in outdoor or large room applications.
It also contains a full set of features, including the ability to control all other
keypad volume controls in the house. Build a system that accommodates the
needs of any space by combining the lyriQ™ High Performance Keypad with
the lyriQ™ Standard Keypad (P/N AU7394-xx) in the same system. The
AU1000-xx is available in white (-WH), light almond (-LA), ivory (-IV), or black
(-BK).
2. Description
The front panel of the lyriQ™ High Performance Keypad, PN AU1000-xx (see
Figure 1), looks almost identical to the lyriQ™ Standard Keypad (AU7394-xx). It
also has push buttons for VOLUME UP/DOWN (with five associated green
Volume Bar Graph LEDs), SOURCE (with four green Source Selection LEDs)
and MUTE (with one red status LED). There is also an IR target window and tri-
colored status LED. The visual cue from the front panel that this is a High
Performance Volume Control are the parenthesis surrounding the music note in
the lower right hand corner.
NOTE: lyriQ™ Keypads are recommended for indoor use only.
On the rear of the lyriQ™ High Performance Keypad (see Figure 2) the Category
5 connection is an RJ45 jack (J1). The TB2 speaker output connections (left and
right, plus and minus) are spring loaded and designed to support up to 14 gauge
wire. The TB3 Line Out connections (plus and minus) are also spring loaded and
designed to support up to 14 gauge wire. This mono-summed output is designed
for powered sub-woofers and as such is filtered through an 80Hz low pass filter.
The other terminal block on the rear (TB1) is used for powering the keypad. Up to
14 gauge speaker wire may be used for this purpose, and this speaker wire (two
conductor or four conductor) is run from a power distribution module (P/N
AU1001) in the enclosure to the ketpad. We recommend 16/4 speaker wire,
since it is available paired with Category 5 from a variety of sources. Again, the
TB1 connections are spring loaded (plus and minus) with the two plus
connections on the red portion of TB1 and the two minus connections on the
black portion of TB1. For ease of installation, connect the red wire and white wire
to the red (plus) portion of TB1 and the black and green wire to the black (minus)
portion of TB1.
Figure 1
Figure 2
301 Fulling Mill Road, Suite G
Middletown, PA 17057
Phone (800) 321-2343 / Fax (717) 702-2546
www.onqlegrand.com
Page 2 of 9
INSTRUCTION/INSTALLATION SHEET
lyriQ™ High Performance Keypad
IS-0369 REV. E
©Copyright 2009 by Legrand All Rights Reserved.
3. Installation
Installation of the lyriQ™ High Performance Keypad is best accomplished at multiple times during new
construction, at “Rough-in” before the drywall is installed, and at “Trim-out” after the drywall is installed and
painted.
NOTE: Before connecting the keypads: Make sure that power supplies are not connected to the lyriQ™
Audio and Power Distribution Modules. For instructions on pre-wiring and installing other components of
the lyriQ™ Audio System, please see the Instruction Sheets included with those components.
NOTE: Always follow TIA-570-B wiring standards for installing and terminating Category 5 cable. Failure to
follow the correct wiring standard could result in damaged equipment and/or electrical interference issues.
NOTE: Maintain a minimum 12” separation between Category 5 cable and any 120VAC cabling.
A. “Rough-in” steps:
1) A single Category 5 cable and 16/4 speaker wire should be run from the enclosure location to a single
gang outlet box or mud ring at each Volume Control location.
B. “Trim-out” steps:
1) Connect the volume control by terminating the pre-wired Category 5 cable from the enclosure with an
RJ45 plug, following the T568A wiring standard and insert this plug into jack J1 (see Figure 2).
2) For the power connection (TB1) strip 3/8” of insulation from each of the four conductors and insert the
red and white wires into the red (plus) portion of TB1. Insert the stripped black and green wires into the
black (minus) portion of TB1 (see Figure 2).
NOTE: The two red connections are tied together, as are the two black connections. They are
provided in pairs to provide flexibility of wiring.
NOTE: Electricians may prefer to think of the black and red wires as plus and the green and white
wires as minus. That wiring will also work, as long as it is also followed at the other end of the cable
(at the Power Distribution Module in the enclosure).
3) Speaker/Line Out/Sub-Woofer connections (see Figure 2):
NOTE: Polarity and channels are clearly marked (L+, L-, R-, R+) for proper identification during
installation.
a) Use TB2 to connect one pair (only) of 8 ohm evōQ™ audio speakers to the volume control.
b) Use TB3 to connect your evōQ™ powered sub-woofer or an external amplifier to the volume control.
These connection terminals do not provide any amplification but the volume control on the keypad
controls the output level of this connection.
4) Connections in the enclosure (see Figure 3):
301 Fulling Mill Road, Suite G
Middletown, PA 17057
Phone (800) 321-2343 / Fax (717) 702-2546
www.onqlegrand.com
Page 3 of 9
INSTRUCTION/INSTALLATION SHEET
lyriQ™ High Performance Keypad
IS-0369 REV. E
©Copyright 2009 by Legrand All Rights Reserved.
a) The Category 5 cable that was run to each keypad location should be terminated with an RJ45 plug
according to the T568A wiring standard and inserted into one of the zone output jacks of the associated
lyriQ™ audio distribution module.
b) For the 16/4 speaker wire power cable that was run to each volume control location, strip 3/8” of
insulation from each of the four conductors and insert the red and white wires into the red (plus ) portion
of TB1. Insert the stripped black and green wires into the black (minus) portion of TB1
NOTE: As noted before, Electricians may prefer to think of the black and red wires as plus and the
green and white wires as minus. That wiring will also work, as long as it is also followed at each
end of the cable.
c) To connect more than eight (8) Keypads to a 4 Source 8 Zone Module, cascade Single Source Modules.
To cascade a Single Source Module, simply run a Cat 5e jumper from any Zone port RJ45 jack on the
front panel of the Multi-source Module he front panel of a Single Source to the “Source In” RJ45 jack on t
Module (see Figure 4).
Figure 3
