Speaker System

D-145

Instruction Manual

Thank you for purchasing an Onkyo Speaker System. Please read this manual

thoroughly before using it. Following the instructions in this manual will enable

you to obtain optimum performance and listening enjoyment from your new

Speaker System. Please retain this manual for future reference.

ᅝ㺙᠟ݠ

ᅝ㺙᠟ݠᅝ㺙᠟ݠ

ᛳ䇶ᙼ䌁фϔ༫᮹ᴀᅝḹ⠠ᡀໄ఼㋏㒳Ǆ೼Փ⫼ᴀᡀໄ఼㋏㒳Пࠡ

ˈ䇋䅸

ⳳ䯙䇏ᴀ᠟ݠǄ䙉ᅜᴀ᠟ݠЁⱘᣛ⼎ˈᙼⱘᮄᡀໄ఼㋏㒳ᇚ݋᳔

᳝

Շᗻ㛑ˈ

ᙼᇚӮѿফࠄໄ䷇ⱘ㕢཭Ǆ䇋

⬭ᴀ᠟ݠˈҹ໛ᇚᴹᶹ䯙Ǆ

Right speake

Left speake

Positive (+)

side is indicated

by a red line

Speaker cable

Getting to Know the Speakers

The two speakers are identical, so it doesn’t matter which one you use

on the left or right.

Using Close to a TV or Computer

TVs and computer monitors are magnetically sensitive devices and as

such are likely to suffer from discoloration or picture distortion when

conventional speakers are placed nearby. Note that discoloration can

also be caused by a magnet or demagnetizing tool that's too close to

your TV or monitor.

Removing the Grills Using the Cork Spacers

Connection the Speakers

࡮Before connecting the speakers, disconnect your amplifiers power

cord from the wall outlet and set its volume control to minimum.

࡮The speaker’s rated impedance is 4 . Make sure you connect an

amplifier that is compatible with a 4  impedance.

࡮Use the supplied speaker cables to connect the speakers to your

amplifier as shown.

1.Peel the

insulation off

the ends of

the speaker

cable and

twist the

core wires.

2.Loosen the

terminal screw

and insert the

speaker cable

into the hole

(until the core

wires are

inserted fully).

3.Fasten the

terminal

screw.

The type of speaker terminals used on the amplifier and their position

depends on the model. Refer to the amplifier’s instruction manual for

details on connecting speakers to the amplifier.

࡮Make sure the speaker’s positive (+) termi-

nals are connected to the amplifier’s positive

(+) terminals, and the speaker’s negative (–)

terminals are connected to the amplifier’s

negative (–) terminals.

࡮Make sure that the positive (+) and negative

(–) wires are not touching each other. If they

are, a short circuit may occur, damaging your

amplifier.

Care

To maintain the appearance of the speakers, you should periodically

wipe them with a soft, dry cloth. Do not use abrasive cloths, thinners,

alcohol, or other solvents that may damage the finish.

Before Using Your New Speakers

࡮

The speaker cabinets are made out of wood and are therefore

sensitive to extreme temperatures and humidity. Do not use

them in locations subject to direct sunlight or in humid

places, such as near an air conditioner, humidifier, bathroom,

or kitchen.

࡮Place the speakers on sturdy, flat surfaces. Putting them on

uneven or unstable surfaces where they may fall and cause

damage will affect the sound quality.

࡮Do not keep water or other liquids close to the speakers. If a

liquid is spilled over them, the woofer and tweeter inside may

be damaged.

࡮Do not handle the speakers with wet or damp hands.

Precautions

In catalogs and on packaging, the letter at the end of the product

name indicates the color. Specifications and operation are the same

regardless of the color.

The speakers can handle the specified input power when used for

normal music reproduction. If they’re fed any of the following sig-

nals, even if the input power is within the specified rating, exces-

sive current may flow in the speaker coils, causing burning or wire

breakage:

1. Interstation noise from an untuned FM radio.

2. Audio from a cassette that’s being fast-forwarded.

3. High-pitched sounds generated by an oscillator, electronic musi-

cal instrument, and so on.

4. Amplifier oscillation

5. Special test tones from audio test CDs and so on.

6. Thumps and clicks caused by connecting or disconnecting audio

cables (always turn off your amplifier before connecting or dis-

connecting cables).

7. Microphone feedback

The speakers contain powerful magnets. Do not put metal items,

such as screwdrivers, close to the speakers, as they damage to the

tweeter diaphragm.

Specification

Type: 2-way bass reflex

Impedance: 4 

Maximum input power: 80 W

Output sound pressure level: 85 dB/W/m

Frequency response: 55 Hz to 35 kHz

Crossover frequency: 3 kHz

Cabinet capacity: 7.5 

Dimensions (W × H × D): 170 × 283 × 230 mm

(incl. grille and projection)

Weight: 3.7 kg

Speakers Woofer: 12 cm OMF cone type

Tweeter: 2.5 cm Soft Dome type

Terminal: Screw-type speaker terminal

Grille: Detachable

Accessories: 1.8 meter speaker cable × 2

Cork spacer × 8

* Specifications and features are subject to change without notice.
