Sida 1/2
Reliable motion detection
with a range of up to 6 m (20ft.)
Easy installation in wall or ceiling
creating a curtain detection area
Flexible mounting height
between 2.4 - 3.6 m (8ft. to 12ft.)
Narrow curtain indoor motion detector providing reliable and
performance up to a range of 6m (20ft.). Ideal for protecting
windows, hallways, doors and a variety of other commercial
residential applications.
AP2-20N
Motion detection and smart automation
Copyright (C) 2022 OPTEX CO., LTD. No. S1551315P26220220603
OPTEX CO., LTD. (JAPAN)
www.optex.co.jp/e
OPTEX EMEA Security Headquarters
OPTEX EUROPE LTD (UK and Africa)
OPTEX Security B.V. (EU)
OPTEX Dubai Branch (Middle East)
W: www.optex-europe.com
E: marketing@optex-europe.com
OPTEX SECURITY SAS
(France, French speaking North
and West African countries)
W: www.optex-europe.com/fr
E: contact@optex-security.com
OPTEX SECURITY Sp.z.o.o.
(Eastern Europe, Turkey)
W: www.optex-europe.com/pl
E: optex@optex.com.pl
Reliable narrow beam detection with high-density detection field
Selectable sensitivity
Specifications
Dimensions
Installation Parameters
Wall mountFlexible installation Ceiling mount
Amp
Pyro electric element
Double shielding
Lens
Infrared rays
OPTEX patented double conductive shielding
allows the AP2-20N sensor to block RFI and
visible light disturbance from sunlight or
strong lamps.
Installation Height (H) 2.4m (8ft)
0.6m (2ft)
6m (20ft)
0.5m (1.5ft)
3.0m (10ft)
0.8m (2.5ft)
6m (20ft)
0.6m (2ft)
1m (3ft)
6m (20ft)
0.7m (2.5ft)
3.6m (12ft)
Max. area width
Max. area length
(20ft)
6.0m
(16ft)
4.8m
(12ft)
3.6m
(8ft)
2.4mCreep zone Creep zone
(20ft)
6.0m
(16ft)
4.8m
(12ft)
3.6m
(8ft)
2.4m
L
(4ft)
1.2m
(0.65ft)
0.20m
(0ft)
0m
W
H
3.6m (12ft)
3.0m (10ft)
2.4m (8ft )
S
H
S
WL
MODEL
Detection Method
Coverage
Mounting type
Mounting Height
Area Width
Sensitivity
Detection speed
LED Indicator
Sensitivity Adjustment
Alarm Output
Tamper Switch
Warm-up Period
Power Input
Current Draw
Weight
Operating Temperature
Environmental Humidity
RF Interference
Application Environment
*Specifications and designs are subject to change without prior notice.
Approx. 2.5 sec, N.C., 28V DC, 200mA max
AP2-20N
Passive Infrared
6m x 1m - mounting height at 3.6m (20ft x 3.3ft - mounting height at 12ft)
Wall and ceiling
2.4m - 3.6m (8ft - 12ft)
1m max - mounting height at 3.6m (3.3ft max - mounting height at 12ft)
2°C at 0.6m/s (35.6°F at 2ft/s)
0.3m - 3m/s (1ft - 10ft/s)
Switchable ON/OFF
H/L
N.C., opens when cover is removed. N.C. 28V DC, 100mA (max)
Approx. 60sec
9.5 - 16V DC
12mA (max)
Approx. 1.75oz (Approx. 50g)
-20°C - +50°C (-4°F - +122°F)
95% max
No alarm 10V/m at 80MHz - 1GHz
Indoor
3.6m (12ft)
3.0m (10ft)
2.4m (8ft )
(4ft)
1.2m
(0.65ft)
0.20m
(0ft)
0m
Detection sensitivity can be adapted
to the ambience conditions for stable
performance. LOW HIGH
SENSITIVITY
eb
ased
anual
Double conductive shielding
3635
80
57
10 7 Unit: mm
Recommended Distance Adjacent to Wall or Ceiling
