Sida 1/7



CAR

VIDEO REGISTRATOR



INSTRUCTION MANUAL

MODEL:DVR-950FHD

English

Dear customers! Thank you for purchasing ORION products. Before operation, please read this instruction manual. Save it for future reference.

2



1. CONTROLS AND CONNECTORS

1. AV-OUT 11. LCD screen

2. Blue record light 12. Menu/ SOS

3. Red charging light 13. Up

4. Reset button 14. Down

5. Microphone 15. Mode

6. Speaker 16. Power

7. Car support 17. OK

8. DC charging 18. Infrared ray night vision lamp

9. USB out 19. Lens

10. SD slot

3



2. HOW TO USE

Install and remove the memory card

1. Insert the memory card into the card slot according to the indication directions until the memory card is fixed in the card slot.

2. For taking out the memory card, press the memory slightly first and then take the card out.

3. With no card in it shows: the "No Card"

Charge

This product built-in Lithium polymer battery, please charge first time you use:

1. Connect to the computer, use the USB transmission line.

2. The original round car charger (Please use the original charger provided by our company)

Cam on and off mode switching

1. Shortly press the "switch" button, power on

2. When the power is on default video mode, press “confirm” then start to record, press "Video" button to pause and automatically save

3. If you need to switch mode, pause the camera, and press mode to switch to camera mode.

4. Pause the camera, long press the "switch" button for three seconds to shut down.

Key functions

"Switch" button (video / camera / playback mode)

Long press: Power on/off

Quick press: Sound off

OK button Video on/off

Up/Down

Mode: camera /video /recording /playback function switch

Option: Quick press: menu Long press: SOS function on (video)

Cycling video recording

Turn on the machine, enter video mode, the upper left corner shows the red recording symbol, this means recording standby state. Press the

"video" button to start recording, if no manual control the machine, the video file will be saved every two minutes automatically, when the card

is full, it will automatically delete the first file, continue recording, to finish cycling recording function (At night, the machine automatically turn to

night vision, open the infrared light to capture). Automatically recording when the car power on. Automatically saving the file and turn off in 5

seconds when the car power off. The user can set up cycle video time: 2 minutes, 5 minutes, 10 minutes
