Luminosity up to 80 Lux Usage time up to 13 hours1) Automatic mode StVZO street legal
The powerful LED technology
provides wide illumination of
up to 80 meters
Ideal for long bike rides or
commutes without having to
worry about recharging
The integrated brightness
sensor automatically adjusts
the light intensity to the
ambient light
Approved according to
German StVZO with K-Mark for
on-road use
Your light, your ride, your safety!
Discover the LEDsBIKE RACE 80 SET, the new highlight for all
cycling enthusiasts, which takes visibility and versatility to a
new level. With multiple lighting modes—automatic and
manual—and three brightness levels (100%, 50%, and 25%
brightness), the front light adapts perfectly to any
environment. It provides powerful illumination with 80 lux
and a range of up to 80 meters. The display always informs
you about the selected mode and the current light intensity.
With a battery life of up to 13 hours1), it is ideal for long
journeys or commutes without having to worry about
recharging. The tool-free 360-degree mounting allows for
quick and easy installation, making the LEDsBIKE RACE 80 SET
an ideal companion for every cyclist. The included USB-C
cable ensures convenient charging of the lithium-ion battery,
while the battery and charging indicator keep you informed of
the current status. The battery of the front and rear light can
be fully charged within 2.5 hours. The high-quality
construction, including a black ABS housing and transparent
polycarbonate lens, promises durability and reliability. It
complies with German road traffic regulations (StVZO) and has
the K-marking. With IP44 certification, it is protected against
water so that you are safe on the road even in bad weather.
OSRAM offers a 2-year guarantee on all LEDsBIKE RACE
bicycle lights2).
Product datasheet
LEDsBIKE RACE 80 SET
__
Product datasheet | LEDsBIKE RACE 80 SET June 25, 2024, 10:00:52
© 2024, OSRAM GmbH. All rights reserved. Page 1 of 3
Technical data
Product information
Application (Category and Product specific) LED Bike Lights
Electrical data
Nominal voltage 3.7 V
Photometrical data
Luminous flux 110 lm
Color temperature 5400 K
Lux Value 80
Light distance at 1lx 80 m
Light color LED Cold white
Lifespan
Guarantee 2 years
Additional product data
Type of Battery Lithium Ion
Charging Type USB-C
Setting 4 settings: eco (25%), low (50%), max (100%), auto
Usage time Up to 13 h (front light): eco (25 %): 13 hours; low (50
%): 6.5 hours; max (100 %): 3.5 hoursUp to 13 h (rear
light)
Capabilities
Technology LED
Certificates & standards
Type of protection IP44
Standards StVZO
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration 24-06-2024
Primary Article Identifier 4062172403856
Declaration No. in SCIP database In work
Product datasheet
__
Product datasheet | LEDsBIKE RACE 80 SET June 25, 2024, 10:00:52
© 2024, OSRAM GmbH. All rights reserved. Page 2 of 3
Logistical Data
Product code Product description Packaging unit
(Pieces/Unit)
Dimensions (length
x width x height)
Volume Gross weight
4062172403856 LEDsBIKE RACE 80
SET LEDBL102 SET
HFB
1
115 mm x 55 mm x
140 mm
0.89 dm³ 248.00 g
4062172403863 LEDsBIKE RACE 80
SET LEDBL102 SET
Shipping carton box
8
315 mm x 245 mm x
153 mm
11.81 dm³ 2294.00 g
The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or
more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit.
Download Data
File
User instruction
LEDsBIKE RACE 80 SET
Safety advice
For detailed application information, please refer to the product data sheet and the user instruction
Legal advice
1) Front light usage time varies depending on the brightness level: 25 %: 13 hours; 50 %: 6,5 hours; 100 %: 3.5 hours
2) For precise conditions please refer to: www.osram.com/am-guarantee
Application advice
For more detailed application information and graphics please see product datasheet.
Disclaimer
Subject to change without notice. Errors and omission excepted. Always make sure to use the most recent release.
Product datasheet
__
Product datasheet | LEDsBIKE RACE 80 SET June 25, 2024, 10:00:52
© 2024, OSRAM GmbH. All rights reserved. Page 3 of 3
