Sida 1/23
No. Model
Operating Instructions
Panduan
使用说明书
Multifunctional Steam
Sterilizer and Dryer
Pensteril dan Pengering Stim
Pelbagai fungsi
奶瓶消毒烘干一体机
Household use only
Kegunaan Rumah Sahaja
仅家庭用
Important safety instructions
Read carefully and keep for future reference
Panduan keselamatan penting
Baca dengan teliti dan simpan untuk rujukan masa depan
请仔细阅读本说明书并妥善保管
Model No.
型号 NU-MX100P
English
1. Introduction
This product kills harmful bacteria with high-temperature
steam and helps you to sterilize various kinds of baby feeding
supplies safely and quickly.
This product can hold 6 baby bottles of any brand and
any size, or even supersized baby bottles. Besides, it can
also accommodate other baby feeding products, such as
complementary food bowls, cups and spoons. This product has
multiple functions: warming milk, reheating foods, steaming
eggs, and sterilizing/drying baby bottles and utensils.
2. Feature Diagram
Lid Clamp
Body
Power Supply Cord
Measuring Cup (150 ml)
Base
Identification
Plate
Scale 1 2 3 4
Water 25 ml 55 ml 80 ml 110 ml
*The above illustrations are for reference only.
3. Specifications
Model Number: NU-MX100P
Power Source: 220 - 240 V ~ 50 - 60 Hz
Input power Steriliser: 550 W
Input power Dryer: 170 W
Outside dimensions (H x W x D): 373 mm x 304 mm x 232 mm
Weight (approx.): 2.5 k g
*Specifications subject to change without notice.
For the batch number (model number) and manufacturer,
refer to the identification plate of the product.
Eng-1
Eng-2
4. Usage
●Control Panel
Power Pad
(On/Off) Reheating/
Steam Pad Sterilizing/
Drying Pad Drying Pad
Warm-milk
Pad
Time-Increase
Pad Time-Decrease
Pad
Display
Window Sterilizing
Pad
●Follow as below steps before first using:
(1) Measure 90 ml water with the measuring cup (maximum
200 ml) and pour it into the water storage tank of the base.
(2) Place the body on the base and cover it with the lid.
(3) Insert the power supply cord, turn on the power supply,
press the Power Pad “ ” to activate the product.
(4) Press the Sterilizing Pad “ ” to start the sterilization mode.
(5) The product starts to generate steam when the water
temperature reaches 100 , and automatically shuts ℃
down when the water is completely boiled away.
(6) After sterilizing, allow to cool for 3 minutes, and then
disconnect the power and unplug.
(7) Remove the lid and the body, pour out the remaining
water in the water storage tank of the base, and dry the
product for normal use next time.
Milk Warming Function
(1) Measure 90 ml water with the measuring cup (maximum
200 ml) and pour it into the water storage tank of the base.
(2) Place the body on the base, put the container (baby
bottle, cup or bowl) with milk and water on a stable
place in the body, and then cover it with the lid.
(3) Turn on the power supply, press the Power Pad “ ”.
(4) Press the Warm-milk Pad “ ” , and then press the Pads
“ ” and “ ” to select the desired time of 3-15 minutes.
*The default setting to milk warming is 6 minutes.
(5) If there is no further operation in 3 seconds, it will enter
working state after a “Beep” sound.
(6) The product heats the water in the water storage tank
quickly to turn it into steam for heating. The product will
beep 3 times and the indicator will flash after the program.
Referential Time Chart for Warming Milk*
Water volume Milk volume Time for 5 ℃
cold milk
Time for 20 milk at ℃
room temperature
90 ml
60-120 ml 3 minutes 3 minutes
120-180 ml 5 minutes 3 minutes
180-270 ml 6 minutes 4 minutes
>270ml 7 minutes 5 minutes
