Sida 1/6
O w n e r’s G u i d e
Z p h o n o P h o n o P r e a m p l i f i e r
Zphono Phono Preamplifier
IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert the user to
the presence of “dangerous voltage” inside the product that may constitute a risk of electric shock. The
exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance instructions in the literature accompanying the product.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
1. Read Instructions — Read all the safety and operating instructions before operating this product.
2. Retain Instructions — Retain safety and operating instructions for future reference.
3. Heed Warnings — Adhere to all warnings on the product and in the operating instructions.
4. Follow Instructions — Follow all operating and use instructions.
5. Cleaning — Unplug this product from the wall outlet before cleaning. Use a damp cloth for cleaning.
Clean the outside of the product only.
6. Attachments — Do not use attachments that are not recommended by the product manufacturer;
they may be hazardous.
7. Water and Moisture — Do not use this product near water.
8. Accessories — Do not place this product on an unstable cart or stand. The product may fall causing
bodily injury and damage to the product. A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the product and cart to overturn.
9. Ventilation — Slots and openings in the cabinet are provided for ventilation to ensure reliable opera-
tion of the product and to protect it from overheating. These openings must not be blocked or cov-
ered. This product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided.
10. Power Sources — Operate this product only from the type of power source indicated on the label.
If you are not sure of the type of power supply to your home, consult your dealer or local power
company. This product is equipped with a three-prong grounding plug. This plug will only fit into
a grounding power outlet. If you are unable to insert the plug into the outlet, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the grounding plug.
11. Power Cord Protection — Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them.
12. Lightning — Unplug the unit from the wall outlet for added protection during a lightning storm
and when it is left unattended and unused for long periods of time. This will prevent damage to the
product due to lightning and power line surges.
13. Overloading — Do not overload wall outlets or extension cords. This can result in a fire or electric shock.
14. Inserting Objects into Unit — Never push objects of any kind into this product through any openings;
they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
15. Servicing — Do not attempt to repair or service this product yourself. Opening or removing covers may
expose you to dangerous voltage and other hazards. Refer all servicing to qualified service personnel.
16. Damage Requiring Service — Unplug this product from the wall outlet and refer servicing to quali-
fied service personnel under the following conditions: If the power-supply cord or plug is damaged.a)
b) If liquid has been spilled into the product. c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating instructions. e) If the product
has been dropped or damaged in any way. If the product exhibits a distinct change in performance.f)
17. Replacement Parts — When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer. Unauthorized substitutions may result in fire, electric
shock, and other hazards.
19. Safety Check — Upon completion of any service or repairs to this product, ask the service technician
to perform safety checks to determine that the product is in proper operating condition.
20. Wall or Ceiling Mounting — Mount the product to a wall or ceiling only as recommended.
21. Heat — The product should be situated away from heat sources such as radiators, heat registers.
stoves, and other products (including amplifiers) that produce heat.
www.parasound.com
Thank You for Choosing Parasound
Congratulations on your purchase of this precision component and thank you for your selection of
Parasound. Please take a few moments to review this manual so you may enjoy all the benefits of your
new Zphono’s unique features.
Please inspect the unit now and contact your Parasound Dealer promptly if you see evidence of shipping
damage. Save the carton and packing inserts in case you move or in the event you need to ship your
amplifier for repair. Before you proceed, locate the serial number on the rear panel or underside of the unit
and record it here for future reference:
Serial # ________________________________________________________________________________________
Purchase Date __________________________________________________________________________________
Parasound Dealer ______________________________________________________________________________
Phone Number ________________________________________________________________________________
115v - 230v AC Voltage Selector Switch
This switch is found on the chassis bottom. Make sure the 115/230V switch is set for the correct AC line
(mains) voltage before you connect the Zphono’s power cord and before you install it. The unit may be seri-
ously damaged if this switch is set incorrectly.
Installation and Ventilation Requirements
The Zphono generates virtually no heat and does not require special ventilation. Since it has no front
panel controls it may be located near your other audio/video components, or hidden out of sight. Locate
the Zphono at least a few feet away from amplifiers or receivers. Sometimes their power transformer
radiate energy that will cause the Zphono to add a background “hum” that is audible at your speakers.
The AC power cords of other components (and the Zphono’s own AC cord) can also induce hum into the
audio input and output cables. Try to keep audio cables as far as possible from AC power cords. Try to
avoid running audio cables and AC cords parallel to each other. Audio cables should cross AC cords at
a 90 degree angle so they’re perpendicular.
Rack Mounting
The Zphono occupies only half the width of a single rack space in a standard 19" equipment rack. For rack
mounting, you can fasten it to another Parasound Z series model by using the Parasound SBS (Side-by-
Side) mounting kit. You can also mount a single Zphono in the rack with the accessory Zblank panel. The
SBS includes four rack mount bolts plus four pairs of plastic “shoulder washers.” The washers are impor-
tant because they insulate the Zphono front panel (and chassis) from the metal equipment rack and from
the four mounting bolts. Locate these washers on both sides of the front panel before the mounting bolts
are screwed into the rack rail.
230
AC Voltage Selector Switch.
Shown set for 230v.
