Professional Laminator PL900
3T Supplies AG Peach Division
Chaltenbodenstrasse 6D
CH-8864 Schindellegi
e-mail: info@peach.info
web: www.peach.info
English
LAMINATING OPERATION:
Turn on the Power switch, and
press the On/Off button.
Select the job by pressing the
correct button:
DOCUMENT/PHOTO/COLD
button.
When READY light turns green
and you hear the beeping
sound, the machine is ready
to start laminating.
Place the pouch
(proper document inside) into
the Pouch entry tray sealed
edge first.
Remove finished lamination
from the Pouch exit tray at the
back of the machine.
In case of pouch jam, press
the REVERSE button. Pull out
the jammed pouch from the
Pouch exit tray. Alternatively
the machine will find out the
jam itself and reverse by itself.
Turn off the machine - Press
the On/Off button and turn off
the Power switch.
Connect your device with USB
power charger. The machine
can support both Android and
IOS system.
Follow the correct document/pouch insert direction.
Only run a lamination job within the Border mark.
Only run a lamination job when READY light turns green.
Make sure there is enough clear space (min. 500mm) behind the machine.
POUCH JAM
Run a plain paper board (about 180gsm-250gsm) trough the machine to clean rollers.
Leave the machine stand-by for 30 minutes and it will shut off by itself.
Let the machine fully cool down before you put it away.
Long life tips
* This may vary depending on the total pouch & paper thickness
Specifications/Technical Data
5.1 kg
Auto shut off time
Power
USB power charger
Dimensions
Net weight
75mic-250mic
up to 1000mm per min.
335mm (up to A3)
Yes
60 seconds
30 minutes
220-240V/50-60H, 1200W
DC 5V 1.5A
520 x 175 x 160mm
Laminating pouch thickness
*Laminating speed (80mic)
Max. laminating width
Pouch jam recovery
Warm-up time
Place machine on a stable surface
DO NOT use the lamninator if its power cord is damaged.
Ensure no lamination runs with metal objects like staples, paper clips.
DO NOT attempt to open or otherwise repair the machine.
Keep the machine including its power cord away from heat and water sources.
DO NOT allow children to use this machine.
Turn off the machine after each use.
Unplug the machine when not in use for an extended period.
DO NOT laminate an empty pouch.
Use pouches required for the appropriate pouch setting.
Follow the instructions and specifications shown on the machine as well.
Leave the Pouch exit tray clear of any objects.
General Safeguards
Pouch exit tray
Pouch entry tray
READY light
Border mark
Power cord Power switch
POWER light
USB power charger
REVERSE button
On/Off button
PHOTO button
Taste PHOTO
COLD button
