Sida 1/16
Atlas andESR ESR
+
Capacitance and Equivalent Series Resistance Meter
Model ESR60/ESR70
Designed and manufactured with pride in the UK
User Guide
©
Peak Electronic Design Limited 2004/2012
In the interests of development, information in this guide is subject to change without notice - E&OE
GB60/70-8
ESR60/ESR70 User Guide April 2012 – Rev 8
Page 2
Want to use it now?
We understand that you want to use your right Atlas ESR
now. The unit is ready to go and you should have little need
to refer to this user guide, but please make sure that you do
at least take a look at the notices on page 4!
Contents Page
Introduction......................................................................... 3
Safety Considerations.......................................................... 4
Notes on ESR ...................................................................... 5
Analysing capacitors ........................................................6-8
Typical values of ESR......................................................... 9
Audible Alerts ................................................................... 10
Probe Compensation ......................................................... 11
Care of your ..................................................... 12 Atlas ESR
Appendix A – Troubleshooting......................................... 13
Appendix B – Technical Specifications ............................ 14
Appendix C – Warranty Information ................................ 15
Appendix D – Disposal Information ................................. 16
ESR60/ESR70 User Guide April 2012 – Rev 8
Page 3
Introduction
The is an advanced instrument designed specifically Atlas ESR
for the analysis of capacitor equivalent series resistance (in or
out of circuit). In addition it will, where possible, display the
capacitance of the device under test.
Summary Features:
• ESR measurement range 0 to 20 (40 for ESR70). Ω Ω
• ESR resolution as low as 0.01 . Ω
• Capacitance range 1µF to 22,000µF.
• Can be used for low-ohms resistance checking too.
• Integrated controlled discharge circuitry reduces the need
for the user to manually discharge capacitors before test.*
• Use in or out of circuit for ESR and low-ohms resistance
measurement.
• The ESR70 features audible alerts for quick user-feedback
of ESR test status.
• Automatic analysis start when component is detected.
• Automatic and manual power-off.
* Note:
The discharge circuitry exists to ensure that a charged capacitor
is less likely to damage the unit. For example, if the capacitor
under test has a potential of a few tens of volts across it, the
charge is removed automatically. It is the user’s responsibility
to ensure that any dangerously charged capacitors are safely
discharged before connection to the unit.
