Peavey AT-200 Bruksanvisning

Peavey Gitarr AT-200

Läs nedan 📖 manual på svenska för Peavey AT-200 (1 sidor) i kategorin Gitarr. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/1

This quick start guide is designed to get you playing right away.

1. Install four fresh AA cells in the battery compartment (1) on the rear of the guitar. For maximum battery life, use

lithium ion batteries, or good alkaline batteries.

Battery Cautions:

Take great care not to install the batteries backwards.

Do not mix used and new batteries.

Do not mix battery type.

Do not expose device to water.

Remove batteries when device is not used for long periods of time to avoid damage caused by battery leakage.

2. Plug a 1/4” cable into the guitar (2) and into your amplier.

3. Adequate string tension is necessary in order for the String Tune function to work properly. Strings that are too

loose (more than ve half steps) will not sense properly.

4. To turn on the Auto-Tune for Guitar system, you must have a plug inserted in the output jack, and the push/

pull switch that is part of the Tone knob (3) must be in the “down” position. The LED (5) on the side of the neck

pickup bezel will light steadily to indicate that the system has power.

5. Strum all the strings evenly, then push down on the volume knob (4). You should hear a “tuning” sound, which

indicates that the AT-200 has been tuned!

Peavey® AT-200™ Quick Start Guide

JACK PLATE

1/4" output

Make sure the guitar is plugged in

TONE CONTROL

Pot down: Turns on the Antares system.

VOLUME/AUTO-TUNE CONTROL

Strum all six strings evenly and push down on the

volume knob to engage tuning.

LED INDICATOR

BATTERY BOX ON BACK OF GUITAR

Install four AA batteries

Features and specifications are subject to change without notice.

Solid-Tune™ is a trademark and Antares
