C761M-A (4/08)
13VDIR Series Day/Night Lenses
Important Safety Instructions
WARNINGS: Prior to installation and use of this product, the following items should be observed.
• Servicing should be done only by qualified service personnel.
• Only use replacement parts recommended by Pelco.
Please thoroughly familiarize yourself with the information in this manual prior to installation and operation.
Description
The purpose of these lenses is to compensate for the focus shift that results from the different wavelengths of visible and IR light. IR corrected lenses focus
light energy on the same plane. The result is better focus, sharper contrast, and better overall image quality.
IR corrected lenses are particularly of benefit to Pelco’s day/night cameras, which “see” both visible and IR light. IR corrected lenses allow a camera’s
imager to take in visible and IR illumination in “night” conditions (when the IR cut filter is not deployed), while eliminating the problem of IR focus shift.
The 13VDIR Series lenses are appropriate for indoor and outdoor lighting situations. The lenses will fit all 1/3-inch CS mount cameras requiring DC drive
auto iris lenses. Lenses in the 13VDIR Series come with a standard square 4-pin plug installed for ease of installation and convenience.
Lenses in this series are available in 2.8X 7X (13VDIR7.5-50) zoom with varying focal (13VDIR3-8.8), 3.9X (13VDIR2.8-11), and 6. lengths.
Maximum and minimum apertures for these lenses are: 1.4-2.6 (13VDIR2.8-11), 1.0-1.6 (13VDIR3-8.5), and 1.3-1.8 (13VDIR7.5-50). This allows for excellent
performance characteristics across a wide range of lighting conditions. These lenses have aspheric elements, which provide crisper, optimized images at all
focal lengths.
MODELS
13VDIR2.8-11 2.8 to 11 mm varifocal lens with direct drive auto iris, manual focus, and manual zoom
13VDIR3-8.5 3 to 8.5 mm varifocal length lens with direct drive auto iris, manual focus, and manual zoom
13VDIR7.5-50 7.5 to 50 mm varifocal length lens with direct drive auto iris, manual focus, and manual zoom
Installation
1. Remove the dust cover from the lens. Remove any dust with a soft brush or clean compressed air.
2. Install the lens by carefully threading it clockwise on the mount of the camera until fully seated. If the lens has a coupling ring, tighten it against the
camera. Use a C/CS mount adapter if attaching a C-type lens to a CS-type camera. The PMCA40 adapter is available from Pelco.
3. Plug the electrical connector directly into the camera’s DC drive.
4. Follow the camera operating instructions for iris and focus adjustments.
Worldwide Headquarters • 3500 Pelco Way • Clovis, California 93612 USA • www.pelco.com
USA & Canada • Tel: 800/289-9100 • Fax: 800/289-9150
International • Tel: 1-559/292-1981 • Fax: 1-559/348-1120
Routine Servicing
Never touch the surface of the lens.
Remove dust from the lens using a soft brush or clean compressed air. Avoid touching the lens surface during handling.
To remove fingerprints or oil stains from the lens surface, use lens cleaning paper or a clean cotton cloth with a little cleaning liquid. Then, wipe off the
stains using a light circular motion, starting from the center of the lens surface. Wipe the lens body with a silicon cloth. Do not use any organic solvents such
as thinner or benzene.
Lens and Connector Wiring Diagrams
Specifications
13VDIR2.8-11 13VDIR3-8.5 13VDIR7.5-50
Type Varifocal Infrared Varifocal Infrared Varifocal Infrared
Format Size 1/3-inch 1/3-inch 1/3-inch
Mount Type CS CS CS
Focal Length 2.8~11mm 3~8.5 mm 7.5~50 mm
Zoom Ratio 3.9X 2.8X 6.7X
Relative Aperture (F) 1.4~2.6 1.0~1.6 1.3~1.8
Operation
Iris Auto (Direct Drive) Auto (Direct Drive) Auto (Direct Drive)
Focus Manual Manual Manual
Zoom Manual Manual Manual
Angle of View
Diagonal 32.7°~123.2° 41.9°~114.1° 7.00°~46.2°
Horizontal 26.2°~97.4° 33.6°~90.5° 5.64°~36.6°
Vertical 19.7°~72.4° 25.2°~67.2° 4.26°~27.4°
Minimum Object Distance 0.3 m 0.2 m 0.4 m
Back Focal Length 8.66~18.69 mm 7.94~13.96 mm 9.61~11.96 mm
Operating Temperature -4° to 140°F 14° to 122°F 14° to 122°F
(-20° to 60°C) (-10° to 50°C) (-10° to 50°C)
Unit Weight 0.18 lb (0.08 kg) 0.12 lb (0.05 kg) 0.15 lb (0.07 kg)
Shipping Weight 1 lb (0.45 kg) 1 lb (0.45 kg) 1 lb (0.45 kg)
(Design and product specifications subject to change without notice.)
REVISION HISTORY
Manual # Date Comments
C761M 11/06 Original version.
C761M-A 4/08 Added 13VDIR2.8-11 lens and specifications for all the lenses.
Pelco, the Pelco logo, and B.O.S.S. are registered trademarks of Pelco, Inc. ©Copyright 2008, Pelco, Inc. All rights reserved.
The materials used in the manufacture of this document and its components are compliant to the requirements of Directive 2002/95/EC.
This equipment contains electrical or electronic components that must be recycled properly to comply with Directive 2002/96/EC of the European Union
regarding the disposal of waste electrical and electronic equipment (WEEE). Contact your local dealer for procedures for recycling this equipment.
Pelco VDIR Type Lenses
RED
BLACK
YELLOW GIRIS
4 -CONDUCTOR
CABLE
4-PIN SQUARE CONNECTOR
3
4
2
TO CAMERA AUTO IRIS SOCKET, DC DRIVE
AUTO IRIS PLUG PIN-OUT
(REAR OF PLUG, SOLDER LUGS)
4 2
3 1
1
DRIVE ( + )
DRIVE ( – )
CONTROL ( – )
CONTROL ( + )
GREEN
