Sida 1/4
20" OSCILLATING
HIGH VELOCITY PEDESTAL FAN
MODEL 1PAFP20
OWNER’S MANUAL
2
RULES FOR SAFE OPERATION
READ AND SAVE THESE INSTRUCTIONS
CAUTION Read and follow all instructions
before operating fan.
Do not use fan if any part is damaged or missing.
WARNING
• Toreducetheriskofreorelectricalshock,
do not expose to water or rain.
• Toreducetheriskofreorelectricalshock,
do not use this fan with any solid state speed
control device.
• Automatically operated device - To reduce
theriskofinjury,disconnectfrompowersupply
before servicing.
• Ifthepowersupplycordisdamaged,contact
yourlocalservicecenteroraqualied
electrician to install an appropriate replacement
cord to prevent any injury or damage.
• The appliance does not apply to be used in
locationswherespecialconditionsprevail,such
as the presence of a corrosive or explosive
atmosphere(dust,vapororgas).
• This appliance is not intended for use by
persons(includingchildren)withreduced
physical,sensoryormentalcapabilities,or
lackofexperienceandknowledge,unlessthey
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
RULES FOR SAFE OPERATION:
1 Neverinsertngersoranyotherobjects
through the grill guard when fan is in operation.
2 Disconnect the fan from its power source
when moving from one location to another.
3 Disconnect the fan from its power source
when removing guards for cleaning.
4 Besurefanisonastable,atsurface
when in operation.
5 Do not use fan in windows. Rain and moisture
may create electrical hazard.
6 Close supervision is necessary when this fan
isusednearchildren,theelderlyandpets.
7 Donotplacethefannearanopename,
cookingorheatingappliance,orhotsurface.
8 This fan should not be operated outside.
CAUTION Do not alter the fan’s assembly.
WARNING Be sure that both front and rear
guard screws are completely tightened in locking
position before operation.
IMPORTANT NOTE:
Read the manual carefully. Make sure to save this manual for future reference. Illustrations in this
manualareforexplanatorypurposesonly,youractualproductmaylookslightlydierent.
CLEANING
WARNING
Unplug from electrical supply source
before cleaning.
1 Use soft damp cloth then wipe
with dry cloth.
2 Do not use harmful cleaners to
paints or plastics.
3 Do not bend the blades.
Machine will need more frequent cleaning
if being used in an environment with high
particle pollution.
RATING:
120V~60Hz,1.25A,150W
3
ASSEMBLY, OPERATING & CLEANING INSTRUCTIONS
8
1
4
5
6
7
8
9
2
73
FAN ASSEMBLY INSTRUCTIONS
1 Remove the L screw and washer
from the bottom of the outer tube.
2 Slide the cover ring onto
thebottomoftheoutertube,
per the assembly diagram.
3 Attach the outer tube
assembly and the base
together by reinserting
then tightening the L
screw and washer.
4 Loosen the inner tube
by twisting the height
adapter and slide the
inner tube up to reveal
the dimpled area needed
to secure the set knob.
5 Slide the motor assembly onto
the innertube so the dimple and
set knob are aligned.
6 Tighten the set knob the secure the
motor assembly to the inner tube.
7 Slide the rear guard onto the shaft
the of the motor and secure with
the predrilled bolts on the front of
the motor. Be sure the small hole
for the grill screw is positioned on
the bottom of the rear guard before
securing it to the motor.
8 Slidethefanbladeontotheshaft,
the set screw needs to be facing
inwardandtightenedontotheat
indent of the shaft. Tighten the set screw with philips screwdriver.
Please be vigilant that the fan blade is secured correctly
and tightly to prevent safety hazards and operational failure.
9 Connectthefrontguardandrearguard,fastentheclipsrunning
along the border of the front guard to secure them together.
10 Install the screw grille to secure the front and back guards together.
Grill Screw
Height
Adapter
