Philips MG7715 Bruksanvisning
Philips
Skäggtrimmer
MG7715
Läs nedan 📖 manual på svenska för Philips MG7715 (39 sidor) i kategorin Skäggtrimmer. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/39
© 2018 Koninklijke Philips N.V.
All rights reserved
8888.989.2535.1 (22/2/2018)
MG7730
MG7720
MG77 1 5
MG77 1 0
>75% recycled paper
>75% papier recyclé
English
Introduction
Congratulations on your purchase and welcome to Philips! To fully benefit
from the support that Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Full-size hair trimmer
2 On/off button
3 Battery status indicator
4 Socket for small plug
5 Body shaver (MG7730, MG7720, MG7715 only)
6 Skin protector (MG7730, MG7720, MG7715 only)
7 Precision trimmer (MG7730, MG7720, MG7715, MG7710 only)
8 Precision shaver (MG7730, MG7720, MG7710 only)
9 Nose trimmer
10 Extra-wide hair trimmer (MG7730 only)
11 Hair comb regular 3/8in. (9mm) (MG7720, MG7715, MG7710 only)
12 Hair comb regular 15/32in. (12mm) (MG7720, MG7715, MG7710 only)
13 Hair comb regular 21/32in. (16mm) (MG7720, MG7715, MG7710 only)
14 Hair comb wide 5/32in. (4mm) (MG7730 only)
15 Hair comb wide 3/8in. (9mm) (MG7730 only)
16 Hair comb wide 15/32in. (12mm) (MG7730 only)
17 Hair comb wide 21/32in. (16mm) (MG7730 only)
18 Body comb 1/8in. (3mm)
19 Body comb 3/16in. (5mm)
20 Stubble comb 3/64in. (1mm)
21 Stubble comb 5/64in. (2mm)
22 Adjustable comb (3-7mm)
23 Supply unit
24 Small plug
25 Cleaning brush
26 Pouch
Note: The accessories supplied may vary for different products. The box
shows the accessories that have been supplied with your appliance.
Important safety information
Read this important information carefully before you use the appliance and
its accessories and save it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable supply unit (HQ8505)
provided with the appliance.
- The supply unit contains a transformer. Do not cut off the supply unit to
replace it with another plug, as this causes a hazardous situation.
- This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
- Always unplug the appliance before you clean it under the tap.
- Always check the appliance before you use it. Do not use the appliance
if it is damaged, as this may cause injury. Always replace a damaged part
with one of the original type.
- Do not open the appliance to replace the rechargeable battery.
Caution
- Never immerse the charging stand in water and do not rinse it under the
tap.
- Do not use the supply unit in or near wall sockets that contain an electric
air freshener to prevent irreparable damage to the supply unit.
- Only use this appliance for its intended purpose as shown in the user
manual.
- For hygienic reasons, the appliance should only be used by one person.
- Never use water hotter than 60°C to rinse the appliance.
- Never use compressed air, scouring pads, abrasive cleaning agents or
aggressive liquids such as petrol or acetone to clean the appliance.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
General
- This appliance is waterproof. It is suitable for use in the bath or shower
and for cleaning under the tap. For safety reasons, the appliance can
therefore only be used without cord.
- The supply unit is suitable for mains voltages ranging from 100 to 240
volts.
- The supply unit transforms 100-240 volts to a safe low voltage of less
than 24 volts.
Charging
Battery status indications
- When the battery is almost empty, the battery status indicator flashes
orange.
- When the appliance is charging, the battery status indicator flashes
white slowly.
- During quick charge, the battery status indicator flashes white. After
approx. 5 minutes of charging, the appliance contains enough power for
one cordless trimming session.
MG77 1 5
MG7720
MG7730
MG77 1 0
MG772 0
MG773 0
MG7710
MG7715
MG7720
MG7730
MG7710 / MG7715 / MG7720
MG77 1 0
MG77 1 5
MG772 0
MG773 0
3-7 mm
1 mm 2 mm
5 mm
3 mm
MG7730 12 mm 16 mm4 mm 9 mm
12 mm 16 mm9 mm
1
2
3
10
7 8 9
5
6
4
13
1918
16 171514
21 2220
23
24
26
25
1211
1
- When the battery is fully charged, the battery status indicator lights up
white continuously.
Note: After approx. 30 minutes, the light goes out automatically.
Charging
Charge the appliance before you use it for the first time and when the
display indicates that the battery is almost empty. When the appliance has
charged for 1 hours, it has a cordless operating time of up to 2 hours.
1 Make sure the appliance is switched off.
2
1
2 Insert the small plug into the appliance and put the supply unit in the
wall socket.
3 After charging, remove the supply unit from the wall outlet and pull the
small plug out of the appliance.
Quick charge
After approx. 5 minutes charging, the appliance contains enough power for
one cordless trimming session.
Using the appliance
Note: This appliance can only be used without cord.
Note: Switch off and clean the appliance after each use.
Detaching and attaching cutting elements
1 To detach a cutting element, push upwards against the teeth of the
cutting element and take it off the handle.
1
2
2 To attach a cutting element, insert the lug of the cutting element into the
guiding slot at the front and push the back of the cutting element onto
the appliance ('click').
Detaching the precision shaver and nose trimmer
1 Place your finger on the arrow at the back of the attachment and push it
off the handle in the direction of the arrow.
Attaching and detaching combs
1
2
1 To attach any type of guard onto a cutting element, slide the front part
of the guard onto the teeth of the cutting element. Then push down the
center of the guard with your fingers or the palm of your hand ('click').
2 To detach any type of comb from the cutting element, carefully pull its
back part off the appliance and then slide it off the cutting element.
Note: When trimming for the first time, start by using the comb with the
maximum trimming length setting to familiarize yourself with the
appliance.
Switching the appliance on and off
Press the on/off button once to turn the appliance on or off.
Attachments for use on beard
Full-size hair trimmer
Use the full-size hair trimmer without a comb to trim hair close to the skin
(to a length of 1/32in (0.5mm) or to create clean lines around your beard,
neck and sideburns.
1 To trim hair close to the skin, place the flat side of the cutting element
against your skin and make strokes against the direction of hair growth.
2 For contouring, hold the cutting element perpendicular to the skin and
move it upwards or downwards with gentle pressure.
Beard combs
Attach a beard comb to the full-size hair trimmer to trim your beard and
moustache evenly. The appliance comes with 5 beard combs. The hair
length settings are indicated on the combs. The settings correspond to the
remaining hair length after trimming.
Comb inch mm
Stubble comb 3/64in. 1mm
Stubble comb 5/64in. 2mm
Adjustable beard comb 1/8in.- 9/32in. 3mm-7mm
1 Attach the comb to the full-size hair trimmer.
= mm
2 Adjustable comb: Push the length selector to the left or right to select
the desired hair length setting.
3 To trim the most effective way, move the comb against the direction of
hair growth. Make sure the surface of the comb always stays in contact
with the skin.
Attachments for use on body
- Use the green body combs to trim body hair.
- When you trim for the first time, use the 5mm/3/16in. body comb to
familiarize yourself with the appliance.
- Make sure hair is clean and dry as wet hair tends to stick to the body.
- When trimming sensitive areas, always use a body comb.
- Since all hairs do not grow in the same direction, you may want to try
different trimming positions (i.e. upwards, downwards, or across).
Practice is best for optimum results.
- Always make smooth and gentle movements and be sure the surface of
the comb always stays in contact with your skin.
- When too many hairs have accumulated on the appliance, blow the hairs
out before use, for best trimming results.
Body combs
Attach a body comb to the full-size hair trimmer to trim hairs below the
neckline. The appliance comes with 2 body combs. The hair length settings
are indicated on the combs. The settings correspond to the remaining hair
length after trimming.
Comb inch mm
Body comb (green) 1/8in. 3mm
Body comb (green) 3/16in. 5mm
1 Attach a body comb to the full-size hair trimmer.
Produktspecifikationer
| Varumärke: | Philips |
| Kategori: | Skäggtrimmer |
| Modell: | MG7715 |
