Sida 1/8

Subwoofer Manual

Features

Models: MX12D2, MX12D4

MX10D2, MX10D4

• 11mm of Linear Excursion

• Dual 2 Ohm or 4 Ohm Voice Coil models

• 12” or 10” versions

• High Excursion CAE/CAD Motor Design

• KlaraForm Vented Kapton Former technology

reduces distortion by reducing heat and resistance

• Glass Fiber Reinforced Cone for Increased Low End

• Phoeniroll Surround Technology promotes

linear motion

• Torriform Voice Coil Technology:

Effectively dissipates heat and minimizes distortion

• Nickel Plated 12 Gauge Speaker Terminal

• Optimized for Sealed Enclosures

• Powder Coated Anti-Resonant Steel Basket

Subwoofer Owner’s Manual

Enclosure Recommendations

SEALED MX10D2 MX10D4

MX12D2

MX12D4

Rock / Punchy Bass (cu. Ft.) 0.5 0.5 0.5 0.5

Neutral / Good All Around 0.75 0.75 0.75 0.75

Hip Hop / Low Bass / (cu. Ft.) 1.0 1.0 1.0 1.0

Enclosure recommendations already include driver and / or port displacement.

Specications

T/S Parameter MX10D2 MX10D4 MX12D2 MX12D4

Impedance (Ohm) Dual 2 Ohm Dual 4 Ohm Dual 2 Ohm Dual 4 Ohm

Znom (Ohm) 2.0 x 2 3.6 x 2 2.0 x 2 3.6 x 2

Revc (Ohm) 1 1.8 1 1.8

FS (Hz) 50.9 51.6 38 40.7

Sd (SqM) 0.034 0.034 0.051 0.051

BL (TM) 6.02 7.9 5.96 8.24

Qms 4.105 3.27 3.514 3.3

Qes 1.085 1.09 1.049 1.217

Qts 0.858 0.819 0.808 0.889

Vas (L) 13.54 15.23 41.68 35.097

Cms (uM/N) 79.45 81.37 112.5 94.76

Mms (gms) 123.228 116.8 155.88 161.46

SPL (dB) 84 85 85 85

Voice Coil Diameter 2in - 50mm 2in - 50mm 2in - 50mm 2in - 50mm

RMS Power Handling 300 watts 300 watts 300 watts 300 watts

PEAK Power Handling 600 watts 600 watts 600 watts 600 watts

Xmax (Linear) 11mm 11mm 11mm 11mm

Driver Displacement (cf) 0.037 0.037 0.040 0.040

Overall Diameter 12.5in - 318mm 12.5in - 318mm10.35in - 263mm 10.35in - 263mm

Mounting Diameter 9.25in - 234mm 9.25in - 234mm 11.10in - 282mm 11.10in - 282mm

Mounting Depth 3.63in - 92mm

3.63 in - 92mm

4.10in - 104mm 4.10in / 104mm

Subwoofer Owner’s Manual

Enclosure Examples

Sealed Enclosure / 0.5cu.ft

Sealed Enclosure / 0.75cu.ft

Sealed Enclosure / 1.0cu.ft

External Dimensions

A = 13 in

B = 21.35 in

C = 5.5 in

External Dimensions

A = 13 in

B = 31.55 in

C = 5.5 in

External Dimensions

A = 13 in

B = 40.14 in

C = 5.5 in

MX10

Qtc = 0.825

F3 = 59.9 Hz

MX10

Qtc = 0.779

F3 = 57.79 Hz

MX10

Qtc = 0.753

F3 = 56.85 Hz

MX12

Qtc = 0.991

F3 = 55.77 Hz

MX12

Qtc = 0.905

F3 = 51.06 Hz

MX12

Qtc = 0.852

F3 = 48.65 Hz

Detail Size Quantity

Top/Bottom 5.5” x 21.35” 2

Front/Rear 11.5” x 19.85” 2

Left/Right 5.5” x 11.5” 2

Detail Size Quantity

Top/Bottom 5.5” x 31.55” 2

Front/Rear 11.5” x 30.05” 2

Left/Right 5.5” x 11.5” 2

Detail Size Quantity

Top/Bottom 5.5” x 40.14” 2

Front/Rear 11.5” x 38.64” 2

Left/Right 5.5” x 11.5” 2

Vb = 0.5 cu.ft

V(total) = 0.53 cu.ft

Vb = 0.75 cu.ft

V(total) = 0.80 cu.ft

Vb = 1.0 cu.ft

V(total) = 1.035 cu.ft

CUBIC FEET

0.5

0.75

1.0

Material Thickness: 0.75 in
