Sida 1/12
Amplifier Manual
Manuel de l’amplificateur
Features: Caractéristiques:
Models: SD300.1, SD600.1, SD500.4, SD800.5
© 2011 Phoenix Gold • www.phoenixgold.com
• High Eciency Class D Topology
• Compact Size for Easy Installation
• High and Low Pass Crossovers
• Robust Unregulated Power Supply
• Surface Mount Component Technology
• Power Supply Filtering eliminates AM/FM interference
• Panel Mounted RCAs
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verication
• High Temperature Plexiglass cover
• Remote subwoofer level control included (SD300.1/SD600.1/SD800.5 Only)
• Topologie de classe D de gamme complète
• Petit format pour faciliter l’installation
• Filtres croisés passe-haut et passe-bas
• Alimentation électrique robuste non réglementée
• Technologie de composant monté en surface
• Filtrage de l’alimentation électrique qui élimine l’interférence AM/FM
• Amplicateurs à couplage RC montés sur des panneaux
• Terminaux d’alimentation et de haut-parleurs à insertion directe
• Vérication du contrôle de la qualité de la précision audio
• Couvercle de plexiglas résistant aux températures élevées
• Niveau de contrôle de passe-bas inclus (SD300.1/SD600.1/SD800.5)
Amplier Owner’s Manual
© 2011 Phoenix Gold • www.phoenixgold.com
SD300.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 18dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohm
Typical Eciency: 70%
Damping Factor: Greater than 200
SD500.4 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High and Low Pass Crossovers: 12dB per Octave
Crossover Range: 40Hz to 400Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohm Bridged or 2 ohm Stereo
Typical Eciency: 70%
Damping Factor Greater than 200
RMS Power 14.4Vdc ≤ 1% THD 200 x 1 @ 4 ohm
300 x 1 @ 2 ohm
Dynamic Power 14.4Vdc >1% THD 300 x 1 @ 4 ohm
400 x 1 @ 2 ohm
Recommended Fuse Size: 30 amp
Power/Ground Wire Size: 8 Gauge
Dimensions (Includes Mounting Feet): 7.24” L x 6.93” W x 2.0” H
184mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 7.36” L x 6.93” W x 2.0” H
187mm L x 176mm W x 51mm H
RMS Power 14.4Vdc ≤1% THD 75 x 4 @ 4 ohm Stereo
125 x 4 @ 2 ohm Stereo
250 x 2 @ 4 ohm Bridged
Dynamic Power 14.4Vdc >1% THD 90 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
Recommended Fuse Size: 50 amp
Power/Ground Wire Size: 8 Gauge
Dimensions (Includes Mounting Feet): 10.0” L x 6.93” W x 2.0” H
254mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 10.63” L x 6.93” W x 2.0” H
270mm L x 176mm W x 51mm H
Specifications
SD800.5 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High Pass Crossovers: 12dB per Octave
Low Pass Crossover: 18dB per Octave
High Pass Crossover Range: 15Hz to 250Hz
Low Pass Crossover Range: 30Hz to 300Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Front and Rear Channels Lowest Load: 4 ohm Bridged or 2 ohm Stereo
Subwoofer Channel Lowest Load: 2 ohm
Typical Eciency: 70%
Damping Factor Greater than 200
Note: All SD ampliers operate correctly up to 14.4 volts. Do not
operate the amplier above 14.4 volts. The amplier will engage its
overvoltage protection, the result is no audio output on one or
more channels.
RMS Power 14.4Vdc ≤1% THD 75 x 4 @ 4 ohm Stereo
125 x 4 @ 2 ohm Stereo
250 x 2 @ 4 ohm Bridged
plus
200 x 1 @ 4 ohm
300 x 1 @ 2 ohm
Dynamic Power 14.4Vdc >1% THD 90 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
plus
300 x 1 @ 4 ohm
400 x 1 @ 2 ohm
Recommended Fuse Size: 60 amp
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Mounting Feet): 11.57” L x 6.93” W x 2.0” H
294mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 12.2” L x 6.93” W x 2.0” H
310mm L x 176mm W x 51mm H
SD600.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 18dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Eciency: 70%
Damping Factor: Greater than 200
RMS Power 14.4Vdc ≤ 1% THD 400 x 1 @ 2 ohm
600 x 1 @ 1 ohm
Dynamic Power 14.4Vdc >1% THD 600 x 1 @ 2 ohm
800 x 1 @ 1 ohm
Recommended Fuse Size: 60 amp
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Mounting Feet): 10.0” L x 6.93” W x 2.0” H
254mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 10.12” L x 6.93” W x 2.0” H
257mm L x 176mm W x 51mm H
© 2011 Phoenix Gold • www.phoenixgold.com
Amplier Owner’s Manual
INPUT
Connect preamp signal cables from the head unit to these terminals.
CROSSOVER FREQUENCY
Controls the lowpass crossover point for the speaker outputs.
BASS BOOST
Variable bass boost from 0 to +18dB @ 45Hz.
REMOTE LEVEL CONTROL
This port is for connecting the subwoofer remote level control. This allows
up to 20dB of volume adjustment. This is not a bass boost, it controls the
level of the low pass signal.
NOTE: This control is not compatible with the Phoenix Gold LPL44 level
control.
SENS
Used to reach maximum amplier power with a wide variety of headunits.
SUBSONIC CROSSOVER FREQUENCY
Controls the highpass crossover point for the speaker outputs to eliminate
extreme low frequencies.
+12V
This must be connected to the fused positive terminal (+12V) of the car’s
battery. The fuse must be located within 18 inches of the battery.
REMOTE
This must be connected to switched +12V, usually a trigger wire coming
from the head unit or ignition.
GROUND
This must be connected to the negative terminal of the car’s battery or
bolted to a clean, unpainted part of the chassis of the vehicle.
SPEAKER OUTPUTS
Used to connect the amplier to speakers. SD600.1 minimum impedance
is 1 ohm. SD300.1 minimum impedance is 2 ohm.
GROUND REMOTE + 12V
FUSE
30A30A SPEAKER
GROU ND + 12VR
POWER
SENS
MIN MAX
BASS
0dB 18dB
X-OVER
FREQ.
30Hz 300Hz
REMOTE
PROTECT
SUBSONI C
10Hz 55Hz
L
R
INPUT
SD300.1/SD600.1
Monoblo ck Power AmplifierS
NOTE: Visible through the plexiglass cover, a single blue power LED is located in the lower corner of all SD ampliers.
