Amplifier Manual
Manuel de l’amplificateur
Features
Models: Ti1500.1, Ti2500.1
Ti600.4, Ti800.4
© 2010 Phoenix Gold • www.phoenixgold.com
• 24dBVariableLowPassandSubsonicCrossovers(Ti2500.1,Ti1500.1)
• 18dBVariableHighandLowPassCrossovers(Ti800.4,Ti600.4)
• Crossoversfeature41DetentsforExactFrequencySelection
• AudiophileBi-PolarOutputTransistors(Ti800.4,Ti600.4)
• HighEfciencyClassDTopology(Ti2500.1,Ti1500.1)
• MassiveUnregulatedPowerSuppliesfeaturingHandWoundTransformers
• PowerOutputPeakIndicators
• 1/0GaugeDirectInsertPowerTerminals
• LPL44-LowPassLevelControlReady
• RMD-RemoteMonitoringDisplayPort
• AdvancedThermalandProtectionCircuitry
phoenix gold ti amp manual.indd 1 3/2/10 11:20:39 AM
Amplier Owner’s Manual
© 2010 Phoenix Gold • www.phoenixgold.com
MONOBLOCK SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Subsonic and Low Pass Crossovers: 24dB per octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Efciency: 80%
Damping Factor: Greater than 200
FOUR CHANNEL SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >110dB
High and Low Pass Crossovers: 18dB per Octave
Low Pass Crossover Range: 40Hz to 400Hz
High Pass Crossover Range: 20Hz to 400Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohm Bridged or 2 ohm Stereo
Typical Efciency: 50%
Damping Factor Greater than 200
Ti1500.1
Dynamic Power 14.4Vdc >1% THD 1100 x 1 @ 2 ohm
1500 x 1 @ 1 ohm
RMS Power 14.4Vdc ≤ 1% THD 900 x 1 @ 2 ohm
1250 x 1 @ 1 ohm
Recommended Fuse Size: 100A
Minimum Power/Ground Wire Size: 4 Gauge
Dimensions: 16.85” L x 9.8” W x 2.5” H
428mm x 252mm x 62mm
Ti2500.1
Dynamic Power 14.4Vdc >1% THD 1500 x 1 @ 2 ohm
2500 x 1 @ 1 ohm
RMS Power 14.4Vdc ≤ 1% THD 1100 x 1 @ 2 ohm
1650 x 1 @ 1 ohm
Recommended Fuse Size: 200A
Minimum Power/Ground Wire Size: 1/0 Gauge
Dimensions: 20.4” L x 9.8” W x 2.5” H
518mm x 252mm x 62mm
Ti600.4
Dynamic Power 14.4Vdc >1% THD 100 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
RMS Power 14.4Vdc ≤1% THD 90 x 4 @ 4 ohm Stereo
120 x 4 @ 2 ohm Stereo
240 x 2 @ 4 ohm Bridged
Recommended Fuse Size: 80A
Minimum Power/Ground Wire Size: 4 Gauge
Dimensions: 16.85” L x 9.8” W x 2.5” H
428mm x 252mm x 62mm
Ti800.4
Dynamic Power 14.4Vdc >1% THD 125 x 4 @ 4 ohm Stereo
200 x 4 @ 2 ohm Stereo
400 x 2 @ 4 ohm Bridged
RMS Power 14.4Vdc ≤1% THD 115 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
Recommended Fuse Size: 100A
Minimum Power/Ground Wire Size: 4 Gauge
Dimensions: 20.4” L x 9.8” W x 2.5” H
518mm x 252mm x 62mm
Specifications
phoenix gold ti amp manual.indd 2 3/2/10 11:20:39 AM
© 2010 Phoenix Gold • www.phoenixgold.com
Amplier Owner’s Manual
INPUT
Connectpreampsignalcablesfromtheheadunittotheseterminals.
OUTPUT
Providesafullrangesignalforanadditionalamplier.Thereisnosignal
lossifusingthisoutput.
CROSSOVER FREQUENCY
Controlsthelowpasscrossoverpointforthespeakeroutputs.
BASS BOOST
Variablebassboostfrom0to+18dB@45Hz.
LOW PASS LEVEL CONTROL (LPL)
Thisportisforconnectingtheoptionalremotelevelcontrol(LPL44).This
allowsupto20dBofvolumeadjustment.Thisisnotabassboost,it
controlsthelevelofthelowpasssignal.
REMOTE MONITORING DISPLAY (RMD)
ConnectoptionalRMDVoltageDisplaytothisport
LEVEL
Usedtoreachmaximumamplierpowerwithawidevarietyofheadunits.
SUBSONIC CROSSOVER FREQUENCY
Controlsthehighpasscrossoverpointforthespeakeroutputstoeliminateextreme
lowfrequencies.
PEAK INDICATOR
Lightswhentheamplierreachesnearmaximumoutput.Undernormal
operationthepeakindicatorshouldbeashingduringthepeaksofthe
music.Peakindicatorshouldnotstaylitforlongperiodsoftime(more
than2or3seconds),ifthisisthecaseyouneedtoreducesystemvolume
orleveloftheamplier.
PROTECT INDICATOR
Lightsredifthereisaproblemwiththeaudiosystem.Forexample,speakerwireis
pinched/shortedtogetherortheamplierisrunningtoolowofanimpedance.
12V+
Thismustbeconnectedtothefusedpositiveterminal(+12V)ofthecar’s
battery.Thefusemustbelocatedwithin18inchesofthebattery.
REMOTE
Thismustbeconnectedtoswitched+12V,usuallyatriggerwirecoming
fromtheheadunitorignition.
GND
Thismustbeconnectedtothenegativeterminalofthecar’sbatteryor
boltedtoaclean,unpaintedpartofthechassisofthevehicle.
SPEAKER OUTPUTS
Usedtoconnecttheampliertospeakers.Minimumimpedanceis1ohm.
ti2500.1 - ti1500.1
Monoblock Power Amplifier
phoenix gold ti amp manual.indd 3 3/2/10 11:20:40 AM
