10” POWERFUL COMPACT ACTIVE SUBWOOFER

Model: ZR10P

POWER RMS 200W (400W Max)

THD <0.5%

SIGNAL-TO-NOISE RATIO >90dB

FREQUENCY RESPONSE 20Hz - 150Hz

INPUT SENSITIVITY (HIGH LEVEL) 1.0V

INPUT SENSITIVITY (LOW LEVEL) 300mV

LOW PASS FILTER 50Hz - 150Hz

BASS BOOST 0 to 12dB

SUBSONIC FILTER 20Hz

FUSE RATING 25A

DIMENSIONS - MM (L x W x H) 340 x 245 x 78

SPECIFICATIONS

400W MAX POWER

All specications subject to change without notice.

ZR10P Owners Manual

ZR10P - ACTIVE SUBWOOFER

Features

• 10" Active powerful compact subwoofer

• 200W RMS 400W Max

• Autostart on high-level input

• Remote gain control

• High and low level input

• Power & high-level cable quick

connector

• Aluminium casing

• Subsonic lter at 30Hz

• Phase control

• Variable bass boost 0-12dB

• Dimensions - 340mm x 245mm x 78mm

Specikationer

• 10” kompakt aktiv subwoofer

• 200W RMS 400W Max

• Autostart på högnivåingångarna

• Volymkontoll via kabelburen fjårrkontroll

• Hög och lågnivåingångar

• Ström, samt högnivåingångar via

snabbkontakter

• Aluminiumkabinett

• Subsonic-lter vid 30Hz

• Faskontroll

• Variabel basfor boost 0-12dB

• Dimensioner - 340mm x 245mm x 78mm

Spezikation

• kompakter aktiver 10” Subwoofer

• 200W RMS 400W max

• Autostart bei High-Level-Eingabe

• Lautstärkeregelung per Fernbedienung

• High und Low Level Eingang

• Schnellkupplung für Strom- und

High-Level-Kabel

• Aluminiumgehäuse

• Subsoniclter bei 30Hz

• Phasensteuerung

• Variabler Bass Boost 0-12dB

• Abmessungen - 340mm x 245mm x 78mm

Caracteristiques

techniques

• Subwoofer actif compact de 10 pouces

• 200W RMS 400W maximum

• Démarrage automatique sur une entrée

de haut niveau

• Contrôle de gain à distance

• Entrée haut et bas niveau

• Connecteur rapide de câble

d’alimentation et de haut niveau

• Boîtier en aluminium

• Filtre subsonique à 30Hz

• Contrôle de phase

• Amplication des basses variable 0-12dB

• Dimensions - 340mm x 245mm x 78mm

Caracteristicas

• Subwoofer de 10” active compacto

• 200W RMS 400W Máximo

• lnicio automático de entrada de alto nivel

• Control remote de ganancia

• Entrada de nivel alto y bajo

• Conector rápido de cable de

alimentación y alto nivel

• Carcasa de aluminio

• Filtro subsónico a 30Hhz

• Control de fase

• lncremento de graves variable 0-12dB

• Dimensiones - 340mm x 245mm x 78mm

• Subwoofer attivo compatto da 10”

• 200W RMS 400W massimo

• Awio automatico su input di alto livello

• Controllo remoto del guadagno

• lngresso di alto e basso livello

• Connettore rapido per cavo di

alimentazione e di alto livello

• Rivestimento in alluminio

• Filtro subsonico a 30Hz

• Controllo di fase

• Aumento dei bassi variabile 0-12dB

• Dimensioni: 340mm x 245mm x 78mm

Caratteristiche

tecniche

ZR10P Owners Manual

ZR10P - ACTIVE SUBWOOFER

A. POWER STATUS LED

PANEL CONTROLS & FEATURES

C D E F G H I J

This bi-color LED glows green when power is on and no problems are present. If one of the

protection circuits comes on, it will change to red.

B. PHASE SHIFT

Use this switch to help compensate for time alignment problems in the system. Such

problems usually result from having the subwoofer at a different distance from the listener

than the other speakers in the system.

C. AUTO POWER ON

The “AUTO POWER ON”( ) is for high level (speaker-level) connections. When the ON/OFF

switch is in the “ ” position, the subwoofer will automatically turn on when there is signal ON

input. If the amplier detects no signal input, the amplier will automatically power off. If

you prefer to use the remote turn on/off connection, leave the switch in the “ ” position.OFF

D. LOW PASS FILTER

This control permits you to dene the frequency range you want the subwoofer amplier

to receive. The subwoofer will reproduce all sound BELOW the frequency you set.

E. BASS BOOST

The bass boost feature will increase the sound level in the bass frequencies.

F. INPUT GAIN CONTROL

After you have installed your system, turn this control to minimum. Turn the head unit on

(and the subwoofer will turn on via the remote connection). Turn the head unit volume to

about 2/3 full level. Slowly turn up the subwoofer input gain control until you hear a small

amount of distortion. Then reduce the level until the distortion is completely gone. Level

the control at this setting.

Note: Please connect the remote terminal to the remote output of head unit as Fig.5

when you hear the unit turn ON/OFF POP noise from the subwoofer.

Note: The low pass lter frequency can be higher or lower than the standard. There is

+/-20% tolerance.
