Technical Support
If you need technical support with your Planet Audio product or have
quesons about its use, please contact us:
805 751 4854- -
www.PlanetAudioUSA.com
Due to ongoing product development, specicaons are subject to change without
AC15D_0616_2
Congratulaons on your purchase of the Planet Audio Anarchy Subwoofer.
Planet Audio takes great pride in producing products that sound and look great and stand up
to the daily rigors applied by audio enthusiasts around the world.
AC15D 15” Subwoofer
Dual 4 Ω Voice Coils
2100 W Peak Power Handling
Customizable Trim Ring
Enclosure
The AC15D is designed to work in a sealed or ported enclosure. Since the
woofer has pole vent, it needs a minimum clearance from the rear wall -
of the enclosure of 0.75” (19 mm).
Below you will nd the dimensions to make the enclosure to suit the
subwoofer, it has been designed for maximum output while retaining
great sound quality.
The dimensions have already accounted for the volume displacement of
the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
Enclosure Dimensions
Extern
Extern
Extern
ExternExternal Seal
al Seal
al Seal
al Sealal Sealed Dim
ed Dim
ed Dim
ed Dimed Dimensio
ensio
ensio
ensioensions:
ns:
ns:
ns:ns:
Height (H) : 16” (406mm)
Depth (D) : 16” (406 mm)
Width (W) : 18” (457 mm)
Cutout Diameter: 13 7/8” (352 mm)-
Extern
Extern
Extern
ExternExternal Po
al Po
al Po
al Poal Ported Di
rted Di
rted Di
rted Dirted Dimensio
mensio
mensio
mensiomensions:
ns:
ns:
ns:ns:
Height (H) : 16 1/2” (419 mm)-
Depth (D) : 18” (457 mm)
Width (W) : 26” (660 mm)
Slot Port Height: 15” (381 mm)
Slot Port Length: 30” (762 mm)
Slot Width: 2” (51 mm)
Tuning Freq: 35 Hz
8 Ω 2 Ω
Parallel Series
Wiring Opons
Series
4 Ω
Parallel
1 Ω
Mulple Subwoofers
Parameters
Impedance Dual 4 Ω
Resonant Frequency 25 Hz
Qts 0.675
Qms 6.147
Qes 0.759
Vas 8 (227 liters) ³
Xmax 13 mm
Sensivity (1 W/ 1 m) 89 dB
Peak Power Handling 2100 W
Mounng Depth 7” (178 mm)
Cutout Diameter 7/8” (352 mm) 13-
