Sida 1/6
BRA1 Info - Sept 2016
Page 1 of 7
BRAVO!®
2-STATION HANDWASH SINK
Operations & Maintenance Guide
We recommend reading through the entire booklet prior to proceeding with use, service or maintenance.
All materials, including resin, pigments and additives used to make the plastic components as well as the plumbing
components that come in contact with the fresh water are U.S. FDA food grade compliant.
Height 62 in 157 cm
Width 26.5 in 67 cm
Depth 21.5 in 54 cm
Fresh Water Capacity 22 gal 83 L
Gray Water Capacity 24 gal 91 L
Pump Capacity
(per stroke) 2 fl oz 59.1 ml
Number of Single
Dispenses 1408 1408
Weight Empty 70 lb 32 kg
Weight Full 254 lb 115.2 kg
Power Requirements
(Heated Model) 110v/15A NA
Paper Towel Dispenser
Four packs of single-fold towels (Georgia Pacic
23504)
250 towels per pack. 1000 per wash station.
Soap Dispensers
Capacity 30 fl oz 887 ml
Total Capacity 60 fl oz 1774 ml
SPECIFICATIONS
Dimension Imperial Metric
NOTE: All dimensions are subject to change due to environmental factors.
Covered by U.S. Patent 7,730,561 & U.S
Design Patent 553,753
POLYJOHN
USA
PolyJohn Enterprises Corp
2500 Gaspar Ave.
Whiting, IN 46394
Phone: 800-292-1305
Fax: 219-659-0625
www.polyjohn.com
info@polyjohn.com
POLYJOHN
WORLDWIDE
PolyJohn (UK) Ltd.
Equinox 1 Audby Lane
Wetherby, England LS22 7RD
Phone: 44 (0) 1937-583333
Fax: 44 (0) 1937-583322
www.polyjohn.co.uk
sales@polyjohn.co.uk
POLYJOHN
CANADA
PolyJohn Canada
P.O. Box 2300
199 Forest Plain Rd.
Orillia, Ontario LV3 6S2
Phone: 800-465-9590
Fax: 705-325-8250
www.polyjohncanada.ca
info@polyjohncanada.ca
BRA1 Info - Sept 2016
Page 2 of 7
The Bravo is a supreme dual hand wash station. It features a sleek design that is unmatched in the industry and is easily
transported inside most portable restrooms. The dimensions are within the United Parcel Service (UPS) shipping require-
ments.
This free standing wash station has been designed with extra deep sink basins so users may wash up to their elbows.
If warm water washing is desired or required, Bravo can deliver instant warm water with the BRA1-2000 Model.
Bravo’s unique options make it an ideal choice for all types of industry.
Service / Maintenance Information
Emptying Gray Water
Bravo features three options to empty the gray water; Siphon, Drain or Pump.
1. Siphon - Place service wand onto rubber gasket (BRA1-0008). Create a tight seal. Open vacuum valve to begin si-
phon; siphon should begin within 5 seconds. Remove wand and allow sink to empty. If “dumping” of gray water is
not approved, leave vacuum on until sink is empty.
2. Drain - There are two drains side by side at the bottom of the sink, remove the one on the left to drain the gray water.
3. Pump - Unlock the lock on the wingnut cap, unscrew the cap and pull the plug out. Unlock the lock on the hinged bowl
top and lift the hinged bowl top up to access the interior of the outer tank.
Filling with Fresh Water
Unlock the lock on the ll cap located on the hinged side of the sink tower top (between the two sink bowls). Unscrew the
wingnut on the ll cap and pull the plug out. Insert a standard 1” garden or similar type hose. Fill with a few gallons of
fresh water to perform a system check. Depress each pump a few times to “prime” them. The pumps have built in check
valves that will hold a prime between uses. Continue lling to the 22 gallon capacity.
Emptying Fresh Water
Drain the fresh water by removing the right side 1” drain plug from the bottom of the sink.
Winterizing
• Drain all water from the tanks.
• Depress the foot pump to clear lines.
• Flush tank with a solution of chlorine and water.
General Product Overview & Operation Information
Paper Towel Dispenser
Unlock the lock on the dd one pack of single fold towels (Geordispenser lid to release the catch lock. Lift up the lid and a -
gia Pacic 23504 or equivalent) to each compartment (total of 4 packs). Feed the rst towel through the slots in the bot-
tom of the towel holder body.
Soap Dispenser
Unlock the lock on the Paper Towel Dispenser Lid to release the catch lock. Lift up the lid and pull the ring of the Soap
Dispenser Mount Plate (BRA1-0021) up through the Paper Towel Dispenser and remove. Open one of the Soap Dispens-
ers by turning the lid counter clockwise and lifting off. Fill with 30 fluid ounces of liquid soap. Replace the lid and repeat
for the other soap dispenser. Reinsert the Soap Dispensers down through the Paper Towel Dispenser and lock.
Cleaning and Maintenance
Use a mild soap to clean all surfaces and component parts.
Minor scratches and abrasions can be lightly sanded or scrubbed with a mild abrasive cleaner (such as “Soft Scrub”) that
contains calcium carbonate, hypochlorate bleach and detergents. Be sure to follow the cleaning product directions since
these ingredients may cause hazardous gases when mixed with other chemicals. Rinse the cleaned area and buff with a
conventional wax.
Some light scratches may also be hidden by using an industrial hot air gun.
To keep the water fresh add a “Fresh Sink Tablet” (chlorinated tablet) each time the sink is lled with water.
BRA1 Info - Sept 2016
Page 3 of 7
PSD1-0003 - Lid
PC-000243 - O-Ring
FP1-0021 - Valve
PSD1-0002 - Soap Body
PSD1-0001 - Mounting Plate
PSD1-0012 - Check Valve
PSD1-0020 - Return Spring
PSD1-0010 - Pump Cup
PSD1-0030 - Check Ball
PSD1-0021 - Check Spring
PSD1-0011 - Pump Shaft
PSD1-0005 - Pump Retainer
PSD1-0004 - Pump Button
Service / Maintenance Information (continued)
PSD1-1000
Exploded View
Soap Dispenser
Unlock the lock on the Paper Towel Dispenser Lid to release the catch lock. Lift up the lid and
pull the ring of the Soap Dispenser Mount Plate (BRA1-0021) up through the Paper Towel Dis-
penser and remove. Open one of the Soap Dispensers by turning the lid counter clockwise and
lifting off. Fill with 30 fluid ounces of liquid soap. Replace the lid and repeat for the other soap
dispenser. Reinsert the Soap Dispensers down through the Paper Towel Dispenser and lock.
