Art.-Nr.: 41.377.56 I.-Nr.: 01014
Operating and Maintenance Instructions
Pneumatic Stapler
PC 25/1
Anleitung PC 25-1 16.11.2004 10:41 Uhr Seite 1
2
Follow the operating instructions!
Wear safety goggles!
Wear ear muffs!
Anleitung PC 25-1 16.11.2004 10:41 Uhr Seite 2
GB
3
Dear Customer,
Before you use the stapler for the first time, please
read these instructions and note the information for
the tool’s operation and maintenance.
Always keep this manual with the tool.
1. Technical data
Permissible working pressure max. 6 bar
Air consumption approx. ca. 011 L/min.
Staple width 5 mm
Staple length 13-40 mm
Nail length 16-50 mm
Recommended hose diameter 9 mm i Ø
Air quality cleaned and oiled
Compressor capacity
approx. 250 l/min. equivalent to a motor
rating of 2.2 kW
Work settings
6 bar working pressure set at the pressure reducer
or filter pressure reducer
Please note:
When working with the stapler, be sure to wear
the necessary protective clothing, particularly
goggles.
Observe the safety regulations.
2. Illustration
Item. Description
A trigger lever
B magazine
C magazine lever
D plug-in nipple for the air supply
E air connection - will accept any standard -
male/female air connector
F Swivel air-outlet
3. Proper use
The stapler is a pneumatic tool for DIY uses such
as upholstery of furniture, fixing skirting boards,
fixing wooden floor boards etc.
The exhaust air leaves the housing to the front.
Repairs and maintenance work are to be carried
out only by authorized specialist workshops.
Gun should operate on most compressors with the
correct connector fitted.
Please note!
The power of the tool will be reduced if you use a
hose that has too small an inner diameter or
which is too long.
4. Safety regulations
Take suitable precautions to protect yourself and
your environment from potential hazards.
Never put the stapler to any use other than that
intended.
KEEP TOOLS AWAY FROM CHILDREN.
Always concentrate while you work. Do not work if
you are tired.
Use only a quick-release coupling to connect up
the air supply.
It is imperative to use a pressure reducer to set
the working pressure.
Never use oxygen or combustible gases as an
energy source.
Always disconnect the tool from the air supply
before carrying out any repairs or maintenance
work.
A
D
E
C
B
F
Anleitung PC 25-1 16.11.2004 10:41 Uhr Seite 3
