CX1400/3500/5500 Portable

Generator

Owner’s Manual

SAVE THIS MANUAL FOR FUTURE REFERENCE

001593

(000209a)

WARNING

This product is not intended to be used in

a critical life support application. Failure to

adhere to this warning could result in

death or serious injury.

MODEL:________________________

SERIAL:________________________

DATE PURCHASED:______________

SAVE THIS MANUAL FOR FUTURE REFERENCE

www.powermate.com

1-800-445-1805

Table of Contents

Section 1 Introduction and Safety 1

Introduction ..................................... 1

Safety Rules .................................... 1

Safety Symbols and Meanings ........ 1

Exhaust and Location Hazards ....... 2

Electrical Hazards ........................... 3

Fire Hazards .................................... 3

Standards Index .............................. 3

Section 2 General Information and

Setup .............................................. 4

Know Your Generator ..................... 5

Emissions ........................................ 5

Connection Plugs ............................ 6

Remove Contents from Carton ....... 7

Assembly ......................................... 7

Add Engine Oil ................................ 9

Fuel ............................................... 10

Section 3 Operation .................... 11

Operation and Use Questions ....... 11

Before Starting Engine .................. 11

Prepare Generator for Use ............ 11

Grounding the Generator When In Use

Know Generator Limits .................. 12

Transporting/Tipping of the Unit .... 12

Starting Pull Start Engines ............ 13

Generator Shut Down ................... 13

Low Oil Level Shutdown System ... 13

Section 4 Maintenance and

Troubleshooting ..........................14

Maintenance ..................................14

Maintenance Schedule ..................14

Preventive Maintenance ................14

Engine Maintenance ......................14

Inspect Muffler and Spark Arrestor 16

Valve Clearance ............................16

Storage ..........................................16

Troubleshooting .............................18

Notes .............................................19

(000004)

WARNING

California Proposition 65. Engine exhaust and some

of its constituents are known to the state of California

to cause cancer, birth defects, and other reproductive

harm.

(000005)

WARNING

California Proposition 65. This product contains or

emits chemicals known to the state of California to

cause cancer, birth defects, and other reproductive

harm.

Owner’s Manual for Portable Generator 1

Section 1 Introduction and Safety

Introduction

Thank you for purchasing a Powermate prod-

uct. This unit has been designed to provide

high-performance, efficient operation, and

years of use when maintained properly.

If any section of the manual is not understood,

contact your nearest Independent Authorized

Service Dealer (IASD), or contact Powermate

Customer Service at 1-800-445-1805, or

www.powermate.com with any questions or

concerns.

The owner is responsible for proper mainte-

nance and safe use of the equipment. Before

operating, servicing or storing this generator:

• Study all warnings in this manual and on

the product carefully.

• Become familiar with this manual and the

unit before use.

• Refer to the Assembly section of the man-

ual for instructions on final assembly proce-

dures. Follow the instructions completely.

Save these instructions for future reference.

ALWAYS supply this manual to any individual

that will use this machine.

THE INFORMATION CONTAINED HEREIN

WAS BASED ON MACHINES IN PRODUC-

TION AT THE TIME OF PUBLICATION.

POWERMATE RESERVES THE RIGHT TO

MODIFY THIS MANUAL AT ANY TIME.

Safety Rules

The manufacturer cannot anticipate every

possible circumstance that might involve a

hazard. The warnings in this manual, and on

tags and decals affixed to the unit are, there-

fore, not all inclusive. If using a procedure,

work method or operating technique that the

manufacturer does not specifically recom-

mend, verify that it is safe for others. Also

make sure the procedure, work method or

operating technique utilized does not render

the equipment unsafe.

Throughout this publication, and on tags and

decals affixed to the generator, DANGER,

WARNING, CAUTION and NOTE blocks are

used to alert personnel to special instructions

about a particular operation that may be haz-

ardous if performed incorrectly or carelessly.

Observe them carefully. Their definitions are

as follows:

NOTE: Notes contain additional information

important to a procedure and will be found

within the regular text of this manual.

These safety warnings cannot eliminate the

hazards that they indicate. Common sense

and strict compliance with the special instruc-

tions while performing the action or service

are essential to preventing accidents.

Safety Symbols and Meanings

• If you start to feel sick, dizzy, or weak after

the generator has been running, move to

fresh air IMMEDIATELY. See a doctor, as

you could have carbon monoxide poison-

ing.

(000100a)

WARNING

Consult Manual. Read and understand manual

completely before using product. Failure to

completely understand manual and product

could result in death or serious injury.

(000001)

DANGER

Indicates a hazardous situation which, if not avoided,

will result in death or serious injury.

(000002)

WARNING

Indicates a hazardous situation which, if not avoided,

could result in death or serious injury.

(000003)

CAUTION

Indicates a hazardous situation which, if not avoided,

could result in minor or moderate injury.

000657

DANGER

Using a generator indoors CAN KILL YOU IN MINUTES.

Generator exhaust contains carbon monoxide. This is

a poison you cannot see or smell.

NEVER use inside a home

or garage, EVEN IF doors

and windows are open.

Only use OUTSIDE and

far away from windows,

doors, and vents.

(000103)

DANGER

Asphyxiation. Running engines produce carbon

monoxide, a colorless, odorless, poisonous gas.

Carbon monoxide, if not avoided,

will result in death or serious injury.
