Presto 07061 Bruksanvisning

Presto Grillplatta 07061

Läs nedan 📖 manual på svenska för Presto 07061 (5 sidor) i kategorin Grillplatta. Denna guide var användbar för 6 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/5

22-inch

Electric Griddle

with removable handles

• Extra-large cooking surface makes

enough for the entire family.

• Control Master

 heat control maintains

the proper cooking temperature

automatically.

• Textured cooking surface provides enhanced

nonstick performance and easier cleaning.

• Slide-out drip tray for quick cleanups.

• Removable handles for easy cleaning and

compact storage.

INSTRUCTIONS

Visit us on the web at www.GoPresto.com

2011 by National Presto Industries, Inc.

This is a Listed appliance. The following important safeguards are recommended by most portable appliance manufacturers.

IMPORTANT SAFEGUARDS

To reduce the risk of personal injury or property damage, when using electrical appliances basic safety precautions should always be

followed, including the following:

1. Read all instructions.

2. Warning: To reduce the risk of ﬁre, do not plug in with handles removed.

3. Be sure that handles are assembled and fastened properly before using this appliance. See instructions regarding handles on

page 2.

4. Do not touch hot surfaces. Use handles or knobs.

5. To protect against electrical shock, do not immerse heat control, cord, or plug in water or other liquid.

6. Close supervision is necessary when any appliance is used by or near children.

7. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning

the appliance.

8. Do not operate any appliance with a damaged cord or plug or in the event the appliance malfunctions or has been damaged in

any manner. Return the appliance to the Presto Factory Service Department for examination, repair, or electrical or mechanical

adjustment.

9. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.

10. Do not use outdoors.

11. Do not let cord hang over edge of table or counter or touch hot surfaces.

12. Do not place on or near a hot gas or electric burner or in a heated oven.

13. It is recommended that this appliance not be moved when it contains hot oil or other hot liquid. If it must be moved when it

contains hot oil or other hot liquid, use extreme caution.

14. Always attach heat control to appliance ﬁrst, then plug cord into the wall outlet. To disconnect, turn control to “OFF” then

remove plug from wall outlet.

15. Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS

THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.

Estas instrucciones también están disponibles en español.

Para obtener una copia impresa:

• Descargue en formato PDF en www.GoPresto.com/espanol.

• Envíe un mensaje de correo electrónico a contact@GoPresto.com.

• Llame al 1-800-877-0441, oprima 2 y deje un mensaje.

Important Cord Information

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is

intended to ﬁt into a polarized outlet only one way. If the plug does not ﬁt fully into the outlet, reverse the plug. If it still

does not ﬁt, contact a qualiﬁed electrician. Do not attempt to modify the plug in any way.

A short power supply cord (or cord set) is provided to reduce the risk resulting from becoming entangled in or tripping

over a longer cord. Extension cords may be used if care is properly exercised in their use.

If an extension cord is used, the marked electrical rating of the extension cord should be at least as great as the electrical

rating of the appliance. The extension cord should be arranged so that it will not drape over the countertop or tabletop

where it can be pulled on by children or tripped over unintentionally.

Before the First Use

Remove all packing material. Set the handles, drip tray, and heat control aside. Wash the griddle according to the “Care

and Cleaning” instructions on page 3.

Before using this griddle, the handles must be attached as instructed below:

1. Place the griddle cooking surface side down on a ﬂat surface (Fig. A).

2. Position one of the handles, feet side up, over the griddle so that the two handle

holes are directly over the latch clip catches. The latch clip levers will rest on the

catches.

3. Pull the latch clips back beyond the catches (Fig. B) and push the handle down until

it is ﬁrmly seated against the griddle. Release the latch clips to lock the handle into

place. To be sure the handle is securely attached, check that both latch clips are

under the edge of the latch clip catches (Fig. C).

4. Repeat steps 2 and 3 with the other handle.

How To Use

1. Place assembled griddle on a dry, level, heat resistant surface. Slide drip tray

onto tracks.

2. If desired, “season” the nonstick cooking surface by rubbing lightly with cooking

oil. Remove excess oil with a paper towel.

3. Insert the Control Master  heat control probe into the griddle so the two electrical

pins on the griddle are fully inserted into the heat control. Connect cord to outlet.

4. Turn Control Master heat control to desired temperature (see page 4 for cooking

temperatures). Preheat griddle. Pilot light goes off when selected temperature is

reached (this takes approximately 5 to 10 minutes).

Note: As the griddle heats up, you may hear a clicking sound; this is due to the

expansion of the metal as it heats. It is normal. You may also notice this sound as the

unit cools down.

5. Prepare food for cooking. Because the griddle features a nonstick ﬁnish, food may

be prepared with little or no oil.

6. Place food on griddle and cook according to the temperature-timetable (page 4).

Heat should be adjusted according to personal preference and particular food being

cooked. During cooking, pilot light will go on and off indicating desired temperature

is being maintained.

For best results use nylon, plastic, wooden, or rubber utensils. Do not use metal

utensils as they may scratch the nonstick surface. Do not cut foods on the cooking surface.

7. Turn heat control to OFF when cooking is completed. Unplug heat control from wall outlet then from appliance. Allow

griddle to cool before removing drip tray.

Note: This griddle is not intended to be used as a warming tray.

Latch clip

catches

Griddle

Handle

holes

Griddle

handle

Fig. A

Fig. B

Latch clip

levers

Latch clip

Latch

clip catch

Fig. C

Rubber

foot

*Scotch Brite and

Dobie

are trademarks of 3M;

dip-it is a registered trademark of Ecolab, Inc.

Care and Cleaning

Before initial use and after each subsequent use, wash griddle in warm, sudsy water, rinse, and dry. Do not immerse

Control Master heat control in water or let it come in contact with any liquid.

To disassemble the griddle handles for cleaning and storage:

1. Initially, place the griddle cooking surface side down on the counter. Remove each of the handles by pulling the

latch clips back until the clips clear the edge of the latch clip catches (Fig. B). While holding the clips back, lift

the handle from the griddle. With practice, you will be able to open the clips and remove the handles while the

griddle is in an upright position.

After each use, clean the nonstick surface with a non-metal cleaning pad, such as Scotch-Brite* Multi-Purpose Scrub

Sponge or Scotch-Brite* Dobie* Cleaning Pad. Firm pressure can be applied, if necessary. Do not use steel wool or

abrasive kitchen cleaners.

In time, the nonstick ﬁnish may darken over the heating element. To remove this discoloration, use a commercial cleaner

designed for cleaning surfaces, such as dip-it* destainer. These cleaners are available at most grocery and hardware stores.

Slide drip tray into place. Preheat griddle to 225° F. Combine 1 cup of hot water and 1 tablespoon of commercial cleaner.

Wearing rubber gloves, dip cleaning pad into cleaning solution and rub over cooking surface. Continue cleaning until

solution is gone. Turn griddle off and allow to cool. Wash griddle in hot, soapy water and dry.

After treating the griddle with a commercial cleaner, it is recommended that the cooking surface be wiped lightly with a

cooking oil before using.

IMPORTANT: To ensure continued accuracy of the Control Master heat control, avoid rough handling in use and

storage.
