Sida 1/4

1 Programme selector

2 “Start/Pause” button

3 “Reset/Drain” button

4 Programme sequence indication

5 “Start delay” button

6 “Spin speed” button

7 Time indication

INDICATORS

Door locked

Failure: Service

Failure: Clean lter

Failure: Water tap closed

In the event of any failure, refer to the

“TROUBLESHOOTING” section

CONTROL PANEL

PROGRAMME CHART

PRODUCT DESCRIPTION

1. Lid handle

2. Lid

3. Control panel

4. Detergent dispenser

5. Drum

6. Water lter - behind the cover

7. Mobility lever (depending on model)

8. Adjustable feet (x2)

DETERGENT DISPENSER

Main wash compartment

Detergent for the main wash, stain remover or

water softener.

Prewash compartment

Detergent for the prewash.

Softener compartment

Fabric softener. Liquid starch. Bleach.

Pour in softener, starch or bleach solution

only up to the “max” mark.

Release button 

Press to remove tray for cleaning.



the programmes, without options. The values given for programmes other than the eco 40-60

programme are indicative only.

* After programme end and spinning with maximum selectable spin speed, in default

programme setting.

** The duration of the programme is shown on the display.

The sensor technology adapts water, energy and programme duration to your wash load.

Eco 40-60 - Test wash cycle in compliance with 2019/2014 regulation. The most ecient

programme in terms of energy and water consumption for washing normally soiled cotton

laundry. Display only: Spin speed values shown on the display can slightly diers from the

values stated in the table.

For all Test Institutes

Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.

Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.

This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of

Quick guide

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bracket is removed.

For more detailed instructions on how to remove it, see the Installation Guide.

THANK YOU FOR CHOOSING OUR PRODUCT.

Max load 6,5 Kg

Power consumption in o-mode 0,11 W / in left-on mode 0,11 W Detergents and additives Recommended

detergent

Residual

dampness % *

Energy

consumption kWh

Total water lt

Loundry

temperature °C

Programme

Temperatures Max, spin

speed (rpm)

Max

load

(kg)

Dura-

tion

(h : m)

Pre-

wash

Main

wash Softener

Powder Liquid

Setting Range

Turn & Go 30°C 30°C 1000 3,5 ** –   –– – – –

Synthetics Synthetik 40°C 40°C 1200 3,0 1:50      40 0,56 50 40

Cotton Baumwolle 60°C 120040°-90°C 6,5 3:00      57 1,23 51 55

Eco 40-60 40°C 40°C

1151 6,5 3:20 –     53 0,97 55 43

1151 3,25 2:30 –     53 0,50 39 31

1151 1,5 1:50 –     53 0,35 31 31

20 °C 20°C 20°C 1200 6,5 2:25 –   –53 0,25 48 20

Wool 20° Wolle 20° 20°C 20°C 1000 1,0 ** –   –– – – –

Delicates 30° Feinwäsche 30° 30°C 30°C 1000 1,5 ** –   –– – – –

Mix 45’ 40° Mix 45’ 40° 40°C 40°C 1000 6,5 ** –     – – – –

Cotton 30° Baumwolle 30° 30°C 30°C 1200 3,0 0:30 –   –57 0,25 42 27

Synthetics 30° Synthetik 30° 30°C 30°C 1200 3,0 ** –   –– – – –

Spin + Drain Centrifug. +

Desague – – 1200 6,5 – – – – – – – – – –

Rinse + Spin Aclarado +

Centrifugado – – 1200 6,5 – – – – – – – – –

  Dosing required Dosing optional

PROGRAMMES

For choosing the appropriate programme for your kind of

laundry, always respect the instructions on the care labels

of the laundry. The value given in the tub symbol is the

maximum temperature possible for washing the garment.

Turn & Go

The best daily washing solution. Particularly useful for lightly and

normally soiled textiles made of cotton or synthetic fabrics, as it washes

at low temperature and a maximum spin speed.

Synthetics / Synthetik

For washing soiled garments made from synthetic fibres (such as

polyester, polyacrylic, viscose, etc.) or cotton/synthetic blends.

Cotton / Baumwolle

Normally to heavily soiled and robust cottons.

Eco 40-60

For washing normally soiled cotton garments declared to be washable

at 40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

20 °C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Wool / Wolle 20°

All wool garments can be washed using programme ‚ “Wool“ even

those carryng the “hand-wash only“ label. For best results, use special

detergents and do not exceed max kg declaration of laundry.

Delicates / Feinwäsche 30°

For washing particularly delicate garments. Preferably turn garments

inside out before washing.

Mix 45’ 40°

For washing lightly to normally soiled garments in cotton, linen,

synthetics bers and mixed bers in just 45 minutes.

Cotton / Baumwolle 30°

For washing lightly soiled garments quickly. This cycle lasts only 30

minutes, saving time and energy.

Synthetics / Synthetik 30°

Enshorted cycle for lightly soiled garments made from synthetic bres

(such as polyester, polyacrylic, viscose, etc.) or cotton/synthetic blends.

Spin + Drain / Schleudern + Abpumpen

Spins the load then empties the water. For robust laundry.

Rinse & Spin / Spülen + Schleudern

Separate rinse and intensive spin programme. For robust laundry.

FIRST TIME USE

Select the “Cotton" programme at a temperature of 90°C. Pour a small

quantity of detergent powder into the main wash compartment of

the detergent dispenser (maximum 1/3 of the quantity the detergent

manufacturer recommends for lightly soiled laundry). Start the

programme without adding any laundry.

DAILY USE

Prepare your laundry according to the recommendations in the “HINTS

AND TIPS” section. Load the laundry, close the drum door and check

that it is closed properly. Pour in the detergent and any additives.

Observe the dosing recommendations on the detergent pack. Close the

lid. Turn the programme selector to the desired programme and select

any option if needed. The display shows the duration of the selected

programme (in hours and minutes), and the indicator for the “Start/

Pause” button flashes. The indicator for the preset spin speed lights up.

The speed can be changed by pressing the “Spin Speed” button. Open

the tap and press the “Start/Pause” button to start the wash cycle. The

“Start/Pause” indicator will lights up and the door will be locked. Due

to variations in load and temperature of inlet water, the remaining time

is newly calculated in certain programme phases. If this is the case, an

animation appears on the time display.

PAUSE OR CHANGE A RUNNING PROGRAMME

To pause the wash cycle, press the “Start/Pause” button, the indicator

light blinks. Select any new programme, temperature, options or spin

speed if you wish to change those settings. Press the “Start/Pause”

button again to start the wash cycle from the point at which it was

interrupted. Do not add detergent for this programme.

DOOR LOCKED

After start of a program the lamp lights up to indicate that the lid

can not be opened. As long as a wash programme is running, the lid

remains locked and must on no account be forced open. In case you

have an urgent need to open it during a running programme, for

example to add more laundry, or to remove laundry which was loaded

by mistake, press the “Start/Pause” button. If the temperature is not too

high, the “Door locked” indicator light turns off. It may last a while

until you can open the lid. Press “Start/Pause” button to proceed with

the programme again.

PROGRAMME END

The “Door locked” indication light goes off and the display shows

. Turn the programme selector to the “OFF” position and close

the water tap. Open the lid and drum and unload the machine. Leave

the lid open for some time to allow the interior of the machine to dry.

After about a quarter of an hour, the washing machine will switch off

completely to save energy.

To cancel a running programme before the end of cycle, press the

“Reset/Drain” button for at least 3 seconds. The water is drained out. It

may last a while until you can open the lid.

OPTIONS

! When the combination of programme and additional option(s) is not

possible, the indication lights switch o automatically.

! Unsuitable combinations of options are deselected automatically.

Startzeitvorwahl (Start delay )

To set the selected programme to start at a later time, press the “Start

delay” button to set the desired delay time. The lamp for the

“Start delay” option button lights up, and it goes off when the

programme starts. Once having pressed the “Start/Pause” button,

the countdown of the time delay begins. Number of hours preselected

can be reduced by pressing the “Start delay” button again. Do not

use liquid detergent when activating this option. To cancel the “Start

delay” turn the programme selector to another position.

Extra Waschen (Intensive wash )

Choose this option if you use an in-wash additive for stain removal - it

will optimize the additive’s eciency to get better wash performance

and stain removal. Use with the maximum load. Add an appropriate of

in-wash additive for stain removal (powder) to the main wash

May prolong the programme by up to 10 minutes. Appropriate for use

of stain removers and bleaches on oxygen basis. Chlorine or perborate

bleches must not be used!

Extra Spülen (Extra rinse )

Helps to avoid detergent residues in the laundry by extending the

rinse phase. Particularly suitable for washing baby laundry, for people

suffering from allergies and for areas with soft water.

Schleuderdrehzahl (Spin speed )

Every programme has a predened spin speed. Press the button to set

another spin speed. The indicator of the predefined spin speed lights

up. If spin speed “0” is selected, the nal spinning is cancelled but

intermediate spin peaks remain during the rinse.

Prewash / Vorwäsche

Only for heavily soiled loads (for example sand, granular dirt). Increases

the cycle time by approximately 15 min. Do not use liquid detergent for

the main wash when activating the Prewash option.

Energy Saver

With a lower temperature and slightly modied washing duration, the

optimum combination of excellent washing results and even lower

energy consumption is achieved.

BLEACHING

Wash your laundry in the desired programme, Cotton or Synthetics

, adding an appropriate amount of chlorine bleach to the Softener

chamber (close the lid carefully). Immediately after the end of

the programme, turn the “Programme selector” and start the desired

programme again to eliminate any residual bleach smell; if you want,

you can add softener. Never put both chlorine bleach and softener into

the softener chamber at the same time.

HINTS AND TIPS

Sort your laundry according to

Type of fabric/care label (cotton, mixed fibres, synthetics, wool,

handwash items). Colour (separate coloured and white items, wash

new coloured items separately). Delicates (wash small items – like nylon

stockings – and items with hooks – like bras – in a cloth bag or pillow

case with zip).

Empty all pockets

Objects like coins or lighters can damage your laundry as well as the

drum.

Appliance interior

If you never or seldom wash your laundry at 90°C, we recommend to

occasionally run a 90°C programme without laundry, adding a small

amount of detergent, to keep the interior of the appliance clean.

Follow the dosage recommendation / additives

It optimizes the cleaning result, it avoids irritating residues of surplus

detergent in your laundry and it saves money by avoiding waste of

surplus detergent

Use low temperature and longer duration

The most ecient programmes in terms of energy consumption are

generally those that perform at lower temperatures and longer duration.

Observe the load sizes

Load your washing machine up to the capacity indicated in the

“PROGRAMME CHART” table to save water and energy.

Noise and remaining moisture content

They are inuenced by the spinning speed: the higher the spinning

speed in the spinning phase, the higher the noise and the lower the

remaining moisture content.

CLEANING & MAINTENANCE

For any cleaning and maintenance, switch off and unplug the washing

machine. Do not use flammable fluids to clean the washing machine.

Clean and maintain your washing machine periodically (at least 4 times

per year).

Cleaning the outside of the washing machine

Use a soft damp cloth to clean the outer parts of the washing machine.

Do not use glass or general purpose cleaners, scouring powder or

similar to clean the control panel – these substances might damage the

printing.

Detergent dispenser

Clean regularly, at least three or four times a year, to prevent detergent

build-up:

Press the release button to release the detergent dispenser and 

remove it. A small quantity of water can remain in the dispenser, thus

you should carry it in an upright position. Wash the dispenser using

running water. You can also remove the siphon cap on the back of the

dispenser for cleaning. Replace the siphon cap in the dispenser (if

removed) Reinstall the dispenser by locating the dispenser’s bottom

tabs into the appropriate openings on the lid, and by pushing the

dispenser against the lid until it locks into place. Make sure that the

detergent dispenser is correctly reinstalled.

Checking the water supply hose

Check the inlet hose regularly for brittleness and cracks. If damaged,

replace it by a new hose available through our After-Sales Service or

your specialist dealer. Depending on the hose type: If the inlet hose has

a transparent coating, periodically check if the colour intensifies locally.

If yes, the hose may have a leak and should be replaced. For water stop

hoses (If availeable): check the small safety valve inspection

window (see arrow). If it is red, the water stop function was triggered,

and the hose must be replaced by a new one. For unscrewing this hose,

press the release button (if available) while unscrewing the hose.

Cleaning the mesh filters in the water supply hose

Check and clean regularly (at least two or three times a year).

Close the tap and loosen the inlet hose on the tap. Clean the internal

mesh filter and screw the water inlet hose back onto the tap. Now

unscrew the inlet hose on the rear of the washing machine. Pull off the

mesh filter from the washing machine connection with universal pliers

and clean it. Refit the mesh filter and screw the inlet hose on again. Turn

on the tap and ensure that the connections are completely water-tight.

Cleaning the water filter / draining residual water

The washing machine is provided with a self-cleaning pump. The filter

keeps objects like buttons, coins, safetypins etc. which have been left in

the laundry. If you used a hot wash programme, wait until the water has

cooled down before draining any water. Clean the water filter regularly,

to avoid that the water cannot drain after the wash due to obstruction

of the filter. If the water cannot drain, the indicator indicates that the

water filter may be clogged.

Open the filter cover with a coin. Place a broad, flat container beneath

the water filter, to collect the drain water. Slowly turn the filter

counterclockwise until water flows out. Let the water flow out, without

removing the filter. When the container is full, close the water filter by

turning it in clockwise. Empty the container. Repeat this procedure until

all the water has drained. Lay a cotton cloth beneath the water filter,

which can absorb a small amount of rest water. Then remove the water

filter by turning it out anti clockwise. Clean the water filter (remove

residues in the filter and clean it under running water) and the filter

chamber. Make sure the pump impeller (in the housing behind the

filter) is not obstructed. Insert the water filter and close the filter cover:

Reinsert the water filter again by turning it in clockwise direction. Make

sure to turn it in as far as it goes. To test water tightness of the water

filter, you can pour about 1 liter of water into the drum and check that

water does not leak from the filter. Then close the filter cover.

Lid seal

Check the condition of the lid seal periodically and clean it from time to

time with a damp cloth.

Recovering an object that falls between the drum and the tub

If an object accidentally falls between the drum and the tub, you can

recover it thanks to one of the removable drum lifters.

Unplug the washing machine. Remove the laundry from the drum.

Close the drum flaps and turn the drum a half-turn (picture ). Using a a

screw-driver press on the plastic end, while sliding the lifter from left to

right (picture , ) by hand it will fall into the drum. Open the drum. You b c

can recover the object through the hole in the drum. Refit the lifter

from inside the drum: Position the plastic tip above the hole on the

right side of the drum (picture ). Then slide the plastic lifter from right d

to left until it clips. Close the drum flaps again, turn the drum through

half a turn and check the positioning of the blade at all its anchorage

points. Plug the washing machine in again.

TRANSPORT AND HANDLING

Pull out the mains plug, and close the water tap. Disconnect the inlet

hose from the water tap, and remove the drain hose from your draining

point. Remove all rest water from the hoses and washing machine

and fix hoses so that they cannot get damaged during transport. To

facilitate moving the machine, pull the mobility lever situated at the

bottom front (if available on your model) out a little by hand. Pull the

washing machine out to the stop with the foot. Afterwards push the

mobility lever back into the original stable position. Refit the transport

bracket. Follow the instructions for removing the transport bracket in

the INSTALATION GUIDE in reverse order.

abcd

Quick guide

Produktspecifikationer

Varumärke:	Privileg
Kategori:	tvättmaskin
Modell:	PWT D6512P N

Behöver du hjälp?

Om du behöver hjälp med Privileg PWT D6512P N ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

tvättmaskin Privileg Manualer

Privileg PWT D61253P Bruksanvisning

19 September 2024

Privileg CCPFU843 Bruksanvisning

9 September 2024

Privileg PWT C623 N Bruksanvisning

9 September 2024

Privileg PWF X 104 A Bruksanvisning

5 September 2024

Privileg PWT D6512P N Bruksanvisning

2 September 2024

Privileg PWT D61253P N Bruksanvisning

1 September 2024

Privileg PWF MT 71484 Bruksanvisning

30 Augusti 2024

Privileg Classic 30716 Bruksanvisning

28 Augusti 2024

Privileg Dynamic 7460 Bruksanvisning

26 Augusti 2024

Privileg Dynamic 7420 Bruksanvisning

21 Augusti 2024

tvättmaskin Manualer

Nyaste tvättmaskin Manualer

AEG LTR8C6152A Bruksanvisning

27 Oktober 2024

Samsung WW90T534ATW Bruksanvisning

27 Oktober 2024

Samsung WW10T754DBX Bruksanvisning

27 Oktober 2024

New Pol XF6600EL Bruksanvisning

27 Oktober 2024

Zanussi ZR8441WF Bruksanvisning

27 Oktober 2024

Philco PLDS 1063 Crown Bruksanvisning

27 Oktober 2024

Candy CO 4104TWM/1-S Bruksanvisning

27 Oktober 2024

New Pol XS 271EV Bruksanvisning

27 Oktober 2024

Corberó CLAV822 Bruksanvisning

27 Oktober 2024

Candy CBD485D2CE/1-80 Bruksanvisning

27 Oktober 2024
