Sida 1/9
BAU REI H E ABLU F TSTEUE R U N G
AS-8000
MIT DEN TYPEN: AS-8020, AS-8030 UND AS-8040
BETRIEBSANLEITUNG 02
OPERATING INSTRUCTIONS 22
MODE D’EMPLOI 42
GEBRUIKSAANWIJZING 64
DE
19
Status
Ofen aus
Ofen an
Rollladen
offen
Rollladen
geschlossen
Alle
Batterie
Warnung
Batterie leer
Ofen-Sender
1x langsam GN blinken
Nach korrekter
Rückmeldung
2x schnell blinken
(3 Min. Abtastintervall)
1x langsam RT blinken
Nach korrekter
Rückmeldung
2x schnell blinken
(3 Min. Abtastintervall)
–
–
–
–
–
Fenster-Sender
–
–
–
–
3x schnell blinken,
neuer Kommunikations-
versuch.
Zentrale nicht erreicht,
beendet nach
3 Versuchen den
Verbindungsaufbau
–
–
Rollladen-Sender
–
–
1x langsam GN blinken
Nach korrekter
Rückmeldung
2x schnell blinken
1x langsam RT blinken
Nach korrekter
Rückmeldung
2x schnell blinken
–
–
–
Zentrale (Akustisch)
–
1x Beep
wenn Fenster zu
–
1x Beep
wenn Rollladen zu
–
–
–
Zentrale (LED)
LED Ofen stetig GN
LED Ofen stetig RT
LED Rollladen stetig GN
LED Rollladen stetig RT
–
Bei Ofen an/Fenster
offen/ Rollladen
offen stetig GN mit
blinkendem RT.
Ansonsten blinkendes RT.
LED POWER blinkt RT
Blinkendes Status LED
Ofen/ Fenster/
Rollladen RT
Zentrale (Relais)
Stromkreis
geschlossen
Stromkreis
unterbrochen, wenn
Fenster und
Rollladen zu
Stromkreis
geschlossen
Stromkreis
unterbrochen, wenn
Ofen an
–
Relais gemäß des
Zustandes (siehe
Fenster offen/zu)
Stromkreis
unterbrochen
6. Replace the magnet and close the magnet casing with
the cover.
Attachment points:
• It must be ensured that the gap between the magnet
and the contact is less than 6 mm when the window
is closed.
• The contact must be attached to the upper or side
window frame and casement in such a way that the
distance between the two sections of the casing is
less than 6 mm when the window is closed. Use
the included packing to adjust the parts for (U)
this purpose.
• We recommend attaching the contact and the magnet
with the double-sided sticky tape before the final
mounting and to only screw the elements in place at
the end.
Testing the function of the window tilt
and swivel position
• Slowly move the window to the tilt or swivel position,
then the green LED on the window transmitter (OPEN)
will flash briefly before the maximum tilt or
swivel position.
• Close the window, then the red LED (CLOSED) will
flash briefly.
• Finally check the opening gaps again using the
minimum value determined in accordance with Table 1.
Attaching the roller shutter transmitter
AS-R40 (figures 20 and 25)
NOTE
Attach the roller shutter transmitter and the
magnet to the window and the frame for the initial
operation using double-sided sticky tape. Once the
function test has been completed then the roller
shutter transmitter and the magnet can be
screwed in place
Attaching the roller shutter transmitter
The roller shutter transmitter and the magnet must
be attached as shown in . The roller shutter (Figure 4)
transmitter must be attached to the inside of the
window in the vicinity of the opened roller shutter.
Alternatively the transmitter may also be attached
between the window and the roller shutter but this
will weaken the radio signal. The attachment point
must be selected in such a way that a ‘roller shutter
open’ signal is only produced once the roller shutter
is completely open.
Proceed as follows to attach the roller shutter
transmitter:
1. Mount the lower casing section of the roller shutter
transmitter to the correct position using the included
double-sided sticky pad.
Alternatively there is a prepared hole in the lower casing
section to screw the roller shutter transmitter onto the
window frame. To use this carefully remove the printed
EN
31
