INSTRUKCJA MONTAŻU/ASSEMBLY INSTRUCTIONS
POLSKI/ENGLISH
kod / code: P261809 AW
Nazwa/ Name: Obudowa ABS 265x 5 IP65 185x9 /E
IM 261809
Wydanie: 2 z dnia 01.03.2018
Zastępuje wydanie: 1 z dnia 21.08.2012
PL
1. Przeznaczenie:
Obudowa przeznaczona jest do instalacji SSWiN, CCTV, KD, itp. AWP261809 wymagających współczynnika ochrony IP65.
Współczynnik ochrony IP65 („6” - całkowita ochrona przed kurzem, „5” – hrona przed strumieniem wody). oc
2. Montaż:
Obudowa przeznaczona jest do montażu przez wykwalifikowanego instalatora, posiadającego odpowiednie
(wymagane i konieczne dla danego kraju) zezwolenia i uprawnienia do ingerencji w instalacje 230V/AC oraz instalacje niskonapięciowe.
Obudowa może być montowana na zewnątrz lub wewnątrz w temperaturze z zakresu 20°C do +70°C.-
1. Destination:
Enclosure AWP261809 intended for instalation of security access control & CCTV systems, w h require IP65 protection level. is hic
Protection level IP65 ( anti-„6” – dust protection, „5” anti-water stream protection).
2. Installation:
The metal casing (+PCB) must be installed by a qualified installer, holding the relevant certificates, required and necessary in the particular
country for connecting (interfering with) the 230 V AC systems and low-voltage installations. The casing can be installed both indoor and outdoor,
where the temperature is in the range of -20oC to +70oC
3. Parametry techniczne / Technical data: PL/EN
PARAMETRY
TECHNICZNE
TECHNICAL
DATA
Obudowa: IP
Enclosure: IP
IP 65
Zastosowanie
Destination
Na zewnątrz/do wewn trz ą
outdoor/indoor
Temperatura pracy
Operating temperature
-20oC÷70oC
Wymiary zewnętrzne obudowy:
Wymiary wewnętrzne obudowy:
Wymiary montażowe:
External dimensions of the enclosure:
Internal dimensions of the enclosure:
Mounting dimensions:
W=185, 265, H= D=95 [±2mm]
W1=158, H1=237, D1=85 [±2mm]
W2=152, H2=252 [±2mm]
Zamykanie
Closing
Wkręt walcowy x6
Screwed p1-x6
Waga netto
Net Weight
~0,70 [kg]
Waga brutto
Gross Weight
~0,85 [kg]
Wykonanie
Material description
ABS
Ogólne warunki gwarancji
Ogólne warunki gwarancji dostępne na stronie www.pulsar.pl
ZOBACZ
Pulsar
Siedlec 150, 32- 744 Łapczyca, Polska
Tel. (+48) 14-610- -40, Fax. (+48) 14- - - 19 610 19 50
e-mail:
biuro@pulsar.pl, sales@pulsar.pl
http:// www.pulsar.pl, www.zasilacze.pl
