Sida 1/2
If the spin dryer does not work, check if:
• The inner lid and outer spin bowl lids are closed.
• The spin dry timer is set.
If there is excessive noise, check if:
• Something is touching the pulsator as it rotates.
• The machine is not placed on a level surface.
• The wash load does not exceed more than the machine
can handle to ensure balance during the spin cycle.
• Something is stuck between the spin bowl and tub.
Wash Day Maintenance
At the end of the day:
• Unplug the power cord from the outlet.
• Check that both timers are set to the OFF position "O"
• Wipe the inside and outside of the unit with damp clean cloth.
• Remove the hose from the water tap.
TWIN TUB WASHING MACHINE
Please read the manual carefully before using the machine
CLEANING AFTER USE
• Always clean the washing machine after every use. Ensure the power switch is
turned off and disconnected from the electrical outlet before performing this action.
POINTS TO REMEMBER
• Avoid using excessive amounts of bleach or detergent; use the amount of soap
recommended by the manufacturer.
• For your safety, ensure that the ground connection is correct.
• Never put your hands into the spin tub while operating.
• When washing, the water temperature should be below 120°F. This is to prevent
the plastic components from being deformed.
• Do not place the washing machine close to heat generating products such as gas
or electric cookers.
• Use soft cloth when cleaning the washing machine to prevent damages on the
surface of the cabinet.
• Do not place wet load on the control panel.
• Do not place washing machine outside or in a damp area.
BEFORE YOU CALL FOR SERVICE
• If you suspect the washing machine requires maintenance, follow these instructions
to save unnecessary costs before calling the manufacturer or a technician.
• If the washing machine will not start, check if:
o The hose circuit breaker is tripped or a fuse is blown.
o The cord is firmly connected to the power point or the power is not switched “ON”.
o Something is stuck and is preventing the pulsator from rotating.
o The wash timer is set.
TABLE OF CONTENTS
Contents Page
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chief Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operation Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Laundry Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cleaning After Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Point To Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before You Call For Service . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintenance After Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
INSTRUCTION MANUAL
PUCWM22
WARNING
• When connecting the appliance to the water main, use a new hose,
do not use an old hose.
• For washing machines with ventilation openings at the base, ensure that nothing
is obstructing the openings.
• If the power cord is damaged, it must be replaced by the manufacturer/distributor
or a certified technician.
• This appliance is not intended to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Do leave children unattended and play near the appliance.
To Rinse In The Wash Tub
• Set the selector knob to “WASH” mode.
• Turn the water tap on.
• When the rinse water became clear, turn off the water tap.
• Set the selector switch “DRAIN” position to discharge the water.
Spin Drying
• To open the inner safety lid of the spin tub, lift up the outer spin cover and then
lift up the safety lid.
• Transfer the wash load to the spin tub commencing with small articles.
Ensure that the clothes are evenly distributed.
• Place the removable spin mat over the load to be dried and push lightly downward.
(To contain delicate articles within the tub.)
• Set the spin timer to the time recommended in the Laundry Guide.
The spin tub will spin for the time selected and then stop on (at the position “O”).
Caution:
Ensure that the spin tub completely stops before reaching in to the wash load.
Do not leave children unattended during this process.
• To remove or reposition clothes during the spin dry cycle, open the spin cover and
inner lids. In this case, the spin tub will automatically stop as a brake is activated
when the spin cover is opened. To restart, close both lids. If required,
reset the spin timer.
• Turn off the spin drying and rearrange the clothes inside the tub if abnormal
vibration is observed during spin drying.
INSTALLATION
Electrical Connection
• The unit is designed to function under the recommended power settings mentioned
in the rating label at the back of the washing machine.
• The power cord must be plugged into a grounded 3-pin outlet.
• If the power cord is damaged, it should be replaced by the manufacturer/distributor
or a certified technician.
Connection of Water Inlet Hose
• Attach the water inlet hose to the water inlet (Please refer to the Parts Identification
on page 1). Caution: Please use water BELOW 120°F.
• The drain hose should be placed so that the water can drain down without any
obstruction.
OPERATION INSTRUCTION
Preparing the Wash
• The machine should be placed on a flat surface.
• Separate the laundry into different groups like: white clothes, color clothes, delicate
clothes, lint-free and etc. Wash the laundry according to the washing guide.
• Clothes with worn patches or tears should be mended first. Empty all pockets and
close all fasteners.
Prior to Wash
• Remove the plastic spin mat from the spin tub.
• Check if wash timer knob is set to position “0” and the selector switch is set to “Wash”.
• Ensure that drain hose is placed properly to allow draining.
• Insert the power cord into a grounded 3-pin outlet.
To Wash
• Place the wash load and detergent in the wash tub.
• Set the selector switch to “Wash” mode.
• Fill the washing machine with water as recommended in the “Laundry Guide.”
• Set the wash timer to the wash period recommended in the laundry guide.
Your machine will now wash for the time selected. When the wash period expires,
set the selector switch to “Drain” position to discharge the water.
Simultaneous Washing and Spin Drying
• The machine has two motors designed for washing and spin drying that allows the
user to load, wash and spin dry all at the same time.
• Set the controls for both “wash” and “spin” modes (see “To Wash” and Spin Drying”).
CLEARING THE TUB
• First, set the selector knob to “DRAIN” mode.
• Wait until the machine empties completely.
• Then, set the selector knob to “WASH” mode.
• Lastly, unplug the power cord from the outlet.
PARTS IDENTIFICATION
1. CONTROL PANEL
2. WATER INLET
3. PULSATOR
4. WASH TUB LID
5. HOUSING
6. SPIN TUB LID
7. SPIN TUB
8. POWER CORD
9. PLASTIC SPIN MAT
10.DRAIN HOSE
LAUNDRY GUIDE
Type of
Fabric
Size of
Wash
Load
Water Level
(Volume)
Degree of
Soiling
Water
Temperature
Wash Cycle
Wash
Period
Spin
Period
Colored
Cotton and
Linens
Full
Half &
Less
High
Low
Heavy
Normal
Light
Below 104°F 5-10 mins. 3-5 mins
Nylon and
P.P
Delicates
Below 104°F
Below 104°F
Full
Half &
Less
Half &
Less
High
Low
High
Normal
Light
Normal
to Light
4-5 mins.
2-3 mins.
2-3 mins.
2 mins.
1-2 mins.
CHIEF TECHNICAL DATA
Model
Rated Wash
Capacity
Rated Input
Power
Rated Power
Source
Energy Efficiency
Grade: 5
Wash Cleaning Rate 0.7
Packaging
Dimension
Net/Gross
Weight
Input Water
Pressure
Area
MPA
LengthxWidthxDepth
Consume
Water
(L/Cycle/KG)
Consume
Electricity
(KWh/Cycle/KG)
FrequencyVoltageSpinWashWash Spin
PUCWM22 3.5KG 1.5KG 250W 120W 110V 60 Hz 0.032 36 590x390x675(MM) 11/13KG 0.05~0.3
