Sida 1/2

Source/Pair

Adjust the switch to one of

the sources to turn the unit

on. In Bluetooth mode,

press to begin pairing.

USB CHARGER LINE IN

AC IN~

SOURCE/PAIR

OFF

/LINE IN

FM 88 91 94 98 102 106 108 MHz

AM 530 700 900 1100 1300 1500 1700 KHz

• Battery shall not be exposed to excessive heat such as sunshine, or the like.

• Keep new and used batteries away from children. If the battery compartment does not close securely,

stop using the product and keep it away from children.

• If you think batteries might have been swallowed or placed inside any part of the body, seek

immediate medical attention.

• Do not mix old and new batteries.

• Completely replace all old batteries with new ones.

• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.

• Batteries should be recycled or disposed of as per state and local guidelines.

FEATUR ONES AND C TROLS

Bluetooth Wooden Retro Radio

User’s Guide for Model No. RETRO-100

Important Safety Instructions

• Read these Instructions.

• Keep these Instructions.

• Heed all Warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with a dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including that produce heat.

• Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two

blades with one wider than the other. A grounding type plug has two blades and a third grounding

prong. wide blade or the third prong are provided for your safety. When the provided plug does

not into your outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

• Only use attachments/accessories by the manufacturer.

• Unplug this apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to service personnel. Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the app aratus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

• Use only with a cart, stand, tripod, bracket, or table by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

FCC Warnings

Warning: Chan ges or to this unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate t he equipment.

NOTE: equipment has bee n tested and found to comply wit h the limits for a Class B digital device,

pursuant to Part 15 of the FCC Ru s. le limits are d ignedes to provide reasonable protection against

harmful interference in a r idential installation. es equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instr uctions, may cause harmful

interference to radio communications. However, there is no guarantee t hat interference will not o ccur

in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can b e determi ned by turning t he equipmen t and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Additional Warnings and Precautions

• CAU TION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE

SLOT, FULLY INSERT.

• WARNING: To reduce the risk of or electric shock, do not expose this apparatus to rain,

moisture, dripping, or splashing.

• CAUTION: Use of controls or adjustments or performance of procedures other than those

may result in hazardous radiation exposure.

• WARNING: Changes or to this unit not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

• WARNING: Do not place this unit directly onto furniture surfaces with any type of porous, or

sensitive As with any rubber compound made with oils, the feet could cause marks or staining

where the feet reside. We recommend using a protective barrier such as a cloth or a piece of glass

between the unit and the surface to reduce the risk of damage and/or staining.

• WARNING: Use of this unit near lighting may cause interference regarding use of the

remote. If the unit is displaying erratic behavior move away from any lighting, as it may

be the cause.

• CAU TION: Danger of explosion if battery is incorrectly replaced. Replace only with the s ame or

equivalent type.

• WARNING: is a danger of explosion if you attempt to charge standard Alkaline batteries in the

unit. Only use rechargeable NiMH batteries.

• WARNING: Lithium batteries, like all rechargeable batteries, are recyclable andshould be recycled

or disposed of in normal household waste. Contact your local government for disposal or recycling

practices in your area. should never be incinerated since they might explode.

• WARNING: Shock hazard - Do Not Open.

• Caution and marking information is located at the rear or bottom of the apparatus.

• Objects with liquids, such as vases, shall not be placed on the apparatus.

• Mains plug is used as disconnect device and it should remain readily operable during intended

use. In order to disconnect the apparatus from the mains completely, the mains plug should be

disconnected form the mains socket outlet completely.

WARNING: To reduce the risk of tric shock, do not remove cover elec

(or back). No user-serv able parts inside. Refer serv ing to ice ic

service pe nel. rson

CAUTION

The ex ion point within an eq u eral t riangle is intended to ert the clamat ilat al

user to the presence of impo rtant oper ing a nd intenance (serv ing) at ma ic

instru ions in the erature co mpanying the app ance.ct lit ac li

This symbol ind es that this product inc r es uble i u ion icat orpo at do ns lat

between h a ous ins vo age and user essible parts. az rd ma lt acc

The lightning with a owhead symbol, within an equ eral triangle, is rr ilat

intended to ert the user to the presence of uninsu ed “dangerous vo age” al lat lt

within the pr uct’s enclosu re that may be of od magnitude to

cons tute a risk of tric ock to pe ns.ti elec sh rso

FEATURES

• 3.5mm audio input

• Analog volume control

• USB port for mobile phone charging

• LED pairing indicator

• Built-in AM/FM wire antenna

• Bluetooth Wireless range: 33 feet

• AC power input: requires an AC power cable (included)

Tuning

Turn to adjust the AM or

FM radio station.

Volume

Turn to adjust the volume.

3.5mm Audio Line Input

USB Charging Port

AC Power Input

Pairing Indicator

R OADI

Playing the Radio

1. Adjust the Source/Pair knob to AM or FM radio mode.

2. Adjust the Tuning dial to tune the radio.

Radio Reception

An AM and FM antenna is built into the radio. To improve radio reception, adjust

the position of the unit.

USB CHARGER LINE IN

AC IN~

Power to unit

Power to device

USB CHARGER LINE IN

AC IN~

PO R & R GWE CHA GIN

Plug the AC/DC power adapter AC Power Input (included) into the on the unit, and a standard power outlet. The unit can be used to charge mobile devices through a

USB Charging Port in the rear, as seen below (additional USB cable not included).

Using the Audio Input

Requires a 3.5mm audio cable (included).

1. Connect a 3.5mm audio cable to the on the unit and the Line In Input

audio output on an audio device.

2. Adjust the Source/Pair knob to the Bluetooth/Line in setting. Use the native

controls on the connected device to play your audio through the unit.

BLUETOOTH

Pairing a Bluetooth Device for the First Time

1. Adjust the Source/Pair knob to the Bluetooth/Line in setting.

of the unit.

2. Press the Source/Pair knob.
