Sida 1/5
www.avsl.com 151.545UK User Manual
Multi-Bar
LED Multi-Effects Bar with Tripod
Item ref: 1.545 15 UK
User Manual
Complete portable lighting solution comprising 2 PAR cans, Ball effect,
laser and UV/Strobe units all powered from a main T-bar. Easily
controlled via DMX, infra-red remote control or internal auto and
sound-activated programs selectable from the rear control panel. Each
lighting fixture is angle-adjustable to distribute colour washes and
effects around the room. Supplied with 2.3m telescopic tripod stand
and carry bags making it ideal for transporting to parties and events.
In the box:
Your M -Bar should arrive with you in a single carton in good condition. T carton should contain ulti he
1 x T-bar with 2 RGBW PAR cans, RGBW Ball, R/G laser and UV/Strobe un s attached 1 x 2.3m Tripod it ,
Stand, 1 x Remote Control, 1 x UK 3m IEC mains lead, 1 x T-Bar Carry Bag, 1 x Tripod Stand Carry Bag
and 1 x user manual.
Warning:
To prevent risk of re or electric shock, do not expo the unit to rain or damp environments. In the event fi se
of a spillage, disconnect the mains and al w the unit to dry out naturally. Qualified personnel should then lo
check the unit before continuing use.
Please read rough this manual thoroughly before use, any dama th ge
cause by misuse of product will not be covered by warrantd y.
Please do not open cover, con s high voltage. This tain
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 1.545UK User Manual 15
Caution: Las radiation er
Avoid pointing directly towards eyes. Laser output can cause injury if viewed directly.
This product is a Class 3B laser and should only be installed and used by persons who
are trained in the management of laser radiation and are able to op ate in accordance er
within the guid given by the Health and Safety Exance ecutive (HSE) in HS(G)95: “The
Radiation Safety of Lasers used for Display purposes”. Copies of this guide can be
downloaded from: www.avsl.com/assets/docum /hsg95.pdfents
Placement:
• Open the included tripod stand legs onto the floor ensuring the thumbscrews are tightened and it s ’
set down on a flat stable surface away from walk ys or where it can be easily knocked over. wa
• Attach the T-Bar to the top of the stand and tighten the thumbscrew ensuring its secure.
• Keep the unit away from damp or dusty environments.
• Ensure adequate air- ow around the fixture housings. fl
• Ensure ade ate access tqu o controls and connections.
• Do not aim LED or laser output directly into line of sight, as this can result in eye injury.
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Use a vacuum cleaner to clear venti tion gr of any dust or debris build-ups. la illes
• Do not use strong solvents for cleaning the unit.
Rear panel and controls:
1. IEC input (110-240 Vac, 50/60 Hz)
2. Earth screw (do not remove)
3. DMX input
4. DMX output
5. UV/Strobe bar input
6. Control panel
7. LED display
8. Microphone
9. Laser key
1.
2.
3.
4.
5.
6.
7.
8.
www.avsl.com 1.545UK User Manual 15
Manual control menu:
Press the “ ” buttoMENU n to enter the settings menu.
Press “ ” and “UP DOWN” buttons to navigate through various setting functions.
Press button confirm the desired setting. “ENTER” to
Display
Mode
d - d 001 512
DMX addres settings s
CH nd
DMX channel select 3CH-12CH
At01-At09
Auto mode program select
S_01-S_ 32
Auto mode speed select (slow to fast)
So01-S003
Sound active mode select
Sn01-Sn09
Sound active mode sensitivity adjust
Slav
Slave mode
DM mode: X
The Multi-Bar can be controll by DMX signal, simply connect the DMX signal source the DMX inped to ut on
the unit a balanced XLR lead. Extra fixtures can be controlled by the same DMX signa by looping vi a l
through the DMX out on the To ent DMX mode, select A001 from the menu and counit. er nfirm the correct
start address using the and ons and by “ ”UP “ ”DOWN butt “ENTER”. The A on the LED display will begin
to flash once it s received the DMX signal from the controller. This unit has 3 or DMX ch nels as ’12 an
indicated in the tables below:
3 Channel:
CH
DMX Value
Function
Description
1
0- 009
Blackout
010- 039
Auto mode 1
All fixtures
040 069-
Auto mode 2
PAR lights (colour jump change)
070 099-
Auto mode 3
PAR, LED Ball & Laser
100 129-
Auto mode 4
PAR, LED Ball Laser & Strobe ,
13 1590-
Auto mode 5
PAR, LED Ball, Laser & UV
160 189-
Auto mode 6
PAR, LED Ball, Strobe & UV
19 2190-
Auto mode 7
PAR, Laser, Strobe & UV
220 249-
Auto mode 8
LED ball, Laser, Strobe & UV
250 255-
Auto mode 9
UV
2
0- 009
Blackout
010 089-
Sound mode 1
All fixtures
0 - 90 169
Sound mode 2
PAR, LED Ball Laser & Strobe ,
170 255-
Sound mode 3
LED ball, Laser, Strobe & UV
3
0- 255
Speed/Sensitivity
12 Channel:
CH
DMX Value
Function
Description
1
0- 255
Red
LED Ball (no1)
2
0- 255
Green
3
0- 255
Blue
4
0- 255
White
5
0- 255
Motor
6
0- 255
Red
PAR light (no2)
