www.avsl.com 151.737UK User Manual
TetraCube
Rechargeable 4- -1 Portable Effect Light in
Item ref: 1.737 15 UK
User Manual
Perfect for smaller venues the QTX TetraCube portable effect
light, offers 4 eye-popping features in one compact package.
Easy operation using the remote control or auto/sound to light
modes and the added convenience of an internal rechargeable
battery offering up to 6 hours of wire free light shows without
the need of additional power. Filling smaller rooms with RGB
washes, strobes, magic ball effects or 2 colour laser waves the
QTX TetraCube provides surprisingly bright and colourful
coverage for such a small unit.
In the box:
Your TetraCube should arrive with you in a single carton in good cond T carton should contain 1 x ition. he
main unit, 1x stand/fix g acket, 1x remote control, 1x laser key and 1 x user guide. in br
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect powthe er and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Caution: Las radiation er
Avoid pointing directly towards eyes. Laser output can cause injury if viewed directly.
This product is a Class 3B laser and should only be installed and used by persons who
are trained in the management of laser radiation and are able to op ate in accordance er
within the guid ance given by the Health and Safety Executive (HSE) in HS(G)95: “The
Radiation Safety of Lasers used for Display purposes”. Copies of this guide can be
downloaded from: www.avsl.com/assets/docum /hsg95.pdfents
Placement:
• Use the included mounting stand/bracket either position on a stable surface or fix to a sta or to nd
ligh truss. ting
• Keep the away from damp or dusty environments. unit
• Do not aim LED or laser output directly into line of sight, as this can result in eye injury.
Please read through this manual thoroughly before use, y damage an
cause by misuse of product will be covered rrantd not by wa y.
www.avsl.com 1. 7UK User Manual 15 73
Usage Instructions:
• Connect the USB charging lead provided to a suitable USB power supply and fully charge the unit
before first use. You should receive up to 6 hours of normal use a single charge. for
• Use the switch on the back of the unit to power the unit on and the function button on the front to
choose between the unit’s various lighting mode s.
• To enable and disable the laser, use the laser key provided in the y on the back of the unit.ke hole
Remote control:
The TetraCube is supplied with an I.R. remote control for quick access the extended functions of the to
unit. Thi has a maximum range of approximately 4-5m and must be aimed towards the front of the units .
Controls and functions are listed on the diagram below:
Specifications:
Power supply
4.2V 4000mAh Lithium Battery
Power consumption
10W
Light source
2pcs white LED strobe, 2pcs RGB LED, RGB LED ball
effect, red/green laser
Modes
Auto, sound light, remote control to
Remote battery
CR2025 (supplied)
Dimensions
120 x 90 x 80mm
Weight
355g
Thi product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at s
the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions e e ed.xc pt
Copyright© 2023 AVSL Group Ltd Unit 2 Bridgewater Park, AVSL (Europe) d, it 3D Nor P nt House, , Lt Un th oi
T lor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus Park, New Mallow Ro , Cork, Ireland. ay . ad
1. ON/OFF = Power on/off
2. Color = Manual colour select
3. Auto 1+2 Auto modes 1 and 2 =
4. Sound 1+2 = Sound modes 1 and 2
5. LED AUTO LED ball auto mode =
6. LED R/G/B = LED ball colour select
7. PAR AUTO PAR lights auto mode =
8. PAR R/G/B PAR lights colour select =
9. Laser AUTO = Laser auto mode
10. Strobe = Strobe ect on eff
11. Laser R/G Laser colour sele (red/green) = ct
12. Mode +/- Laser effect speed adjust =
13. SEN +/- Sound mode sensitivity adjust =
14. 0.5A + 1A = 0.5 1 hour timer set or
15. 2A + 3A = 2 3 hour timer set or
NOTE: To set the timer, first select the desired
mode (i.e Auto 1) then press the length of time
required. T unit will flash 4 times then return he
to your selected mode and power off at the end
of the set time span.
1.
3.
5.
6.
2.
9.
8.
4.
10.
11.
12.
13.
14.
15.
