PAR 54
4in1 LED PAR Can
Item ref: 4. 5 15 03 UK
User Manual
Thank you for choosing the PAR a lightweight and compact LED PAR Can fitted with 9x 6W 4- -54, in 1
RGBW LEDs. This unit can be controlled by auto, sound- -light, master/slave programs or via 8 channel to
DMX. A versatile and value solution for background wash illumination requirements.
In the box:
Your PAR should arrive with you in a single carton in good condition. T carton should contain 54 he
1 x main unit with bracket and screws, 1x remote contro 1 x UK IEC mains lead and 1 x user guide. l,
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally Qualified personnel should then .
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
Cause by misuse of product will be covered by warrantd not y.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 4. 5UK User Manual 15 03
Placement:
• Use the included mounting bracket to fix to a stand or lighting truss
• Keep away from damp or dusty environments
• Ensure adequate airflow around the fixture housings
• Ensure adequate access to controls and connections
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required
• Use a vacuum cleaner to clear ventilation grilles of any dust or de s build-ups bri
• Do not use strong solvents for cleaning the unit
Rear panel controls:
1. Manual control buttons
2. DMX Signal in
3. DMX signal out
4. LED display
5. IEC power in (fused)
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “ ” and “ ”UP DOWN buttons to navigate through various setting functio ns.
P button save the desired setting. ress “ ”ENTER to
Menu
Number range
Function and description
A001
A001-A512
DMX address setting 512
IrYE
IrYE or Irno
IR remote control on or off
AU01
AU01-AU07
Manual colour selection
FF00
FF00-FF99
Colour jump setting (speed slow to fast)
2.
3.
5.
1.
www.avsl.com 4. 5UK User Manual 15 03
EE00
EE00-EE99
Colour fade setting (speed slow to fast)
CC00
CC00-CC99
Colour pulse setting (speed slow to fast)
F000
F000-F255
Strobe setting (speed slow to fast)
So UD
SoU0-SoU9
Sound to light colour jump setting (sensitivity high to low)
SUnD
SU -SU n0 n9
Sound to light co pulse setting (sensitivity high to low) lour
r000
r000-r255
Red dimming (0-100%)
G000
G000-G255
Green dimming (0-100%)
b000
b000-b 255
Blue dimming (0-100%)
u0 00
u000-u255
White dimming (0-100%)
o0 00
o0 -o255 00
IR remote control dimming (dark to bright)
Remote control:
The PAR is supplied with an I.R. remote control for quick access to most of the basic functions of the 54
unit. Thi has a maximum range of approximately 4-5m and must be aimed towards the front of the units .
Controls and functions are listed on the diagram below:
DMX mode:
The PAR can be controll by DMX signal, simply connect the DMX sig sourc the DMX input on 54 ed nal e to
the via balanced XLR lead. Extra fixtures can be controlled by the same X signal by looping unit a DM
through the DMX out on the To enter DMX mode, select A001 from the menu and co m the correct unit. nfir
start address using t and buttons and by he “ ”UP “ ”DOWN “ENTER” to confirm .
This unit has 8 DMX channels as indicated in the b l : ta le be ow
Channel
Value
Function
CH1
0-255
Master dimming (0-100%)
CH2
10-255
Strobe (speed slow to fas t)
CH3
0- 50
CH1-CH6 control
051-100
Manual c lection olour se
101-150
Col r jump ou
151-200
Colour fade
201-250
Colour pulse
CH4
0-255
Function speed control (slow to fast)
1. Power = Remote on/off
2. + = Increase option setting
3. D = DMX512 open/off MX
4. Auto = Automatic mode
5. R = Red open/off ed
6. Motor = Manual colour select
7. Jump = Colour jump mo de
8. Sound Sound activated mode =
9. -- Decrease option setting =
10. Green = Green open/off
11. Blue = Blue open/off
12. White = White open/off
13. Flash = Strobe open/off
14. Gradual = Colour fade mode
1.
2.
3.
4.
5.
6.
7.
10.
11.
12.
13.
14.
