Sida 1/4
www.av .comsl 151.556UK User Manual
PB-1214
LED PAR BAR SYSTEM
Item ref: 151.556UK
User Manual
Please read through this manual thoroughly
before use, any damage caused by misuse of
the product will not be covered by the warranty.
www.av .comsl 151.556UK User Manu
Safety Instructions
• Please keep this manual for future reference.
• Always make sure that you are connecting to the proper voltage, and that the line voltage you are
connecting to is not higher than that stated on the bottom of the fixture.
• This product is intended for indoor use only. It must be connected to an earthed mains outlet.
• To prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least 20cm from adjacent surfaces. Be
sure that no ventilation slots are obstructed.
• Always disconnect from power source before servicing or replacing fuse and be sure to replace with same
fuse size and type.
• Maximum ambient temperature is 40°C. Do not operate the fixture at higher temperatures.
• In the event of a serious operating problem, stop using the unit immediately. Never try to repair the unit by
yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the
nearest authorised technical assistance centre.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
DMX-512 connection
If you are using a standard DMX controller, you can connect the DMX output from the controller directly to the
DMX input of the first unit in the DMX chain. Connect the DMX output of the first unit in a DMX chain with the
DMX input of the next unit in the chain. Always connect the output of one unit with the input of the next unit
until all units are connected.
Number
Item
Function
1
Power supply input
Attach the IEC mains cable here.
2
DMX input
3 pin XLR connector for DMX 512 input communication.
3
DMX output
3 pin XLR connector for DMX512 output communication.
4
LED display
LED function display and menu buttons to control the operating
mode of the unit.
5
MENU buttons
MENU function buttons Menu, Up, Down Enter
6
Microphone
Built-in microphone for Sound- -Light operation. to
7
Par can mounts
Attach the par can lights to the controller bar
8
Par can connections
Attach the par can cables to the controller bar
9
Light stand socket
Tighten screw to secure the controller bar to the light stand.
www.av .comsl 151.556UK User Manu
Function Settings
Using the four function buttons on the controller bar you can set the operating mode of the unit. Press the
‘Menu’ button to display the different functions (see table below for a description of the functions). Use the
‘Up’ ‘Down’ arrow buttons to make your selection. When you have chosen your desired function, press the
‘Enter’ button to confirm the selection.
Sequence
Number
Display
Sub-Menu
Function/Action
1
d001 d512 –
001 512-
DMX address setting
2
IP.01 IP.64 –
001 512-
IP mode
3
A1.01
A1.01 A1.18 –
Static Colour. Select one of 18 colour options
4
A2.01
A2.01 A2.32 –
Colour Jump. A2.01 (slowest) A2.32 (fastest)
5
A3.01
A3.01 A3.19 –
Multi Colour. Different Colour selection available
6
A4.01
A4.01 A4.04 –
Sound to Light Function
7
A5.01
A5.01 A5.32 –
Strobe Function A5.01(slowest) A5.32 (fastest)
8
r000 r255 –
Adjust red colour intensity. r000 (off) r252 (brightes t)
9
G000 G255 –
Adjust green colour intensity. G000 (off) G252
(brightest)
10
b000 b255 –
Adjust blue colour intensity. b000 (off) b252 (brightest)
11
u000 u252 –
Adjust white colour intensity. u000 (off) u252
(brightest)
DMX address setting
When controlling the unit (or units) with a DMX controller, each one must be set with a specific DMX address.
You can choose to set all units with the same DMX address (usually d001) or you can set every unit with its
own DMX address. If all units are set with the same DMX address all units will be synchronised and operate in
the same way.
If you set each unit with a different DMX address, they will receive the DMX signal from their own DMX
address. You will now be able to control each unit individually. The DMX address that you set for each unit
must be determined by the number of channels. The PB-1214 has 8 DMX channels, therefore you should set
the starting address of the first unit to 1 (d001), the second unit must be set to 9 (d009) being 1+8, the third
to 17 (d017) being 9+8, the fourth to 25 (d025) being 17+8 and so on.
Channel
Value
Function
1
0 10-
Macro A1
11 50-
Macro A2
51 100-
Macro A3
101 150-
Macro A4
201 255-
Macro A5
210 255–
Red + Green + Blue
2
0 255-
Macro Colour
3
0 25- 5
Speed Adjustment
4
0 255-
Master Dimmer
5
0 255-
Red Dimmer
6
0 255-
Green Dimmer
7
0 255-
Blue Dimmer
8
0 255-
White Dimmer
