Sida 1/8

www.avslgroup.com 151.558UK

PB-7

High Power Foldable PAR Bar

Item ref: 151.558 UK

User Manual

Thank you for choosing this QTX PB-7 PAR bar. A foldable PAR bar kit fantastic for mobile DJs

and performers who need their lighting to be quick to set up and easily transportable. This

PAR bar boasts 4 high power Cans, each fitted with 7 x 3W RGB LEDs. Smooth colour blending

can be achieved by controlling with the included foot controller or via DMX.

In the box:

Your PB-7 should arrive to you in two separate cartons in good condition.

Carton 1:

• PAR bar with 4 LED PAR Cans

• Foot controller

• Foam carry case

• 2 x IEC mains lead (UK and EU)

Carton 2:

• 35mmØ tripod stand

• Stand bag

Warning:

To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments.

In the event of a spillage, disconnect the mains and allow the unit to dry out naturally.

Qualified personnel should then check the unit before continuing use.

• Always check the correct voltage and the condition of the IEC lead before connecting to a

power outlet.

• Always ensure any DMX leads used are in good condition with no short connections or

damaged plugs.

Please read through this manual thoroughly before use, any damage cause by

misuse of product will not be covered by warranty.

Please do not open cover, contain high voltage. This

product is not serviceable or repairable by end user.

Please refer to qualified personnel for service and repair.

www.avslgroup.com 151.558UK

Setup:

Release the clasp that holds the top bar in the folded position and unfold to the open position

as pictured below. There are two clasps at the back of the unit that need to be locked to keep

the top bar in the open position.

The opened top bar can now be place on to the supplied tripod stand and adjust to desired ed

height. Each LED PAR Can pans and tilts to face different directions and angles.

Back panel:

1. LCD Display

2. Manual control buttons

3. DMX signal in (DMX male socket)

4. DMX signal out (DMX female plug)

5. Foot controller socket

6. Built in m ic

7. IEC socket

8. Earth connection screw

DO NOT REMOVE

www.avslgroup.com 151.558UK

Manual control menu:

Press the “menu” button to enter the setting menu.

P s. ress “up” and “down” to navigate through various setting option

P the desired setting. ress “enter” to enter

C s and confirm setting by pressing hoose set value by “up” and “down” button “enter”.

Display

Mode

Press ENTER for setting





DMX address



 



to





DMX channel mode



 



 



 



 



, , , 1 1or





Slave mode



 



 



 



= master, = slave 1, = slave 2





Auto mode



 



 to





Sound activation



 



 



= sound to light on, = sound to light off





Microphone

sensitivity



 



 



 



 (0-100% gain)





Blackout mode



 



 



 = on, = blackout





LED display dimmer



 



 



 = display off after 20s = constant display





LED display inverted



 



 



 / (normal or inverted display)





Fixture test

sequence

Fixture steps through all functions press MENU to exit–









Fixture hours

Displays how many hours of use for the fixture





Operation:

The PB-7 can operate in stand-alone master slave or DMX modes. , ,

Stand-alone/master/slave:

For stand-alone mode, first choose whether sound to light is required by selecting or



 





from . Then select one of the eight pre-programmed modes from option to



 







 







 



, select for random chase option. Further PB-7 units can be controlled by one

master unit allowing synchronization. Ensure the master unit slave mode is set as



 





and the controlled unit slave mode is set as or . Connect DMX out from the master



 





unit to the DMX in of the slave unit.

DMX mode:

The -7 can be control by DMX signal, simply connect the DMX signal source to the DMX in PB

of the unit via balanced XLR lead. Extra fixtures can be controlled by the same DMX signal a

by looping through the DMX out on the -7. Ensure the correct DMX start address is set from PB

the option on the manual control.




