www.avsl.com 160.4 UK User Manual 76
QTFX-9 00
Fog Machine
Item ref: 160.476UK
User Manual
Please read through this manual thoroughly before use, any damage
Cause by misuse of product will not be covered by warranty.d
www.avsl.com 160.4 UK User Manual 76
Introduction
Thank you for choosing the QTFX-900 as part of your stage effects system.
This machine is designed to provide generous fog output and reliable service for medium sized
venues. Please read these instructions fully to achieve the best results and avoid damage
through misuse.
Unpacking
Your QTFX-9 should reach you in good condition and should be supplied with IEC mains 00
lead(s), mounting bracket, wireless controller with remote and wired handheld remote.
If there are any signs of damage or items missing from the packaging, contact your dealer
immediately.
Warning
To prevent risk of fire or electric shock, do not expose electrical parts to rain or moisture.
If liquids are spilled on the housing or through the vents, disconnect the mains, allow the
QTFX-9 to dry out and have it checked by qualified personnel before further use. 00
Avoid any impact, dropping or extreme pressure to the housing.
No user serviceable parts inside - do not open the case.
Allow the QTFX- to acclimatize to room temperature before operating. 900
Refer all servicing to qualified service personnel.
Placement
The QTFX- has a built-in fluid tank and should be operated in an upright position. 900
If free-standing, ensure that the QTFX- is positioned on a stable, non-slip surface. 900
If mounted at height, use the integral bracket and it is advisable to add a safety cable.
Safety
• Check for correct voltage and condition of IEC lead before connecting to power outlet.
• Check the condition of the remote lead and ensure that it is not trapped.
• This unit must be earthed.
• This unit uses a heating element - do not touch the nozzle area whilst in use!
Cleaning
• Use a soft dry or slightly damp to clean the casing.
• Do not use strong solvents for cleaning the unit.
• It is recommended to use fog machine cleaning fluid (160.670UK) periodically.
www.avsl.com 160.476UK User Manual
Layout and connections
Setting up and operation
The QTFX-9 requires fog fluid to produce the effect. 00
It is recommended to use one of the range of qtx fog fluids for best results.
• Unscrew the top cap of the tank and remove to fill with the selected fog fluid.
• Replace the cap and close securely, ensuring the pipe is fed down to the bottom of the
bottle so a consistent flow of fluid is supplied to the machine.
• Select either wired or RF remote control and connect to the appropriate socket (4, 7).
• Connect the IEC mains plug.
• Check the fog fluid level indicator at the rear and fill if necessary.
• Switch the mains power on.
• Heat up time is approximately 3-6 minutes. Please ensure that the remote button is not
pressed during the heat up time.
• If fluid level is empty, the heater will shut down and the Fluid Low LED will light.
• Switch off when not in use.
• Unplug from mains if not in use for long periods.
1.
Fog output nozzle
5.
Fluid low warning LED
2.
Mounting bracket
6.
Fluid level indicator
3.
Fog fluid tank
7.
RF remote control connection
4.
Wired remote control connection
8.
Mains inlet IEC & fuse holder
