Sida 1/5
www.avslgroup.com 160.447UK
QTFX-LF900
Low Level Fog Machine
Item ref: 160.447UK
User Manual
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
www.avslgroup.com 160.447UK
Introduction
Thank you for choosing the QTFX-LF900 low level fog machine as part of your stage effects setup. This
machine is designed to emulate low lying dry ice effects using cooled fog fluid.
Please read and keep this manual to ensure maximum performance and avoid damage through misuse.
Unpacking
Your QTFX-LF900 should reach you in good condition and should be supplied with IEC mains lead(s) and a
wired handheld remote control. If there are any signs of damage or items missing from the packaging, contact
your dealer immediately.
Warning
To prevent risk of fire or electric shock, do not expose electrical parts to rain or moisture.
If liquids are spilled on the housing or through the vents, disconnect the mains, allow the QTFX-LF900 to dry
out and have it checked by qualified personnel before further use.
Avoid any impact, dropping or extreme pressure to the housing.
No user serviceable parts inside - do not open the case (other than to access the ice reservoir)
Refer all servicing to qualified service personnel.
Placement
The QTFX-LF900 has a ice reservoir and fluid tank, so should be operated in the upright position only. n
Choose a position where the g output zzle is not obstructed and is facing the general area to be filled. fo no
Ensure easy access to the rear panel, fluid tank and ice reservoir
Safety
• Check for correct mains voltage and condition of IEC lead before connecting to power outlet
• Check the condition of the remote lead and ensure that it is not trapped
• This unit must be earthed
Cleaning
• Use a soft dry or slightly damp cloth to clean the casing
• Do not use strong solvents for cleaning the unit
• It is recommended to use fog machine cleaning fluid (160.670UK) periodically
Setting up
The QTFX-LF900 requires fog fluid and ice (water ice) to produce the effect.
It is recommended to use qtx low level fog fluid for best results (160.5 UK, 160.5 UK) 92 93
This fluid is specially formulated to achieve a dense, low lying fog effect.
A chart for recommended fog fluids is included further along in this document.
Unscrew the top cap of the tank fill with the recommended smoke fluid. and
Screw the cap securely ensuring the pipe is fed down to the bottom of the bottle so a consistent flow of fluid
is supplied to the machine.
Unscrew the safety screw on top panel to open and fill the reservoir with no more than 5kg of ice.
Close the top panel and secure the safety screw.
Connect the remote control via the 5-pin connector on the rear panel.
Connect the IEC mains plug, ensuring correct supply voltage.
www.avslgroup.com 160.447UK
Layout
1. Carry Handle
2. Top panel lifts up for loading the ice
3. Safety screw to secure top panel
4. Fog output nozzle
5. Fluid bottle
(Note: the fluid bottle cannot be removed)
Rear panel
1. Remote control connection
2. Power ON/OFF
3. IEC mains inlet and fuse holder
4. Fluid drain tap
Remote control / timer control
1. Timer on/off button
2. Continuous output
3. Manual override button
4. Timer LED indicator (Illuminated when timer active)
5. Manual ready indicator
6. Continuous LED indicator (Illuminated when continuous active)
7. Adjust the amount of f is released ( 100%) og 0 –
NOTE:
The below controls are only used in timer mode
8. Adjust the interval gap between each release of Fo g
(between 30 Min approximately) 0 –
9. Adjust the duration the Fog is released at each interval
(between 0 15 seconds approximately) –
