www.avsl.com 4.055UK User Manual 15
SpectraWash
240W LED Colour Blinder and Strobe
Item ref: 4.055 15 UK
User Manual
The SpectraWash is a powerful 240W Multicolour LED stage-blinder that can produce a vast array of
moving effects, strobes and washes. Easy to setup and use via a wide range of integrated automatic and
sound to light programs or for more precise control there are 4 DMX modes to choose from. Fitted with
twist and lock power connections for a more professional feel and housed in an all-metal casing with fan
cooling for durability and reliable operation.
In the box:
Your SpectraWash s ld arrive with you in a single carton in good condition. T carton should contain hou he
1 x main uni fixing bracket with thumbscrews, 1 x twist and lock UK mains lead and 1 x user guide. t, 1
Warning:
To prevent risk of fire or electric shock, do not expo the unit to rain or damp environments. In the event se
of a spillage, disconnect the mains and al w the unit to dry out naturally. Qualified personnel should then lo
check the unit before continuing use.
Please read rough this manual thoroughly before use, any dama th ge
cause by misuse of product will not be covered by warrantd y.
Please do not open cover, contains high volt e. This ag
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 4.055UK User Manual 15
Placement:
• Use the included mounting bracket fix a stand or lighting truss. to to
• Use secondar safety fixings if mounting overhead. y
• Keep away from damp or dusty environments.
• Ensure adequate airflow around the fixture housings.
• Ensure ade ate access to controls and connections. qu
• Do not aim LED tput directly into line of sight, as this can result in eye injury. ou
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups.
• Do not use strong solvents for cleaning the unit.
Rear panel controls:
1. Power input (twist and lock)
2. Power output (twist and lock)
3. Fan ventilation (do not cover)
4. DMX input
5. DMX output
6. Led display
7 Control panel.
Manual control menu:
P ss the re “ ” buttoMENU n to enter the settings menu.
Press “ ” and “UP DOWN” buttons to navigate through various setting functions.
P button confirm the desired setting. ress “ENTER” to
Function
Description
A001-A512
DMX address settin gs
CH03-CH39
Switch between CH04, CH11, CH32 and CH39 then
press Enter key to save (default CH11)
1.
2.
3.
4.
6.
7.
www.avsl.com 4.055UK User Manual 15
M000-M083
Switch between 84 diffe RGB effects then press rent
Enter key to save
S000-S255
Modify the operating speed of the RGB effects (slow
to fast) then press Enter key to save
M000-M040
Switch between 41 different White effects then press
Enter key to save
S000-S255
Modify the operating speed of the White effects
(slow to fast) then press Enter key to save
Soud
Sound activated mode
R255-R000
Red linear dimmer (0-100%) default is R255
G255-G000
Green linear dimmer (0-100%) default is G255
B -B000 255
Blue linear dimmer (0-100%) default is B255
W255-W000
White linear dimmer (0-100%) default is W 255
T000
Displa current fixture temperature (eg T045 means y
current temp is 45°C; if 10K thermistor is not
installed display will read T000)
Factory settings:
When any address code is A001~A512, press the menu button for 3 seconds to enter the factory settings
mode. In this mode you can adjust the output power of the lamps, fan setting mode, setting temperature
protection point, and sending parameters. Exit the factory settings mode at any time by pressing the
menu button for 3 seconds.
Function
Description
R255-R032
Modify the red colour up or down, then press enter to save (Default
setting is R200)
G255-G032
Modify the green colour up or down, then press enter to save (Default
setting is G200)
B -B032 255
Modify the blue colour up or down, then press enter to save (Default
setting is B200)
W255-W032
Modify the white colour up or down, then press enter to save (Default
setting is W200)
FAN0-FAN1
FAN0 lamp bead lights up to start the fan, FAN1 reaches the set
temperature protection point to start the fan, confirm to save.
T040-T105
Set the temp protection point, modify the parameter up or down
(40℃~105℃) press enter to save. (Default setting is T060)
Send
Send the factory setting parameters of this fixture up or down to all
other lights connected in parallel. Confirm the sending of the
parameters and press the menu button for 3 seconds to exit. If the
parameters are denied, press the ENTER button to cancel the sending.
DMX mode:
The SpectraWash can be controlled by DMX signal, simply connect the DMX signal source the DMX to
input on the unit a balanced XLR lead. Extra fixtures can be controlled by the same DMX signa by vi a l
looping through the DMX o To enter DMX mode, select d001 from the menu and cout uniton the . nfirm
the correct start address and channel selection using the and buttons and by “ ”UP “ ”DOWN “ ”ENTER .
The d on the LED display will begin to flash once it s received the DMX signal from con oller. This “ ” ’ the tr
unit has 4, 11, 32 or 3 DMX channels as indicated in the tables below: 9
