www.avsl.com 154.047UK User Manual
Tri-PAR
Rechargeable PAR Uplighter
Item ref: 4.0 15 47UK
User Manual
Compact yet surprisingly powerful, the QTX Tri-PAR is perfect for many events and scenarios. Three super
bright 4W LEDs provide colourful mixes and washes for walls and ceilings and the internal, rechargeable
battery means the unit is totally portable and can be placed in any location without requiring a power
source. Simple to operate using the onboard control panel, supplied RF remote control or DMX if
preferred, the Tri-PAR is packed with features and integrated light shows that are sure to illuminate any
occasion.
In the box:
Your -PAR should arrive with you in a single carton in good condition. T carton should contain Tri he
1 x main unit, 1x remote contro 1 x UK IEC mains lead and 1 x user guide. l,
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally Qualified personnel should then .
check the unit before continuing use.
Please read through t s manual thoroughly before use, any damage hi
Cause by misuse of product will be covered by warrantd not y.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel r service and repair. fo
www.avsl.com 4.0 UK User Manual 15 47
Placement:
• Keep away from damp or dusty environments.
• Ensure adequate airflow around the fixture housings.
• Ensure adequate access to controls and connections.
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Use a vacuum cleaner to clear ventilation grilles of any dust or de s build-ups. bri
• Do not use strong solvents for cleaning the unit.
Front/rear panel controls:
1. Battery status indicators
2. LED display
3. Manual control buttons
4. Microphone
5. DMX input
6. DMX output
7. On/off switch
8. IEC power output
9. IEC power input (fused)
Charging the battery:
The QTX -Par can be either mains or battery powered as it contains an internal rechargeable lithium Tri
battery. To charge the unit simply connect to mains power using the IEC lead supplied and keep the
Power Switch (7) off. When charging, the battery status light will glow red and when completely charged
it will turn green s recommended to fully charge the -Par before first use and let the power run down . It’Tri
each time before recharging to achieve optimum battery life of the unit.
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “ ” and “ ”UP DOWN buttons to navigate thr h various setting functio oug ns.
P button save the desired setting. ress “ ”ENTER to
1.
2.
3.
4.
5.
6.
7.
8.
9.
www.avsl.com 4.0 UK User Manual 15 47
Menu
Number range
Function and description
A001
A001-A512
DMX address setting 512
Chnd
4Ch, 6Ch, 8Ch
DMX channel selection
FAIL
B Lnd
DMX data is not ma ained int
HOLd
DMX data retention
CL01
CL01-CL15
Static colour modes
St00-St16
Strobe effect speed select (slow to fast)
Aut0
Aut0-Aut4
Auto colour change modes
Sp01-Sp16
Auto modes speed select (slow to fast)
SoU1
SoU0- 3 SoU
Sound to light modes
nAnU
d0 -d 00 255
Manua mode master dimmer (0-100%) l
r000-r255
Manual mode red dimming (0-100%)
G000-G255
Manual mode green dimming (0-100%)
b000-b 255
Manual mode blue dimming (0-100%)
U000-U255
Manual mode white dimming (0-100%)
S0 -S255 00
Manual mode strobe speed (slow to fast)
test
Colour test mode
Led
o n/off
Digital display on/off
IrcL
o n/off
IR remote on/off
v er
2.0
Software version number
Advanced parameter settings:
In A001 mode press and hold the Enter button for 3 seconds to enable/disable.
Press Menu button at any time to return to normal mode.
Menu
Number range
Function and description
r
r.001-r.255
Red colour regulation (0-100%)
G
G.001-G.255
Green colour regulation (0-100%)
b
b.001-b.255
Blue colour regulation (0-100%)
U
U.001-U. 255
White colour regulation (0-100%)
L
L .on
Colour regulation mode all bright
L.OFF
Colour regulation mode monochrome
F
F.00.6
600Hz refresh rate
F.01.2
1.2K refresh rate
F.02.0
2K refresh rate
F.04.0
4K refresh rate
F.12.0
12K refresh rate
F.24.0
24K refresh rate
t
t.000
Temperature displa (Celsius) y
n
n.OFF
Smart thermostat off
n.040-n.095
Smart temperature control on (40° to 90° power reduction)
d
d.on
Dimming delay on
d.OFF
Dimming delay o ff
C
C.0
Linear curve
C.1
Square curve
C.2
Logarithmic cur ve
C.3
S-curve
