RAM_OCS v3 Quick Guide

INSTALLATION AND FIRST STEPS

Welcome to RAM OCS, the Online Control System for RAM Audio V/W Series DSP amplifiers. By using it you can control

and monitor the DSP unit of a V/W amplifier through an Ethernet network or a USB connection, in a Windows system.

To start, install the software in a Windows system (XP, Vista, 7, 8 or 10) and connect the amplifiers to the Ethernet network or

the USB port. Each amplifier is programmed from factory with a unique IP number inside the range 192.168.xxx.xxx. To de-

tect initially the amplifiers you have to work inside this range. Change the computer IP to 192.168.0.10 for example, and use

a mask 255.255.0.0. After detect the amplifiers inside this range you can change the IP of each one if required.

Execute the RAM OCS software using the Shortcut created in the desktop and start scanning the network. To do that, click in

the loupe (1) icon placed near to the left top side of the window. The system has to detect all amplifiers you have connected

in your network or connected using the USB port. To open an amplifier you have to do a double click on the amplifier showed

in the devices tree (2).

Create a virtual amplifier: if you do not have any amplifier connected to the system, you can add an offline amplifier clicking

with the right mouse button on the “Amplifiers” section of the devices tree (3), and selecting the Add device option.

To obtain some help for the different button functions, you can maintain the cursor over a button for two seconds to show a

hint which can help you.

The elements of the main screen are as follows:

Project Menu Tab Amp Menu Tab

Devices Tree:

show a list of all

amplifiers detected

in your Ethernet

network or USB

connection

Amp Information:

show the model,

serial number,

name, IP address

and firmware ver-

sion of the selec-

ted amplifier

Amps Scan - Tree

management icons

Poject/Amp Menu

Icons

Frequency response graphic window

Amplifier configuration main window

MAIN MENU DESCRIPTION

- Project Menu icons:

It contains different sections:

File section: contains different icons for manage your project, to open or save the structure of an amplifier group. Also you

can create a new empty project.

Settings section: contains the following icons:

- : pressing this icon you can change the name or the IP of an amplifier. Also you can send a buzz to a spe-Ethernet devices

cific amplifier to do a blinking of the back panel LEDs to help you to identify an amplifier.

- : permits to change different software parameters, as can be the dB scale of the response window, humidity Preferences

and temperature taken in account to calculate the speed of sound, wrapped or unwrapped phase representation, or write a

resume of the current project. Also, contains a button for firmware update.

View section: contains the following icons:

- : shows the graphical window with the frequency response of your current DSP configuration. Show Frequency Response

- : turn on/off the monitor mode which permits to read the real time data of the current amplifier. You can see it Monitor Online

in the Gain or Amp Setup tabs

- Amplifier Menu icons:

It contains different sections:

File section: contains different icons where you can manage your Library, to open or save the current PC Library. Also you

can create a new empty Library.

Communications section: using the icons you can send or receive the current library to/from the amp. These icons are the

same you have in the Sync Library section of the Library Tab. Also you can send to the amp a new DSP firmware to upgrade

it in the future.

View section: contains the following icons:

- : shows the graphical window with the frequency response of your current DSP configuration. Show Frequency Response

- : turn on/off the monitor mode which permits to read the real time data of the current amplifier. You can see it Monitor Online

in the Gain or Amp Setup tabs.

- : turn on/off the real time mode, so any change you make in the DSP configuration or the amplifier Real Time Operation

setup is replayed instantaneously. When you enable this option, it will synchronize the amp and the PC configuration, sen-

ding the current configuration you have in the PC to the amplifier.
