Sida 1/2
Pi
DSP management: RAM OCS and amplifier display:
Two general working modes: User and Advanced (manufacturer)
· User functionalities:
- Input Routing matrix Analog/Dante/AES3
- Input EQ section with 8 filters and 20 memories
- Input EQ Use section, predefined by the manufacturer
- System Preset selection predefined by the manufacturer
(Locked/Unlocked)
- Snapshot library management up to 20 pre-sets
- Master Control Groups
· Advanced functionalities (manufacturer):
- Input EQ “Use” section creation, up to 20 pre-sets
- Ways routing section (Locked/Unlocked)
- IIR EQ section: XOver, Gain, Delay, and 7 EQ filters
- FIR EQ section: linear phase XOver and EQ filters, or
custom up to 1000 taps
- RMS and Peak Dynamic control
- Snapshot library management up to 20 pre-sets (Locked/Unlocked)
- System Preset library management up to 100 pre-sets
- 5 Security levels definition to limit final user functionality
■ Extra-large TFT display, capacitive touch panel user inter-
face
■ 64 bit double-precision 96kHz DSP process
■ High performance 96kHz/24 bits AD/DA converters
■ Available versions with DanteTM Networking (AES67) and
AES3 Digital inputs
■ Two ports Ethernet switch for daisy chain connection
■ USB port for firmware update and DSP control
■ High voltage output for high headroom performances
■ Similar power per channel in any impedance
■ Advanced power management to squeeze until the last
watt of your speakers
■ Exceptional power sharing in asymmetrical loads
■ Powerful and fast response cooling system
Series
OUTPUT POWER Pi2- 3K Pi2-5K Pi4-6K Pi4-10K
2 ohms 2x 1450 W 2x 2500 W 4x 1450 W 4x 2500 W
4 ohms 2x 1500 W 2x 2500 W 4x 1500 W 4x 2500 W
8 ohms 2x 1100 W 2x 1600 W 4x 1100 W 4x 1600 W
Hi-Z 70V 2x 1500 W 2x 2500 W 4x 1500 W 4x 2500 W
Hi-Z 100V 2x 800 W 2x 2500 W 4x 800W 4x 2500 W
©2021 by C.E. Studio-2 s.l. Pol.Ind. La Figuera - C/Rosa de Luxemburgo nº34 - 46970 Alaquas - Valencia - SPAIN
Phone:+34 96 127 30 54 - ramaudio.com - e-mail: info@ramaudio.com
RAM Audio®, PMS™, SSP™, ICL™ and QuantaPulse™ are registered trademarks of C.E. Studio-2 s.l.. All other names are trademarks of their respective companies.
Amplifier Specifications
DSP Specifications - RAM_OCS Control
Overall:
• High performance 96kHz/24 bits AD/DA converters
• 64 bit double-precision 96kHz DSP process
• 0.85 ms minimum process latency time
• Custom FIR process up to 1000 taps
• Dante and AES3 input versions
Input Section (x4):
• Gain, Mute and Phase inversion
• Input Delay: Up to 114 meters (333ms)
• Input EQ: 16 filters (Param., Shelving, LP, HP, BP, SB, AP)
Output Section (x4):
• Crossover Filters: FIR and IIR (up to 48dB/oct,
Butterw./LR/Bessel)
• Output Delay: 0 to 31 meters (90ms) per channel
• Output IIR EQ: 12 filters per channel (Param., Shel, LP, HP,
BP, SB, AP)
• Output FIR EQ: 20 filters per channel (Parametric,
Shelving, LP, HP, BP, SB, AP), or Custom. Up to 1000 taps
• RMS and Peak limiter per channel
Communications:
• Two ports Ethernet switch for daisy chain connection
• USB 2.0 Type B port
Miscellaneous:
• 100 Manufacturer system preset memories library
• 20 User preset memories library
• 20 User snapshot memories library
• Manufacturer/User passwords
• User control groups for virtual Equalization, Gain and
Delay
• Zones definition for library management and alerts infor-
mation
• Smaart® analysis software integration
Pi2-3K Pi2-5K Pi4-6K Pi4-10K
Number of channels 2 2 4 4
Total output power 3000 W 5000 W 6000 W 10000 W
Output Power* (All ch.’s driven/single channel)
2 ohms 2x 1450 W 22x 2500 W 24x 1450 W 24x 2500 W 2
1x 1450 W 21x 2500 W 21x 1450 W 21x 2500 W 2
4 ohms 2x 1500 W 2x 2500 W 4x 1500 W 4x 2500 W 1
1x 1750 W 1x 2800 W 1x 1900 W 1x 3000 W
8 ohms 2x 1100 W 2x 1600 W 4x 1100 W 4x 1600 W
1x 1150 W 1x 1700 W 1x 1200 W 1x 1800 W
4 ohms Bridged 2900 W 25000 W 22x 2900 W 22x 5000 W 2
8 ohms Bridged 3000 W 5000 W 2x 3000 W 2x 5000 W 1
Hi-Z 70V 2x 1500 W 2x 2500 W 2 4x 1500 W 4x 2500 W 2
Hi-Z 100V 2x 800 W 2x 2500 W 4x 800 W 4x 2500 W 1
Max output voltage 144 V 176 V 144 V 176 Vpeak peak peak peak
Max output current 38 A 50 A 38 A 50 Apeak peak peak peak
Total Harmonic Distortion <0.05%
Voltage Gain 26dB to 44dB (1dB step)
SNR 106 dBA 107.5 dBA 106 dBA 107.5 dBA
Required AC Mains
Operating Voltage (50Hz-60Hz) 170V-265V AC / 90V-140V AC
1/8 Rated Power (@230V, 4 ohms) 7 A 8 A 15 A 16 A
Dimensions W x H x D (mm) 483x89x320
Weight Net (kg-Lbs) 6-13.2 8.5-18.7 8.5-18.7 8.5-18.7
Protections: Soft-start, Turn-on Turn-off transients, Muting at turn-on, Over-heating, DC, RF, Short-circuit, Open or mismatched loads,
Overloaded power supply, ICL™, PMS™, and SSP™
* IEC filtered pink noise signal (40Hz-5kHz, 12dB crest factor). 230V AC mains.
1 PMS can limit output to prevent excessive current draw tripping the mains breaker.
2 SSP can limit output to prevent excessive heating.
