Sida 1/4
Manual-1
MLM82S
MIC/LINE MIXER
OPERATORS MANUAL
MLM82S CONNECTION
When connecting the MLM82S to other components in your
system for the rst time, leave the power cord for last. is gives
you a chance to make mistakes and correct them without dam-
age to your fragile speakers, ears and nerves.
MIC/LINE INPUTS 1-4
e four XLR jacks provided on the MLM82S are balanced
MIC/LINE inputs. ey will also accept unbalanced connec-
tors. Use only shielded cable for inputs. For best noise rejection
use two-conductor-plus-shielded wire, even for unbalanced
operation. Connect the shield at both ends to help insure proper
grounding. See the Sound System Interconnection RaneNote
included with this manual for all cable adaptations. Rane follows
the AES recommended practice of pin 2 positive, pin 3 negative,
and pin 1 to shield. Switch any input connected to a microphone
to the MIC position (out) using the associated switches on the
rear panel. When connecting line level signals, switch the input
to the LINE position (in). A single phantom power switch is
provided for the four MIC inputs. If LINE is selected, Phantom
Power is disabled for that input.
QUICK START
is section is provided as a convenience for those in a rush. If you are experienced with this unit or other Rane products, these few
words will refresh your memory.
INPUTS 1 through 4 may be microphone or line level. e choice between the two is made by setting the LINE push buttons
on the REAR of the unit next to the . Each microphone input may be assigned to , MIC/LINE INPUT JACKS A B or outputs A+B
using the front panel ASSIGN switches.
INPUTS 5 through 8 are stereo line inputs which may be set to mono using the recessed MONO switches located on the front
panel.
Internal switches allow setting output signal levels for e factory default setting is . If the MLM82S is con-MIC or LINE. LINE
nected directly to a power amplier, equalizer or recorder input, choose level. If the MLM82S is connected to a microphone LINE
jack of an existing sound system, choose MIC level.
Once Inputs, Outputs, and power are properly connected, with the OUTPUT LEVELS counterclockwise (o ), set the Input
LEVELS as high as possible without causing the SIG/OL indicators to blink red except during extreme signal peaks. Now slowly
raise the OUTPUT LEVELS as desired.
STEREO LINE INPUTS 5-8
e ¼" connectors are line-level balanced/unbalanced Inputs.
If the MLM82S is to be used with unbalanced sources, consult
the Sound System Interconnection RaneNote included with this
manual for proper wiring. Stereo Inputs use both A and B jacks
at each INPUT. INPUTS 5 through 8 also serve as mono Inputs
when the front panel MONO switch is engaged.
OUTPUTS
e MLM82S’s OUTPUTS are balanced. e same wiring
conventions as the XLR Inputs apply. e type of device follow-
ing the MLM82S must be considered when setting the internal
Output Level switch. Choose between LINE (0 dB) or MIC (-40
dB) output, the factory setting is LINE. If the MLM82S is con-
nected directly to a power amplier input, choose LINE level. If
the MLM82S is connected to a microphone jack on an existing
sound system, choose MIC level. For unbalanced OUTPUT
connections do not tie pin 3 (i.e. “–”) to ground.
WEAR PARTS:is product contains no wear parts.
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
MLM82S
MIC / LINE MIXE R
POWER
OUTPUTS
1
MONO MIC / LINE INPUTS
STEREO LINE INPUTS
OL
A+B
ASSIGN
MONO
SIG/ OL
2
A+B
ASSIGN
SIG/ OL
A+B
ASSIGN
SIG/ OL
4
MONO
MONO
8
MONO
A
OL
B
A+B
ASSIGN
SIG/ OL
LEVELLEVELLEVELLEVELLEVELLEVELLEVELLEVELLEVELLEVEL
Manual-2
FRONT PANEL DESCRIPTION
1 SIGnal present/OverLoad LED. is bi-color LED lights green for a -30 dBu signal, and turns red when the Input is within 3
dB of clipping.
2 MONO MIC/LINE INPUT LEVEL controls 1-4 determine the MIC/LINE preamp gain and mix level to be assigned to the A,
A+B, B Outputs.
3 ASSIGN switches determine between the A, A+B or B Outputs for each MIC/LINE input.
4 STEREO LINE INPUT LEVEL controls 5-8 determine the amount of stereo or mono line Input routed to the Outputs.
5 MONO switch mixes the A and B sides of each STEREO LINE input together. When active, the associated LED lights, and the A
and B Inputs for that channel have exactly the same level.
6 OUTPUT OverLoad LED illuminates within 3 dB of an approaching overload condition. To avoid this, the associated OUT-
PUT LEVEL control may be decreased, or the problem-causing individual Input Level may be lowered.
7 set the Output Level for A and B outputs.A and B OUTPUT LEVEL controls
8 is lit whenever adequate power is applied to the unit.POWER LED
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
MLM82S
MIC / LINE MIXE R
POWER
OUTPUTS
1
MONO MIC / LINE INPUTS
STEREO LINE INPUTS
OL
A+B
ASSIGN
MONO
SIG/ OL
2
A+B
ASSIGN
SIG/ OL
A+B
ASSIGN
SIG/ OL
4
MONO
MONO
8
MONO
A
OL
B
A+B
ASSIGN
SIG/ OL
LEVELLEVELLEVELLEVELLEVELLEVELLEVELLEVELLEVELLEVEL
2 3 4 51 7 86
Manual-3
REAR PANEL DESCRIPTION
1 MIC/LINE INPUTS 1 through 4. ese XLRs connect either balanced Microphone or Line signals, depending on the LINE
switch setting (see ). Rane adheres to the international and U.S. standard for balanced pin congurations: Pin 1 is chassis 3
ground (neutral), pin 2 is positive (+), and pin 3 is negative (–).
2 PHANTOM POWER switch applies 15 V Phantom Power to any Inputs 1-4 that are set for MIC Input.
3 LINE Input selectors switch the sensitivity and input impedance for either a microphone or line level input. If LINE is chosen,
Phantom Power is deactivated for that Input.
4 ¼" LINE INPUTS. ese stereo pairs of balanced inputs accommodate stereo line-level signals. ese TRS (Tip-Ring-Sleeve) ¼"
jacks handle either balanced or unbalanced signals. In most cases an unbalanced signal may use a mono ¼" plug (Tip-Sleeve). See
the Sound System Interconnection RaneNote included with this manual for proper connection.
5 A and B OUTPUT jacks. ese balanced XLR’s provide the A and B mixed output. INTERNAL OUTPUT LEVEL switches
allow setting the output level for MIC or LINE level. Pin connections are the same as above in .1
6 Power connector: e internal universal switching power supply operates on any AC mains 100 to 240 VAC, 50 or 60 Hz (most
places in the world). All that is required when traveling is the appropriate IEC line cord.
LINE
MADE IN U.S.A. RANE CORP.
LINE
LINE
LINE
15V
PHANTOM
POWER
MLM82S
5
B
6
A
7
8
A
B
OUTPUTS
1
3
4
2
LINE INPUTS
MIC / LINE INPUTS
BALANCED:
PIN 3 =
(–),
PIN 2 =
(+),
PIN 1 = (G)
100-240 V
50/60 Hz 7 WATTS
ACN 001 345 482
COMMERCIAL
AUDIO
EQUIPMENT
24TJ
R
6 23
514
