Sida 1/3

RELACART Set MIPASSPORT Wireless Cameramount Microphone System + LM-P01 Lavalie

Art. No.: 20000865

GTIN: 4026397674361

List price: 177.31 €

incl. 19% VAT.

Logistic

EAN / GTIN: 4026397674361

Weight: 0,55 kg

Length: 0.00 m

Width: 0.00 m

Heigth: 0.00 m

Features:

RELACART MIPASSPORT Wireless Cameramount Microphone System

Wireless audio transmission system for cameras

- Portable transmitter and receiver with attachment clip

- Perfect video sound for cameras, smartphones, camcorders, etc.

- Easy attachment to clothing, the camera's hot shoe, etc.

- Ultra-compact and lightweight design

- Rechargeable lithium batteries

- Charging via USB-C socket

- Transmitter with integrated omnidirectional condenser microphone

- 3.5 mm TRS jack for an external lavalier microphone (optional)

- Receiver with 3.5 mm TRS jack for your recording device and 4-stage gain control (0 dB, -3 dB,

-6 dB, -9 dB)

- Automatic pairing in 2 seconds

- Up to 6 systems can be operated simultaneously (max. range 20 m)

- Works with iOS and Android devices

- OLED display

- 2.4 GHz license-free worldwide

- Operating range up to 40m with line-of-sight

- For application areas such as: Trade fair and shop tting; mobile use; mobile djs/entertainer;

homerecording and studios; video and photography

transmitter

- Polar pattern: Omnidirectional

- Cordless, exible and versatile

- Battery operation up to 7h

Receiver

- Cordless, exible and versatile

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

- Battery operation up to 7h

Package contents

- 1 x transmitter, 1 x receiver, 2 x jack cable, 1 x uSB cable, 1 x windshield, 1 x user manual, 1 x

declaration of conformity

RELACART LM-P01 Lavalier for MIPASSPORT System

Inconspicuous electret lavalier microphone

- Provides high-quality voice pickup

- For attaching to the user's tie, shirt or collar

- Polar pattern: Omnidirectional

Package contents

- 1 x microphone, 2 x windshield, 1 x bag, 1 x user manual

Technical specications:

Weight: 130 g

RELACART MIPASSPORT Wireless Cameramount Microphone System

Type: Wireless set

Power supply: 5 V DC 500 mA

Power connection: Battery/battery pack

Mains input via USB C (M) mounting version

power supply cord for USB A mains connection

(provided)

Number of channels: 1

Frequency range: 100 - 20000 Hz

S/N ratio: >93 dB

Max. SPL: 97 dB

Display type: OLED display

Frequency band: 2.4 GHz

Range: Range up to 40m with line-of-sight

Switch: On/o switch

Material: Plastic

Color: Black

Dimensions: Width: 4,4 cm

Depth: 1,9 cm

Height: 5 cm

Weight: 120 g

Transmitter

Capsule type: Electret

Polar pattern: Omnidirectional

Battery pack type: 1 x lithium ion 3,7 V, 435 mAh, 1,61 Wh

Battery pack: Battery operation up to 7h

Connections: Input: Microphone via 3.5 mm jack (mono)

mounting version 2,5 V

RF power output: 10 dBm

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

Weight: 32 g

Receiver

Battery pack type: 1 x lithium ion 3,7 V, 435 mAh, 1,61 Wh

Battery pack: Battery operation up to 7h

Connections: Output: 3.5 mm jack (mono) mounting version

Weight: 32 g

RELACART LM-P01 Lavalier for MIPASSPORT System

Type: Lavalier microphone

Power supply: 1,5-9 V DC

Power connection: Via 3.5 mm jack (mono)

Cable length: 1,2 m

Capsule type: Electret

Size: Ø 8 mm x 18 mm

Polar pattern: Omnidirectional

Frequency range: 50 - 20000 Hz

S/N ratio: >65 dB

Sensitivity: -39 dB

Impedance: 2200 Ohm

Switch: Without

Material: Aluminum

Color: Black

Weight: 20 g
